- Page 1 TSL.C061 channel hand dryer +"' +THE +"' SPLASH +"'...
- Page 2 Safety and Warnings Box Contents Technical Data Before You Install How to Install Commissioning Resetting the Sensor Operation Maintenance & Cleaning Troubleshooting Diagram Spare Parts / Accessories Warranty Back Cover Contact Details 2 + TSL.C061 CHANNEL HAND DRYER MANUAL...
- Page 3 The dryer must be installed in accordance with the electrical installation regulations in force at the time of installation. The hand dryer must be grounded. General information lnfo.uk@thesplashlab.com + 44 (0) 161 482 7000 Technical support lnfo.uk@thesplashlab.com For further contact information visit: www.thesplashlab.com TSL.C061 CHANNEL HAND DRYER MANUAL+ 3...
-
Page 4: Box Contents
Dryer head assembly Hand dryer motor unit Power cable Gasket Washer Fixing nut Angled pipe Motor mounting screws Hex wrench HEPA filter (Optional) 4 + TSL.C061 CHANNEL HAND DRYER MANUAL Air hose... -
Page 5: Technical Data
Thermal cutout fuse set to 142 Insulation Class 1 IP rating IP35 Approvals CE, UKCA, RoHS, UL, cUL Warranty One years limited warranty Filter 3M filter assembly (HEPA filter is available for this product, please enquire for technical information) TSL.C061 CHANNEL HAND DRYER MANUAL+ 5... -
Page 6: Before You Install
If the Channel Hand Dryer is installed with basin is used, please confirm with other units from the Channel range, the The Splash Lab that there will be no Channel Tap, which is at the center, should reflection or splash issue. - Page 7 before you install wall thickness 50mmMAX 10mm MIN 236.5mm /05Omm jlJJ & 028.6mm Sensor Range 120±20mm >< z<C - ::, ::, E g $2 1200mm Mains 270mm 306mm 148.5mm installation depth 170mm MIN TSL. C 061 CHANNEL HAND DRYER MANUAL+ 7...
-
Page 8: How To Install
Drill hole 30mm diameter in wall dryer body into the 30mm hole in wall. 200-250mm above the bottom of the basin. 8 + TSL.C061 CHANNEL HAND DRYER MANUAL... - Page 9 When step 3 is finished, run the sensor wire through the gasket, washer and and ground wire through angled pipe and fix fixing nut, and tighten the nut it to the fixing nut. against the installation wall. TSL.C061 CHANNEL HAND DRYER MANUAL + 9...
- Page 10 Fit the dryer motor unit to wall or cabinet, underside of dryer motor using the within 1200mm of the dryer nozzle already security hex key provided, and then installed in the wall. remove the cover. 10 + TSL.C061 CHANNEL HAND DRYER MANUAL...
- Page 11 Feed sensor cable through angled pipe knockout in the back or base of the dryer connector and fit flexible hose. and feed to connector block. Connect the cables as marked on the dryer unit. (Cable supplied pre-fitted) TSL.C061 CHANNEL HAND DRYER MANUAL+ 11...
- Page 12 Thread the sensor and ground cables Fasten pipe clip and tighten with through the air-hose. screwdriver. 12 + TSL.C061 CHANNEL HAND DRYER MANUAL...
- Page 13 Connect the sensor cable to the 6-pin then through cable exit grommet. fitting on the PCB control, and the ground cable to the corresponding earth Note: grommet is split to allow cable installation. connector in the dryer motor unit. TSL.C061 CHANNEL HAND DRYER MANUAL+ 13...
- Page 14 Connect air hose onto outlet nozzle on Re-fit the dryer cover and tighten the dryer motor and tighten hose clamp. fixing screws. 14 + TSL.C061 CHANNEL HAND DRYER MANUAL...
- Page 15 PCB with a small plastic or wood clockwise to increase the motor flat blade probe. speed; turn counter-clockwise 0 2-1 Slide the switch to 'ON': to reduce the motor speed. Enables heater 2-2 Slide the switch to '1': Disables heater TSL.C061 CHANNEL HAND DRYER MANUAL+ 15...
-
Page 16: Resetting The Sensor
3 seconds to complete setting up the the desired sensor range (min. 50mm / desired sensor range. max. 150mm) and keep your hand at the desired position for 3 seconds. *Remove reflective clothing during installation. 16 + TSL.C061 CHANNEL HAND DRYER MANUAL... -
Page 17: Operation
operation The user is to shake excess water off their hands. The user then places their hands within the detection range of the sensor to activate the hand dryer. The motor will start and air is blown onto the user's hands. The motor will stop when the user's hands are removed from the detection range. -
Page 18: Maintenance And Cleaning
Best care for PVD Finishes You can clean the PVD finished spouts with a damp cloth and water. Do not use cleaning solution or liquid alcohol. 18 + TSL.C061 CHANNEL HAND DRYER MANUAL... -
Page 19: Troubleshooting
troubleshooting initial installation If the dryer will not run: First ensure that the breaker supplying the dryer is operational. If it is, disconnect the power and remove the dryer cover. Taking suitable precautions to avoid shock hazard, reconnect the power and check for voltage at the terminal block. Verify that connections are made correctly. - Page 20 Remove the dryer cover. Remove any dust/lint buildup from intake vent slots. Check VR for speed setting. Disassemble the blower / motor / fan housing. Check motor brushes for wear; if less than 6mm is remaining. Replace motor. 20 + TSL.C061 CHANNEL HAND DRYER MANUAL...
- Page 21 diagram •- • • • • • • TSL.C061CHANNE L HAND DRYER MANUAL+ 21...
-
Page 22: Spare Parts And Accessories
Ueeer Stainless steel front cover plate If further information is required, Motor cover fixing screws contact The Splash Lab team (2 required) for more detailed guidelines. Hex wrench Motor case cable entry grommet 22 + TSL.C061 CHANNEL HAND DRYER MANUAL... -
Page 23: Warranty
One year limited warranty + If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning will void the warranty. - Page 24 contact General information lnfo.uk@thesplashlab.com +44 (0) 161 482 7000 Technical support I nfo.uk@thesplashlab.com For further contact information visit: www.thesplashlab.com...
