Summary of Contents for Waykar BL001C
- Page 1 Tent Air Conditioner Please read the manual carefully before using the unit BL001C USER MANUAL...
- Page 3 Please read the manual carefully to ensure proper use the conditioner . The tent air conditioner from waykar provide and efficient operation to adjust the temperature and bring you a healthy and comfortable life.
- Page 4 BEFORE FIRST USE: To prevent any internal damage, it is very important to keep refrigeration units (like this one) upright throughout their journey. Please leave it standing upright and outside the box for 24 HOURS before plugging it in.
- Page 5 TABLE OF CONTENTS PRECAUTIONS FOR USE ............1 PRODUCT DESCRIPTION............3 CONTROL PANEL ..............5 USAGE ....................6 ACCESSORY CONNECTION ..........7 USAGE ENVIRONMENT ............9 INSTALLATION INSTRUCTIONS ........10 TROUBLESHOOTING ............12 CLEANING AND MAINTENANCE........13 PACKING LIST................14 ENVIRONMENTAL CHECKLIST........15 SPECIFICATIONS ..............16 SPECIAL NOTES..............17 WARRANTY & CONTACT US ..........18...
- Page 6 PRECAUTIONS FOR USE PRECAUTIONS FOR USE This manual records the important safety items for the correct use and maintenance of the air conditioner to prevent personal injury or Property damage, please read the text on the basis of fully understanding the following content (logo, icon), and please be sure to abide by the recorded safety matters.
- Page 7 PRECAUTIONS FOR USE ● Use only the included accessories and parts and specified tools for installation. Using non-standard parts may cause water leakage, electric shock, fire disaster, injury or property damage. ● Make sure the outlet you are using is grounded and of the correct voltage. The supplied power cord has a three-prong grounded plug to prevent electric shock.
- Page 8 PRODUCT DESCRIPTION Product Description ● This product is equipped with a new 24v high-performance compressor, a new double-pipe exhaust system, and a classic handle design for easy movement. The Host Control Panel Cold Air Outlet Air Inlet Extension Tube Mounting Port Air Inlet Hot Air Outlet Air Conditioning...
- Page 9 PRODUCT DESCRIPTION Appendix Power Adapter Power Adapter Plug Duct Connector Heat Pipe Condenser Duct Connector Design and specification ● Design Notes: In order to ensure the best performance of the product, the design specifications of the device and the remote control are subject to change without prior notice; ●...
- Page 10 Control Panel Control Panel Power Button ● In the case of power on, short press to power on when using the control panel to operate, and the power indicator light is always on. Long press for 3 seconds to power off...
- Page 11 USAGE Usage It can work with the original factory equipped power adapter. Adapter specifications for this device:Input voltage: AC100-240 V~50-60 Hz, voltage: DC24V, Power: 240W Powered by adapter: 24V Power Adapter Home AC Power → → Air conditioner Household AC Power adapter power connector 100-240 V (50-60 Hz )
- Page 12 ACCESSORY CONNECTION Accessory Connection 1. Connect The Drain ● Fitting connection to connect the drain. ● The device, like a conventional air conditioner, turns gaseous water in the air into a liquid, and it uses gravity to collect and expel the resulting water. Its interior can store the condensed water for about 1-2 hours, depending on the air humidity.
- Page 13 ACCESSORY CONNECTION ● Note that it should be kept level during use. It's better to tilt it back 5-10 degrees, don't tilt it forward or side to side, Otherwise condensate will leak out from the front and bottom of the air conditioning unit. ●...
- Page 14 USAGE ENVIRONMENT Usage environment Your installation location should meet the following requirements: ● Make sure to mount the unit on a flat surface to minimize noise and vibration. ● The distance between the air outlet of the machine and the wall or obstruction >12in, and the distance between the exhaust port and the wall or obstruction >...
- Page 15 INSTALLATION INSTRUCTIONS Tent placement Conventional Tent/Tent With Air Conditioning Vent Suggestion: ● Pay attention to the tent insulation, if the tent is poor in insulation, please cover the tent with an insulated mat. ● Pay attention to airtight, vented tents, be careful to close or cover the vents. ●...
- Page 16 INSTALLATION INSTRUCTIONS Connecting windows Artwork cutter to cut tape Connecting windows Artwork cutter Cloth-based adhesive tape ● You can use a piece of pearl cotton suitable for the size of the window, cut out two 3.15in diameter round holes with a cutter, the two holes are about 4.72in apart, adjust the appropriate angle to the window.
- Page 17 TROUBLESHOOTING Cooling air Extension Tube Installation Instructions ● This accessory can be used in some narrow space where it is not convenient to place the equipment, such as the cab, etc., you can use this accessory to send cold air to the specified position.
- Page 18 CLEANING AND MAINTENANCE Cleaning and Maintenance ● Before cleaning and maintenance, you must first stop and cut off the power supply. ● Do not use flammable liquids or chemicals to clean the device, and under no circumstances are allowed to wash the device with water, otherwise it may cause electric shock gas hazard.
- Page 19 PACKING LIST Packing List Quantity Serial number Picture Name Air Conditioner 24V 240W Adapter 39.4in Drain Pipe Extension Tube Cold Air Extension Tube Connector Duct Connector - 14 -...
- Page 20 ENVIRONMENTAL CHECKLIST Environmental Checklist Harmful Substance Part Name Hexavalent Polybrominated Mercury PBBs Cadmium Lead ( Pb ) Chromium Diphenyl Ethers ( Cd ) ( Hg ) (PBBS) (Cr+6) (PBDE) Compressor and × × Accessories Pipe Fittings and × Valves × Motor Power Cord / Connection Cord...
- Page 21 SPECIFICATIONS Specifications BL001C MODEL DC 24V POWER 240W COOLING RATED POWER (W) 1.1A COOLING RATED CURRENT (A) COOLING RATED CURRENT (A) ADAPTER 1.5A COOLING CURRENT COOLING CAPACITY 1450 BTU DEHUMIDIFICATION CAPACITY 1.7L/Day REFRIGERANT R134a/140g WARNING This product can expose you to chemicals including Styrene and its compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm.
- Page 22 SPECIAL NOTES Do not insert any thin rods or When using the machine, please When using the machine, hard items into the machine to please do not put it on a soft keep it away from any heating prevent malfunctions and or uneven ground to prevent furnaces, electric kettles and dangers.
- Page 23 - 18 -...
- Page 25 We are expecting to see our products fulfill your life and hear your voice. Your satisfaction means a lot to us. Please tag us if you share a snap on your social media.
