Summary of Contents for The Splash Lab TSL.R.030
- Page 1 TSL R 030 ribbon hand dryer...
- Page 2 Safety and Warnings Box Contents Technical Data BeforeYouInstall HowtoInstall Commissioning Operation Maintenance Cleaning Troubleshooting Diagram Spare Parts / Accessories Warranty BackCover ContactDetails 2 + TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 3 General information 310 410 5008 Showroom: 8745 Washington Boulevard, Studio D, Culver City CA 90232 Warehouse + Offices: 20809 Higgins Court, Torrance CA 90501 Technical support info@thesplashlabusa.com For further contact information visit: www.thesplashlabusa.com TSL.R.030 RIBBON HAND DRYER MANUAL + 3...
-
Page 4: Box Contents
Dryerheadassembly Hand dryer motor unit Power cable Anti-rotation collar (already installed) Gasket (already installed) Anti-rotation washer Fixing nut Motor mounting screws Hex wrench Air hose 4 + TSL.R.030 RIBBON HAND DRYER MANUAL... -
Page 5: Technical Data
Thermalcutoutfusesetto288°F Insulation Class1 IPrating IP35 Approvals CE UL cUL, RoHS, ADA Warranty 1 year parts and labor Filter 3M filter assembly (HEPA filter is available for this product, please enquire for technical information) TSL.R.030 RIBBON HAND DRYER MANUAL + 5... -
Page 6: Before You Install
220V8Amp circuitshouldonlyuse Basins upto4ofits8 amps. Use of a The Splash Lab Monolith basin Spacing isrecommendedforusewiththeRibbon rangeofproducts Ifanalternativebasin If the Ribbon Hand Dryer is installed with isused, then appropriatemountingpoints other units from the Ribbon range, the... - Page 7 3-15/16 - 5-1/8 " " (195.3mm) (100-130mm) Ø 1 3/8" (35mm) THROUGH HOLE Ø 1-1/4" (32mm) 2-23/32" (69mm) 110-120V / 15A plug 220-240V / 8A plug 10-3/4" (270mm) 12-1/16" (306mm) 5-7/8" (148.5mm) 51-3/16" (1300mm) TSL.R.030 RIBBON HAND DRYER MANUAL + 7...
-
Page 8: How To Install
Drill hole 1 3/8 " (35mm) diameter in Fit anti-rotation washer from below basin. counter-top, if not already cut. 8 + TSL.R.030 RIBBON HAND DRYER MANUAL... - Page 9 Fix fixing nut, and secure using wrench. Remove cover-fixing screws from underside of dryer motor using the security hex key provided, and then remove the cover. TSL.R.030 RIBBON HAND DRYER MANUAL + 9...
- Page 10 47-1/4 " (1200mm) of the dryer and feed to connector block. Connect nozzle already installed on the basin / the cables as marked on the dryer unit. countertop. (Cable supplied pre-fitted) 10 + TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 11 Thread the sensor and ground cables Feed cables into air outlet nozzle and through the air-hose. then through cable exit grommet. TSL.R.030 RIBBON HAND DRYER MANUAL + 11...
- Page 12 Connect the sensor cable to the 6-pin Connect air hose onto outlet nozzle on fitting on the PCB control, and the dryer motor and tighten hose clamp. ground cable to the corresponding earth connector in the dryer motor unit. 12 + TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 13 Re-fit the dryer cover and tighten the fixing screws. TSL.R.030 RIBBON HAND DRYER MANUAL + 13...
- Page 14 Turn to adjust the variable resistor. Turn clockwise to increase the motor clockwise to increase the sensitivity; speed; turn counter-clockwise turn counter--clockwise to reduce to reduce the motor speed. the range. 14 + TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 15 2. Adjust the heater switch on the PCB with a small plastic or wood flat blade probe. Slide the switch to ‘ON’: Enables heater 2-2 Slide the switch to ‘1’: Disables heater TSL.R.030 RIBBON HAND DRYER MANUAL + 15...
-
Page 16: Operation
Remove the cover by unscrewing the fixing screws on the underside of the cover. Remove any dust or foreign body from the air intake and (both inside and outside the dryer). Where necessary, use a brush or vacuum cleaner. 16 + TSL.R.030 RIBBON HAND DRYER MANUAL... - Page 17 If further information is required, contact The Splash Lab Team for more detailed stainless-steel care guidelines. TSL.R.030 RIBBON HAND DRYER MANUAL + 17...
-
Page 18: Troubleshooting
The dryer runs but air stream is low pressure and/or low velocity: Ensure that the supply voltage is correct. Dryer will run weakly if the input voltage is too low. Verify voltage requirement on unit rating label and correct supply as required. 18 + TSL.R.030 RIBBON HAND DRYER MANUAL... - Page 19 The heater gets hot but no air stream is produced: Disconnect the power. Remove the dryer cover. Check variable resistor for speed setting. Disassemble the blower- motor/ fan housing. Replace the fan motor. Reassemble. TSL.R.030 RIBBON HAND DRYER MANUAL + 19...
- Page 20 Check motor brushes for wear; if less than 1 1/4" is remaining. Replace brushes. We are always looking to improve. If these steps did not solve your problem please contact us and we will endeavor to help. Tel: 310 410 5008 Email: info@thesplashlabusa.com 20 + TSL.R.030 RIBBON HAND DRYER MANUAL...
- Page 21 TSL.R.030 RIBBON HAND DRYER MANUAL + 21...
-
Page 22: Spare Parts And Accessories
Upper If further information is required, Stainless steel front cover plate contact The Splash Lab team Motor cover fixing screws for more detailed guidelines. (2 required) Hex wrench Motor case cable entry grommet 22 + TSL.R.030 RIBBON HAND DRYER MANUAL... -
Page 23: Warranty
The Splash Lab will warrant that its products will be free of manufacturing and material defectsduringnormaluseandenvironmentalconditionsasdetailedbelow: RibbonCollection1yearparts&labor If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide areplacementpartorproduct, ormakeappropriateadjustments.Damagecausedby accident,misuse,orabuseisnotcoveredbythiswarranty.Impropercareandcleaning willvoidthewarranty. - Page 24 contact General information 310 410 5008 Showroom: 8745 Washington Boulevard, Studio D, Culver City CA 90232 Warehouse + Offices: 20809 Higgins Court, Torrance CA 90501 Technical support info@thesplashlabusa.com For further contact information visit: www.thesplashlabusa.com...
