Connecting the home hub inverter to multiple home batteries

Advertisement

Quick Links

Technical Note
Connecting the Home Hub
Inverter to Multiple Home
Batteries – North America
Version 1.1
March 2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCI-CB-01304-A and is the answer not in the manual?

Questions and answers

Summary of Contents for SolarEdge MCI-CB-01304-A

  • Page 1 Technical Note Connecting the Home Hub Inverter to Multiple Home Batteries – North America Version 1.1 March 2025...
  • Page 2: Table Of Contents

    Required Additional Equipment ....................4 Y-Connector Diagram and Component Specifications ............4 MCI-CB-01304-A ........................4 MCI-CB-01305-A ........................5 Sample Connection Scheme ....................6 Safety Symbols Information ...................... 7 Support Contact Information ....................8 © SolarEdge Technologies, Ltd 2025. All rights reserved.
  • Page 3: Version History

    Version 1.0, July 2023: Initial version Overview This document describes the connection of a SolarEdge Single Phase Home Hub Inverter to multiple SolarEdge Home Batteries using a special Y-type connector (“Y-connector”) cable. When more than one battery is connected, the Y-connector is required to create parallel connections to the inverter.
  • Page 4: Installation Rules

    • 10 AWG wiring • 8 AWG wiring • MC4 connectors for 10 AWG wiring, supplied in the SolarEdge Home Battery 400V package • Crimping tool for 10 AWG and 8 AWG MC4 connectors Y-Connector Diagram and Component Specifications MCI-CB-01304-A ©...
  • Page 5: Mci-Cb-01305-A

    • Upper limiting temperature: 221o ̊ F • Cable length: 5 inch PV cable 10 AWG • Rated voltage: 1000V • Upper limiting temperature: 221o ̊ F • Cable length: 9 inch MCI-CB-01305-A © SolarEdge Technologies, Ltd 2025. All rights reserved.
  • Page 6: Sample Connection Scheme

    A sample connection scheme with three batteries is illustrated in the figure below. Items supplied with the field kit are highlighted in green. For other items, the wire and connector gauges are specified. © SolarEdge Technologies, Ltd 2025. All rights reserved.
  • Page 7: Safety Symbols Information

    Do not proceed beyond a caution sign until the indicated conditions are fully understood and met. NOTE Denotes additional information about the current subject. © SolarEdge Technologies, Ltd 2025. All rights reserved.
  • Page 8: Support Contact Information

    • System configuration information, including the type and number of modules connected and the number and length of strings. • The method of communications with the SolarEdge server, if the site is connected. • The product's software version as it appears in the ID status screen.
