- Page 1 SHENZHEN XFT MEDICAL LIMITED WWW.XFT-CHINA.COM...
- Page 2 XFT-2003EA H2 Operation Instruction -- For the version without iPad WWW.XFT-CHINA.COM...
- Page 3 XFT-2003EA H2 Hand Rehab System Brief Introduction H2 Hand Rehab System is a wearable hand rehabilitation device with wristband integrated metal electrode. It adopts sEMG technology, can be used to improve the hand function and active range of motion in patients with hemiplegia due to stroke or upper limb paralysis.
- Page 4 XFT-2003EA H2 Hand Rehab System Treatment Principle...
- Page 5 XFT-2003EA H2 Hand Rehab System Parts Spray bottle User can fill water in this bottle to wet the skin when use the H2. ※ Please remember to remove the plastic film on the integrated metal electrode before you start to use the device.
- Page 6 XFT-2003EA H2 Hand Rehab System Operation Panel Power Button: press and hold the button to turn on/off the device. OLED Screen: user can check the treatment information such as the Mode on the screen. Play/Pause Button: press this button to start/pause the treatment.
- Page 7 XFT-2003EA H2 Hand Rehab System Structure ※ The device can’t be used when it is been charging.
- Page 8 XFT-2003EA H2 Hand Rehab System Indicators Introduction Battery status indicator. It will flash once per second when the battery is lower than 10%, and the stimulator will stop and auto off in 5 minutes. The stimulator will auto off in 5 seconds when the battery is lower than 2%.
- Page 9 XFT-2003EA H2 Hand Rehab System Modes Introduction H2 totally includes 5 modes: NMES, ETS, PAS, EMG and GAME mode. User can press the Mode Button to switch among different modes. ※ G A M E m o d e i s n o t...
- Page 10 XFT-2003EA H2 Hand Rehab System Modes Introduction Neuromuscular Electrical Stimulation Mode When use the H2 without iPad, only one prescription of NMES can be used. And only the intensity parameter can be adjusted. Operation Steps: Press the Mode button to choose the NMES mode;...
- Page 11 XFT-2003EA H2 Hand Rehab System Modes Introduction EMG Triggered Stimulation Mode The device will keep on detecting the EMG signal when the muscles are contracted. Once the EMG signal value exceed the threshold, the electrical stimulation will be triggered. The preset threshold is 10µv.
- Page 12 XFT-2003EA H2 Hand Rehab System Modes Introduction Power Assistant Stimulation Mode Operation Steps: Press the Mode button to choose the PAS mode; Press the Play/Pause button to start the treatment; Press the +/- button to increase / reduce the intensity (preset intensity).
- Page 13 XFT-2003EA H2 Hand Rehab System Modes Introduction EMG Signal Test Mode The device will test the EMG signal in 3 cycles of 3 seconds relax and 6 seconds flex, and then comes to the average value which will be set as the threshold in ETS mode.
-
Page 14: Game Mode
XFT-2003EA H2 Hand Rehab System Modes Introduction GAME Mode Note: GAME mode is not available if the device is not connected with APP on iPad. - Page 15 XFT-2003EA H2 Hand Rehab System Operation Steps Step 1: Wet the skin with water or conductive gel; Step 2：Wear the device to the arm; Step 3: Turn on the device, choose the mode, start treatment. Step 4: If the electrical stimulation is not comfortable, user can pause the...
- Page 16 Technology upgrades our life! If you have any question, please feel free to contact us Shenzhen XFT Medical Limited Address: #203 Building 1, Shenzhen Biomedicine Innovations Industrial Park, #14 Jinhui Road, Pingshan New District, Shenzhen, China Tel: 00 86-755-29888818 Fax: 00 86-755- 28312625 Email: xft@xft.cn...
