KDWLC1015A Dual Ear Wireless Charging Specification
一、Product Parameters:
Input voltage
Input current
Output power
Output parameters
Operating
Frequency
Antenna type
Modulation
FOD protection
Wireless charging
over temperature
protection
Standby current
Wireless charging
indicator light
DC9V
9V@2A
Max 10W
9V/1A;
5V/1A
(There are differences in the output voltage of different
fixtures)
111-205KHz
Coil antenna
FSK
The wireless charging end of the mobile phone has metal
FOD protection enabled
65+/-3℃
< 70mA
Wireless charging standby working green. lightWireless
charging standby green light always on, working green light
flashing slowly.

Advertisement

loading
Need help?

Need help?

Do you have a question about the KDWLC1015A and is the answer not in the manual?

Questions and answers

Summary of Contents for Kaidi KDWLC1015A

  • Page 1 KDWLC1015A Dual Ear Wireless Charging Specification 一、Product Parameters: Input voltage DC9V Input current 9V@2A Output power Max 10W Output parameters 9V/1A; 5V/1A (There are differences in the output voltage of different fixtures) Operating 111-205KHz Frequency Antenna type Coil antenna Modulation...
