Page 1: Table Of Contents
DIGI FAN II OPERATING MANUAL Contents 1. Introduction 2. Specification 3. Installation 4. Operation 5. Safety Information 6. Maintenance 7. Wind Speed Test Report... -
Page 2: Introduction
1. Introduction The Digi Fan II (DF-502) is an upgraded version of the DF-500, designed for enhanced performance and versatility. It features advanced DMX512 control with user-friendly options, a wider power range, and improved airflow capacity. The fan housing is constructed from lightweight, durable plastic, ensuring easy transport and robust protection. -
Page 3: Installation
KCP-844 TV Coupler (28mm or 16mm stud) KCP-703 Stage Clamp 2. Standing on a Floor or Stand Use KUPO stands that support a minimum weight of 9.8kg. Recommended Stands: 310M Low Mighty Stand (Capacity: 35kg) 350 Runway Base Stand (Capacity: 70kg) Use KS-200 Adaptor (28mm/16mm) for mounting compatibility. -
Page 4: Safety Information
Press “Setting” button, slide the fader to select this mode, and press the button again to confirm Slide the fader to control the fan speed correspondingly. Press Turbo Button for immediate maximum fan output. For single or multiple units of remote control. Adjust fan speed by external XLR remote device for up to 20 meter distance through ordinary DMX cable Master &... - Page 5 Replacing the Fuse (if necessarily) 1. Disconnect power. 2. Remove the driver from the barrel, and unscrew the metal cover. 3. Replace the fuse (250V, 7A) with an identical rating. 4. Reattach and test power. 7. Wind Speed Test Report...
- Page 7 Contacting Information If you have any questions, you are welcome to contact us via the following methods: KUPO CO., LTD. Head Office - Taipei 6F, No.4, Lane 609, Sec.5, Chung Shin Rd., San Chung, Taipei, Taiwan TEL: +886-2-2999-1906 E-MAIL: stage@kupo.com.tw...
