1.Product parameter
Wireless charging
Compatible protocol
Output Power
Input voltage
Protect function
Indicator light
instruction
USB instruction
Working temperature
2. System configuration
User Manual
QI-BPP aggreement
Samsung Fast Charge Agreement
DC29V
Over temperature protection, FOD foreign object detection
1. Standby state: the indicator light is not lit
2. Charging status: indicator light is green
3.If there is any abnormality such as foreign matter during
over-temperature and wireless charging, the indicator light will
flash green.
Maximum output 5V/2A, support USB charging and wireless
charging at the same time.
0-35℃
5W
10W
Advertisement
Table of Contents
Related Manuals for Kaidi KDDY101
Summary of Contents for Kaidi KDDY101
- Page 1 User Manual 1.Product parameter Wireless charging QI-BPP aggreement Compatible protocol Samsung Fast Charge Agreement Output Power Input voltage DC29V Protect function Over temperature protection, FOD foreign object detection 1. Standby state: the indicator light is not lit 2. Charging status: indicator light is green Indicator light 3.If there is any abnormality such as foreign matter during instruction...
- Page 2 3.Instructions I.Provide wireless charging DC29V power supply through a dedicated power adapter. Once powered, you can start working properly. II.Put the mobile phone with wireless charging function (such as iPhone8/8plus/X, Samsung Note8/S9+, Huawei mate20Pro, etc.) into the wireless charging slot, and the charging will start automatically.
- Page 3 4.Notes ⚫ Do not mix metal foreign objects between the phone and the wireless charger while charging. ⚫ In order to ensure normal charging, the thickness of the plastic or silicone mobile phone case is less than 1-2mm. The material and thickness of the phone case can affect the normal charging function and increase the temperature of the wireless charging.
