- Page 3 EMS1000 PRO BOX EMS1000 PRO BOX-8 EMS1000 PRO BOX-16 Installation Manual Version 2.0 www.solaxpower.com eManual in the QR code or at http://kb.solaxpower.com/...
-
Page 5: Table Of Contents
Table of Contents Safety ........................1 Product Introduction ..................3 Scope of Delivery ....................4 Mechanical Installation ..................4 Electrical Connection ..................6 Pre-power Check ....................14 System Configuration ..................14 Webpage Login ....................16 Technical Data ....................16... -
Page 6: Safety
Safety General Notice 1. Contents may be periodically updated or revised. SolaX reserves the right to make improvements or changes in the product(s) and the program(s) described in this manual without the prior notice. 2. The installation and maintenance can only be performed by qualified personnel who: •... - Page 7 This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body. • Hereby, SolaX Power Network Technology (Zhejiang) Co. ,Ltd. declares that EMS1000 supports 2.4G WIFI, 2G, 3G and 4G functions. It is in conformity with the relevant union harmonization legislation: Radio Equipment Directive: 2014/53/EU.
-
Page 8: Product Introduction
Product Introduction EMS1000 PRO BOX includes an EMS1000 PRO device, an 8-port or 16-port switch, and an AC power adapter. It is suitable for use in large-scale industrial and commercial power stations for system data collection, energy control, and intelligent operations. -
Page 9: Scope Of Delivery
Scope of Delivery Wall bracket × 4 Expansion tube × 4 4G antenna stick × 1 EMS1000 PRO BOX × 1 ST4.8 self-tapping screw × 4 ST6.0 self-tapping screw × 4 Positing Cardboard × 1 Document Mechanical Installation Installation Site Requirements +50°C... - Page 10 Installation Tool Requirements Hammer drill Rubber mallet Marker Measuring tape (Drill bit:Ø10mm) Torque screwdriver (Flat-head: M2) Crimping tool for RJ45 Wire stripper Crimping tool for ferrules (Phillips head: M4) Anti-dust mask Safety gloves Safety boots Safety goggles Installation Procedure Aligning ST4.8 screws ST4.8 0.8 N·m...
-
Page 11: Electrical Connection
ST6.0 screws Expansion tube ST6.0 8 N·m Electrical Connection Port and Terminal Description Figure 5-1 Cable threading hole distribution Port No. Recommended distribution 1 & 2 Threading through cables for RS485 and NET connection 3 & 4 Threading through cables for switch and AI connection 5 &... - Page 12 Top view Left side view Bottom view Figure 5-2 EMS1000 PRO terminal Position Area Item QTY. Description • NET1: Connected to EMS1000 or sub EMS1000 PRO Ethernet terminal • NET2: Connected to upper EMS1000 PRO (NET) • NET3: Reserved DEBUG terminal •...
- Page 13 Position Area Item QTY. Description • 1-4: Reserved • 5: Only connected to the Running status (RUN) indicator of SolaX Parallel Cabinet • 6: Only connected to the ALARM indicator DO terminal of SolaX Parallel Cabinet • 7: Only connected to the GRID indicator of SolaX Parallel Cabinet •...
- Page 14 Cable Requirements RS485 cable AI/DO/DI cable Three-core shielded Two-core cooper copper cable cable CAT 5E network cable ferrule RJ45 connector (REC: 1.5mm (REC:1.5mm Preparing Cables Preparing network cable PIN No. Color PIN No. Color Orange-White Blue-White Orange Green Green-White Brown-White Blue Brown Preparing RS485 cables...
- Page 15 Preparing AI/DO/DI cables 8-10mm Ferrule AI/DI/DO wire Grounding/Com (Required only for flexible cables) Connecting cables RS485 Terminal Cable Connection Remove 0.4 N·m...
- Page 16 NET Cable Connection Remove AI Cable Connection Remove...
- Page 17 0.4 N·m DO Cable Connection Remove 0.4 N·m...
- Page 18 DI Cable Connection Remove 0.4 N·m 4G Antenna Installation...
-
Page 19: Pre-Power Check
SIM Card Installation Chip side down Pre-power Check Inspection Item Check whether EMS1000 PRO BOX is installed firmly. Check whether all terminal blocks are properly inserted. For 4G networking, check whether the SIM card is correctly inserted into to the Nano-SIM slot. - Page 20 Create a plant. Bind EMS100 PRO to the plant.
-
Page 21: Webpage Login
EMS login webpage. • IP address: 192.168.14.10 (wired connection); 192.168.10.10 (hotspot connection) • User account: Username: user; Password: 123456 Technical Data Model EMS1000 PRO BOX-8 EMS1000 PRO BOX-16 Power Supply 100 a.c V-240 a.c V 100 a.c V-240 a.c V Max. -
Page 22: Contact Information
