Description
The AKG Model D 3800 is a rugged dynamic
hypercardioid microphone intended for on-stage instrumental
and vocal pickup. Its hypercardioid pattern is uniform with
frequency, and response has been boosted at mid and high
frequencies for crisp instrumental pickup and improved
speech intelligibility. The microphone capsule is shock
mounted with an easily removable wire mesh grille. The
smooth triangular shape of the microphone is easier to hold
than normal circular cross-section designs and is stable
when the microphone is placed on a surface. The light-
weight body is die cast zinc alloy and has a dark matte finish
for minimum reflection and glare.
Specifications
Transducer type:
Dynamic pressure gradient
Frequency response:
40 - 21 kHz
Polar pattern:
Hypercardioid
Impedance:
600 ohms
Recommended load impedance: >2000 ohms
Output connector:
XLR-M
Sensitivity:
2.8 mV/Pa; -51 dB (re 1 V/Pa)
Sound pressure level for 1% (3%) THD:
147 dB SPL (156 dB SPL)
Environmental operation:
Temperature:
-10°C to +65°C
Maximum relative humidity at +20°C: 90%
Size:
Maximum diameter: 2.1 in. (53 mm)
7.4 in. length (187.5 mm)
Net weight:
9.7 oz. (275 g)
Shipping weight:
1.5 lbs. (675 g)
Accessories included: SA 41/1 stand adapter
Optional accessories:
W 23 foam windscreen
D 3800
Features
• Response tailored for instrumental
and vocal on-stage performance
• Accurate hypercardioid pattern for
added immunity to feedback
• High sensitivity (2.8 mV/Pa)
resulting from use of high-energy
neodymium-iron-boron magnet
• Light-weight die cast metal body
with dark matte finish
• Replaceable grille assembly
