40402 36" x 24" CABINET BLASTER
40403 36" x 24" CABINET BLASTER WITH FOOT PEDAL
INSTRUCTION AND ASSEMBLY MANUAL
PLEASE READ INSTRUCTIONS
COMPLETELY BEFORE STARTING
ANY ASSEMBLY
DIVISION OF S&H INDUSTRIES
5200 Richmond Road  Cleveland, OH 44146
Phone 216-831-0550  Toll Free 800-253-9726 
Fax 216-831-9573
www.shindustries.com
E-mail: www.service@shindustries.com
Rev. 2/2/17

Advertisement

loading
Need help?

Need help?

Do you have a question about the 40402 and is the answer not in the manual?

Questions and answers

Summary of Contents for ALC 40402

  • Page 1 40402 36” x 24” CABINET BLASTER 40403 36” x 24” CABINET BLASTER WITH FOOT PEDAL INSTRUCTION AND ASSEMBLY MANUAL PLEASE READ INSTRUCTIONS COMPLETELY BEFORE STARTING ANY ASSEMBLY DIVISION OF S&H INDUSTRIES 5200 Richmond Road  Cleveland, OH 44146 Phone 216-831-0550  Toll Free 800-253-9726 ...
  • Page 2 Page 2 WARNING! Do not use an ALC Cabinet Blaster until you have read this manual and you understand its contents and warnings. These warnings are included for the health and safety of the operator and those in the immediate vicinity. Keep this manual for future reference.
  • Page 3: Cabinet Operation

    40402 & 40403 Assembly Instructions Page 3 CABINET OPERATION Assemble light and siphon gun/foot pedal per instructions. Attach gloves to inner glove hole collar and secure with glove clamps included in parts kit. Remove dust collector hose from bottom of drum and connect one end to the dust collector and the other end to the right upper side of cabinet.
  • Page 4 40402 & 40403 Assembly Instructions Page 4 If twist-on type air hose couplings are used, they must be secured by safety lock pins or wires to prevent accidental disconnection while under pressure. Hose disconnection while under pressure could cause serious injury.
  • Page 5 40402 & 40403 Assembly Instructions Page 5 Do not use this equipment in any area that might be considered hazardous or where flammable gases or liquids are present. Failure to do so may cause an explosion resulting in serious injury.
  • Page 6: Maintenance

    40402 & 40403 Assembly Instructions Page 6 MAINTENANCE Check siphon gun nozzle and air jet for wear when replacing. Proper matching of nozzle and air jet is very important for effective blasting. Match size or color small/small (gold), medium/medium (silver) and large/large (black).
  • Page 7 40402 & 40403 Assembly Instructions Page 7 LIGHT ASSEMBLY INSTRUCTIONS Before assembly check to see that all components have been received with cabinet. Part Qty. Description Part Qty. Description 11007 Light fixture 11012 Power cord connector ¾’’ Sheet Metal Plug...
  • Page 8 40402 & 40403 Assembly Instructions Page 8 LIGHT ASSEMBLY INSTRUCTIONS Press metal plug into 3/4” diameter hole from inside of cabinet. (The purpose of the grommet is to prevent abrasion of the light wires.) Install electrical box to outside of cabinet using two 8-32 x 1/2”...
  • Page 9 40402 & 40403 Assembly Instructions Page 9 ASSEMBLY DIAGRAM FOR BLAST CABINET Below is the component breakdown for ALC Cabinet Blasters. Please see separate instructions and parts breakdowns for light assembly, siphon gun/foot pedal and dust collector. Item Part Description...
  • Page 10 40402 & 40403 Assembly Instructions Page 10 Use maximum 60 watt bulb (not included)
  • Page 11 40402 & 40403 Assembly Instructions Page 11 OPTIONAL SIPHON GUN/FOOT PEDAL ASSEMBLY INSTRUCTIONS Below is the component breakdown for siphon gun/foot pedal. Part No. Description Siphon gun pressure hose (6’) 11595 Foot pedal pressure hose (8’) 11596 11594 Foot pedal assembly...
  • Page 12 40402 & 40403 Assembly Instructions Page 12 must be kept open and clear of any debris for proper operation.
  • Page 13 40402 & 40403 Assembly Instructions Page 13...
  • Page 14 40402 & 40403 Assembly Instructions Page 14 SIPHON GUN PARTS BREAKDOWN Replacement Parts and Optional Accessories REPLACEMENT PARTS PART NO. DESCRIPTION 11665 Blast gun for foot pedal 40153 Blast gun for trigger operation 40137 Blast gun handle only, with trigger and valve...
  • Page 15 Page 15 ASSEMBLY DIAGRAM FOR DUST COLLECTOR Below is the component breakdown for ALC 100 CFM dust collector. The dust collector is assembled and ready for use. Dust collector hose is located in the bottom drum of the collector and must be removed and attached to dust collector and cabinet.
  • Page 16 40402 & 40403 Assembly Instructions Page 16 TROUBLESHOOTING TIPS PROBLEM/CAUSE POSSIBLE SOLUTION Surging of blast flow: Air pressure too low Check pressure gauge on air compressor Excessive media consumption: Air pressure too low Check pressure gauge on air compressor Clogging and plugging of blast flow:...
  • Page 17 40402 & 40403 Assembly Instructions Page 17 Coal Slag #40093 Coal Slag is used when paint and rust has to be removed from steel, such as car bodies, tanks or heavy machinery. Coal Slag is faster cutting, can be re-used, is moisture free, and will not pack or absorb moisture.
  • Page 18 40402 & 40403 Assembly Instructions Page 18 Disclaimer of Warranties. S & H Industries, Inc. ("Seller") makes no warranties with respect to any goods delivered to Buyer or users except as specifically set forth within this manual. S & H INDUSTRIES, INC.
