Module: CLUB100/CSD100
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLUB100 and is the answer not in the manual?

Questions and answers

Related Manuals for Carlsbro CLUB100

Summary of Contents for Carlsbro CLUB100

  • Page 1 Module: CLUB100/CSD100 OWNER’S MANUAL...

  • Page 3: Handling And Transport

    Congratulations! Thank you for purchasing this digital drum set. The drum set has been developed to act and play like a drum set but with greater ease. Before you use the instrument, we recommend you to read through this manual. Taking care of your digital drum set Handling and Transport Location...

  • Page 4: Module Function

    1. Module function Front panel LED display Displays the menu parameters. VOLUME Adjusts the headphone and main output volume. SETUP/SAVE Enters setting menu, to adjust parameters of VOICE/SONG/TEMPO. Press and hold to save user presets. PAGE Changes sub menu of VOICE/SONG/TEMPO. CLICK Turns on/off the metronome.
  • Page 5 Top panel Stereo headphone connector. INPUT External stereo input connection, e.g. MP3 or CD player. OUTPUT The stereo output connector to connect with audio system or drum amp, mono output. MIDI OUT Connects with external MIDI devices(The drum MIDI signal outputs via MIDI OUT to external audio source.) DC-IN Power adapter connector.
  • Page 6 Rear panel Trigger in connector D-SUB pad signal input connector. 2. Connect with external devices Connecting with audio system or drum amplifier Connect module OUTPUT socket to audio system or drum amplifier using 1/4” jack instrument cable. Note: The volume is controlled by the module volume knob and device volume knob.
  • Page 7 Connect with Headphones Connect headphones with 1/8” stereo connector, to the headphone socket on the module. The volume is controlled by the Volume knob on the module. Connect with MP3 or CD player Connect the output of your MP3 or CD player with the INPUT socket on the module. Volume of input can be adjusted via your MP3 or CD player.

  • Page 8: Power Supply

    Connect with PC Connect with PC Connect PC via MIDI port MIDI OUT: delivers pad signal to PC. Power supply 1). Turn off the module power switch. 2). Connect the power supply with DC IN connector. 3). Confirm all the pads are correctly connected. Set the module volume to minimum, then turn on the power switch of the module.
  • Page 9 5. Operation Adjust the master volume Strike the pads and adjust the volume knob for suitable master volume. Preset drum kit: KIT01---10 1. Power on to enter drum kit selection, the KIT LED lights up(the display shows drum kit number saved last time before power-off); 2.
  • Page 10 2. Adjust voice volume VOLUME (1) In voice mode, press [Page] button to enter the voice volume adjustment (the screen will show [L - -]) Press [+/-] button to adjust the voice volume of the pad you are playing (range 0-32) (2) This change will automatically save until the module is switched off.
  • Page 11 Saving adjustments When you are happy with your adjustments, press and hold the [SETUP] button. The screen will flash U01, you can now select which user preset you would like to save your new drum settings to. Use [+/-] buttons to select U01 or U02 and press the [SETUP] button again to save your adjustments.
  • Page 12 Song setting 1. Song selecting (1) Press [SET UP] button to enter into song menu, the SONG LED lights up. (2) Press [+/-] button to switch the song, range 001-010 (non-cycle); SONG LED lights up 2. Song playing (1) Press [START/STOP] button to play the selected song. During playing, change the song via [+/-] button.
  • Page 13 Percussion: the three LED shows DXX (XX refers to drum volume value); 2). Press [+/-] button to switch the accompaniment/volume (0-32, non-cycle). 4. Tempo 1). When playing DEMO SONG, press [SET UP] button to enter into Tempo setting, the TEMPO LED lights up; 2).
  • Page 14 (2) Click volume After [CLICK] is pressed down, press [PAGE] button, it shows “click volume” interface, the three LED shows LXX (XX refers to volume value), press [+/-] button to switch the click volume. CLICK LED lights up Record and replay Record quickly “REC”.

  • Page 15: Play Recording

    Play recording Press and hold the RECORD button, the RECORD LED lights up, press [START STOP] button to replay the recorded song, press [START/STOP] button again to stop the recorded song. Record LED lights on 4. MIDI setting This equipment is compatible with various MIDI devices and can be used as trigger device or audio source.

  • Page 16: Troubleshooting

    5.Trouble shooting Problem Reason No sound Please confirm the volume knob is not turned off Pad has no sound 1.confirm the pad connection is correct. 2.confirm the pad volume is not set to 0 Metronome has no sound Confirm the metronome volume is not set to 0 DEMO SONG has no sound Confirm the DEMO SONG volume is not set to 0 6.

  • Page 17: Drum Kit List

    7. DRUM KIT LIST 8. VOICE LIST ELE TOML SCRATCH PULL BASS DRUM...

  • Page 19: Gm Percussion List

    9.GM PERCUSSION LIST GM Percussion List Note No. Standard name Voice No. Voice Name 27－D#1 High Q High Q 28－ E1 Slap SLAP 29－F1 Scratch Push SCRATCH PUSH 30－F#1 Scratch Pull SCRATCH PULL 31－G1 Sticks STICKS 32－G#1 Square Click CLIP 33－A1 Metronome Click METRONOME CLICK...
  • Page 20 57－A3 Crash Cymbal 2 LTCRSH1 58－A#3 Vibraslap VSLP03 59－B3 Ride Cymbal 2 RIDE1 60－C4 Hi Bongo HIBNGO01 61－C#4 Low Bongo LOBNGO 62－D4 Mute Hi Conga MHCNGA 63－D#4 Open Hi Conga OHCNGA01 64－E4 Low Conga LOCNGA01 65－F4 High Timbale HTMBL1 66－F#4 Low Timbale L0TMBL1 67－G4...

  • Page 21: Demo Song List

    10.DEMO SONG LIST...
