Akai GX-65 Service Manual

STEREO CA SSETTE CECH GX-65
STEREO CASSETTE DECK
MODEL GX-65
SPECIFICATIONS
Track system 4 track 2 channel stereo Total harmonic distortion .
Heads Input(Level/Impedance)
Erase head x]
Recording head LC-OFC SGX x1 Output
Playback head LC-OFC SGX x1 (Level/Impedance)
Motors
Capstan drive Electronically controlled DC Headphone
motor X1 Power requirement
DC motor X1
0.06%(DIN), 0.035(WRMS)
Tape winding time 80 sec.(C-60 Tape)
Frequency response
Normal tape 15Hz to 19,000Hz +3dB
CrO2 tape 15Hz to 19,000Hz +3dB
Metal tape 15Hz to 21,000Hz +3dB
57dB(Metal tape)
Dolby B type NR switch ON: Im-
proves up to 5dB at 1kHz, 10dB
above SkHz
Dolby C type NR switch ON: Im- | Standard accesories
proves up to 15dB at 500Hz, Connection cord
20dB at 1kHz to 10kHz
0.7%
70mV/47kohms
388mV/2kohms
1.3mW/sohms
AC 220V, 50Hz for Europe ex-
cept UK
AC 240V, 50Hz for UK and Aus-
tralia
AC 110V-120V/220V-240V,
50Hz/60Hz convertible for
other countries
425(W)X137(H)X353(D) mm
(16.7X5.4X 13.9 inches)
5.5kg(12.1 Ibs)
