Man & Machine Y Cool Operating Manual

Operating Manual
Y Cool Keyboard
Part functions:
EN
Keyboard Lock
1
Quick disconnect cable: keyboard cable can be removed from
2
the USB extension cable port to disconnect the keyboard.
Installation: No software required for installation. Quick
disconnect cable can be positioned in 3 directions (left, right,
back). (See figure B).
Optional extension cable included.
3
Turning ON Backlight Function: Press FN and the "B" Backlight
Key. Adjust the brightness by continuing to click the "B" Backlight
Key.
Turn OFF Backlight Function: Press FN and the "B" Backlight Key
to cycle the brightness until it is off.
Change Backlight Color: Press FN and the "C" Color Key to cycle
4
between the colors. The keyboard comes equipped with a 7-color
backlight.
Installation:
(See figure B)
Cleaning Instructions
Press the FN and F11 key simultaneously to lock the keyboard. The LED's blink
when the keyboard is in lock mode. Clean keyboard with approved cleaning
method and approved disinfectant or soap and water. After cleaning is done,
press FN key and F11 key simultaneously again to unlock the keyboard.
B
Y Cool (replacement) drapes are
available in two styles (profile or flat).
(See figure A)
2
4
3
Approved cleaning methods keyboard
• You can wipe the keyboard with a soft cloth that is non-abrasive like a
microfiber cloth, a disinfecting wipe, a soft brush similar to a paint brush in
bristle stiffness, or a sponge, but not a scourer of any sort.
• You can spray the keyboard with soap and water or an approved
disinfectant.
• You can rinse the keyboard with soap and water or an approved
disinfectant.
Approved cleaning methods drape
• You can wipe, spray or rinse the drape as described under "Approved
cleaning methods keyboard".
• You can immerse the drape in soap and water or an approved disinfectant.
• You can expose the drape to Hydrogen Peroxide Vapour (HPV).
• You can sterilize the drape in an autoclave or thermo disinfector (up to 134
ºC, tested 200 cycles).
Approved disinfectants
• Chlorine based, up to 100,000 ppm (10%) bleach content
• Alcohol based
• Glutaraldehyde based
• Phenol based
• Formaldehyde based, up to 370,000 ppm (37%) formaldehyde content
• Oxidizing, such as Hydrogen Peroxide, up to 30,000 (3%) ppm content
• Quaternary Ammonium, up to 20,000 ppm (2%) content.
Restrictions
!
• Only clean using the cleaning methods and disinfectants described under
1
1. Keyboard Lock
2. Quick Disconnect Cable
3. Backlight Key
4. Color Change Key
