METER CAPACITIES
Model
Size
⅝" x ½"
625JL/JLR
⅝" x ¾"
6251JL/JLR
750JL/JLR
¾" x ¾"
1000JL/JLR
1" x 1"
150JLS/JLRS
1½"
THREADED
200JLS/JLRS
2"
THREADED
⅝" - 1" meter ends have straight threads, not tapered.
Note:
CARLON METER, INC. • PRODUCT WARRANTY
Carlon Meter, Inc.(hereinafter Carlon or "the company") warrants products of its manufacture to be free of
defects in material or workmanship. Liability under this warranty extends for twelve (12) months from the date
of purchase. Liability is limited to repair or replacement of any failed product or assembly proven to be
defective in material or workmanship upon manufacturer's examination. Removal and installation costs are
not included under this warranty. Manufacturer's liability shall never exceed selling price of the meter or
assembly in question. Carlon disclaims all liability for damage its products caused as the result of improper
installation, maintenance, use or attempts to operate products beyond their intended functionality,
intentionally or otherwise. Carlon is not responsible for damages, injuries or expenses incurred through the
use of its products. The above warranty is in lieu of all other warranties, either expressed or implied. No
agent of the company is authorized to alter or otherwise revise this warranty.
*For complete specifications, visit
Normal
Maximum
Flow
Flow
10 GPM
20 GPM
10 GPM
20 GPM
15 GPM
30 GPM
25 GPM
50 GPM
50 GPM
100 GPM
80 GPM
160 GPM
8/18
www.carlonmeter.com
Installation and
Operating Instructions
Model JL
& JLR
®
Series Water Meter
½"- 2" Sizes
Leaders in water measurement and control
1710 Eaton Drive
Grand Haven, MI 49417
Ph: (616) 842-0420
Fax: (616) 842-1265
E-mail:
carlon@carlonmeter.com
Website: www.carlonmeter.com
®
