SAFETY PRECAUTIONS
1. Make sure incoming pressure does not exceed
the rated pressure.
2. Use proper eye protection when assembling and
using the hose reel.
3. Assemble the hose reel on a clean workbench
free of debris and moisture.
4. Use soap and water when checking for air leaks.
5. Keep children away from work area.
WARNING!
Exposure of skin directly to
pressurized air or fluids could
result in severe bodily injury!
General Pump
1174 Northland Drive • Mendota Heights, MN 55120
Phone: 651.686.2199 • Fax: 800.535.1745
www.generalpump.com • email: sales@gpcompanies.com
Ref 300889 Rev. A
12 12
• direct hand-crank rewind
with locking mechanism
• solid steel construction
• durable powdercoat finish
• full flow brass swivel
• 100' Capacity for 3/8" Hose
• 125' Capacity for 1/4" Hose
• 5,000 PSI
• 1/4" NPT-F Inlet
• 3/8" NPT-F Outlet
operator's manual
Ref 300889 Rev. A
12 12
General Pump
is a member of
The Interpump Group
INDUSTRIAL
Hose
Reel
From General Pump
2100357 Hose Reel
Advertisement
Related Manuals for Interpump Group GENERAL PUMP 2100357
Summary of Contents for Interpump Group GENERAL PUMP 2100357
- Page 1 Ref 300889 Rev. A Ref 300889 Rev. A 12 12 12 12 General Pump General Pump 1174 Northland Drive • Mendota Heights, MN 55120 is a member of Phone: 651.686.2199 • Fax: 800.535.1745 The Interpump Group www.generalpump.com • email: sales@gpcompanies.com...
- Page 2 ASSEMBLY INSTRUCTIONS Clamp the hardware kit to the hose reel handle with the two M8 bolts. Secure it from rotating or slipping with the M6 bolt. Use thread sealant (not provided) and the supplied fittings/adapters as needed to connect an inlet hose (not provided) to the hardware kit inlet.3. Use thread sealant on the hose reel pigtail and connect to the hardware kit outlet.
