Thickness gauge for coating and clad layer
Instruction Manual
Dongguan Xintai Instrument Co.,Ltd.
Add: Building F, No. 13-16, Hongye Industrial Zone, Tangxia
community, Tangxia Town, Dongguan City
Postcode:523710
Tel:+86-769-82612006
Fax:+86-769-82612005
Website:www.hti-meter.com
https://hti-instrument.com www.xintest.en.alibaba.com
Version 2.0 Revised 9/10/2019.
HT-128
Advertisement
Table of Contents
Related Manuals for HTI HT-128
Summary of Contents for HTI HT-128
- Page 1 Thickness gauge for coating and clad layer Instruction Manual Dongguan Xintai Instrument Co.,Ltd. Add: Building F, No. 13-16, Hongye Industrial Zone, Tangxia community, Tangxia Town, Dongguan City Postcode:523710 Tel:+86-769-82612006 Fax:+86-769-82612005 Website:www.hti-meter.com https://hti-instrument.com www.xintest.en.alibaba.com Version 2.0 Revised 9/10/2019. HT-128...
- Page 2 Table of content Product introduction ------------------------1 Considerations ------------------------ -----1 Install/replace battery ----------------------2 Product description 1. Structure information --------------------3 2. Description of display information ---- -----4 Use of the product 1. Power on/off ------------------------ -----4 2. Basic measurement ---------------------5 3. Backlight --------------------------- -----6...
-
Page 3: Table Of Contents
4. Check data - - - - -------------------------6 Measurement method for sand-blasted surface -1 8 5. Delete data - - - - -------------------------6 Communication ---------------------------1 9 6.Alarm setting - - - -------------------------6 Product specification ----------------- ----2 1 7.Statistics data --------------------------8 Frequently asked questions --------------2 3 8.Setting of probe mode... -
Page 4: Product Introduction
Product introduction 3.Please keep sensors clean and avoid dirt and oil stain, etc. 4.Wet cotton cloth or 95% alcohol should be used to wipe or The product adopts two types of principle of electro-magnetic clean the instrument at the time of cleaning. Don’t use induction and eddy current effect. -
Page 5: Product Description
Product description 2. Description of display information 1. Structure information Group mode Battery level indicator USB interface Battery box Data number Current readings Unit Display Substrate nature indication screen N:non magnetic conductive substrate F:magnetic conductive Max： substrate Mean Min： Mean： Menu key Power key ZERO... -
Page 6: Check Data
2. Basic measurement it indicates that the materials are identical. Direct measurement The measurement will be affected when the battery level is may be made. low. Measurement should be carried out when the battery has 3. Backlight high level. The default work of the instrument is at mode of After power on, the backlight is on automatically. -
Page 7: Statistics Data
setting for the upper limit value. Press the down key to select 7. Statistics data Press ZERO CAL key to enter the menu bar. Press up/down the place to be changed. Press the up key once to increase key to select “Count” and press OK key to enter the interface. the value by adding 1. -
Page 8: Group Mode
10. Measurement mode Magnetis mode: It is for measurement of coating thickness Single measurement:The probe touches perpendicularly and of magnetic substrate and cannot be used to measure the presses against the tested objects slightly. After completion coating thickness of non magnetic conductive substrate. of test, lift the probe and carry out measurement of the next Vortex mode: It is for measurement of coating thickness of time. -
Page 9: Calibration Method
13. Calibration Method A i r There are two types of calibration methods. We recommend using calibration method Ⅰ for calibration. The instrument is calibrated properly before delivery. Users may carry out recalibration if it is necessary. Calibration Method-1 Figure 1 Preparation before calibration: 3. - Page 10 5. Replace the 1000um foil on the iron substrate with 500um 5 0 0 foil. Then press the probe against the 500um standard foil perpendicularly and softly and stay for more than 5 seconds. Press “OK” key and the instrument enters 250um calibration 5 5 9 7 4 interface as shown in figure 4.
- Page 11 7. Replace the 250um foil on the iron substrate with 100um 0 0 0 foil. Then press the probe against the 100um standard foil perpendicularly and softly and stay for more than 5 seconds. Press “OK” key and the instrument enters 50um calibration interface as shown in figure 6.
-
Page 12: Measurement Method For Sand-Blasted Surface -1
Calibration for iron substrate: after entering the calibration Calibration Method-2 interface, select “1000” and press “OK” key. Then follow step Press ZERO CAL key → select “factory restore” → press OK 4 to 9 in “calibration method Ⅰ” to complete calibration of key →... -
Page 13: Communication
2. Carry out about 10 times of single measurements on the 1. After the software is downloaded, install USB driving program sand-blasted test specimen with coating to obtain average “CH341SER”. It can be used without the need to install “HT-128” value B. application software for the instrument. -
Page 14: Product Specification
Product specification Others LCD display with back light Performance Product weight: 80g (without battery) Measurement mode: single and continui Product size (length ×width ×height): 112mm × 51mm × 28mm Unit: um, mm，mil Accessories Range:0～1300um One piece of standard aluminum substrate Resolution: 1um (0～999um);... -
Page 15: Frequently Asked Questions
Product warranty bill Frequently asked questions (Kept by customer) Phenomenon Solution Reading appears when ★ The probe touches metal base at the measurement is not made time of power on self test. Power on or the reading has large again. Purchase date: (day,month,year) deviation.
