Watts Industries tekmar 654 Quick Setup Manual

Snow Melting Control 654
1.
Location
Behind
Door
Exterior
Wall
3.
Install Mounting Base
Stud
Base
1
3 / "
4
(83 mm)
Gang
Box
5.
Wiring
Transformer 009
R
L
N
C
Relay 003
3 2
4 1
5 8
+ – T T
6 7
G
Modulating
Boiler 115 V (ac)
A Watts Water Technologies Company
Quick Setup Guide
Interior
Wall
5 feet
1.5 m
Base
Optional
tN4
Communication
C tN4
Relay 003
Aux Ht R
3 2
4 1
5 8
6 7
System
Pump
N L
2.
Remove Mounting Base
4.
Switch Settings
1058-01
ON
Stud
1 2
Back of
Wall
Control
No Power
C tN4 Mod Brn Yel Blu Red Blk Out/ Sup
– + Slab Com Bret
1 of 2
Snow Melting
LOCK ACCESS LEVEL
The control is locally locked and the access
level cannot be changed. Set to Lock when
installation has been completed.
UNLOCK ACCESS LEVEL
The control is unlocked and the access
level may be changed. Go to the Toolbox
menu to change the access level. Set to
Unlock during the installation process.
Snow / Ice Sensor Snow
090 or 094 Sensor 095
Or
Snow
Sensor
095
Brn Yel Blu Red Blk Brn Yel Blu Red
Slab Com Slab
Supply Outdoor
Sensor Sensor
082 070
© 2013
654_Q
05/13
Replaces: New
Slab Sensor
072 or 073
And/Or
Blk
Com
654_Q - 05/13
