RS PRO - VMX-Synergy Plus
Quick Start Guide
200-600VAC, 17-850 Amps
Removable 3.5" Colour Touch Screen rated IP66/N4X
45 Smart Application Profiles - Easy set up in 1 minute
Auto Pedestal to control spinning motors
Built in iERS - intelligent Energy Recovery System
Life Time Event Logging Diagnostics
Metering for Power, Voltage and Current
Internally Bypassed
1
M-RS-025-EN-V01.01 March 2025
Advertisement
Table of Contents
Related Manuals for RS PRO VMX Synergy Plus
Summary of Contents for RS PRO VMX Synergy Plus
- Page 1 RS PRO - VMX-Synergy Plus Quick Start Guide 200-600VAC, 17-850 Amps Removable 3.5” Colour Touch Screen rated IP66/N4X 45 Smart Application Profiles - Easy set up in 1 minute Auto Pedestal to control spinning motors Built in iERS - intelligent Energy Recovery System...
- Page 2 RS PRO VMX Synergy Plus Quick Start Guide RS Components Ltd Birchington Road, Corby, NN17 9RS, United Kingdom...
- Page 3 équipement. Short Circuit RS PRO soft-starters are not short circuit proof. After severe overload or short circuit, the operation of the soft-starter should be fully tested by an authorised service agent.
- Page 4 Safety • RS PRO soft-starters contain dangerous voltages when connected to the mains supply. Only qualified personnel that have been completely trained and authorised, should carry out installation, operation and maintenance of this equipment. • Les démarreurs progressifs RS PRO contiennent des tensions dangereuses, lorsqu’ils sont connectés à...
-
Page 5: Model Number Description
Model number description It is essential to check the RS PRO VMX-Synergy Plus and the AC motor nameplate and ensure the soft-starter is properly sized for your AC motor. Main Supply Frame Size Rated kW Rating @ 400VAC Control Supply RS PRO Stock Number (Iₑ) -
Page 6: Key Features
Key Features... -
Page 7: Weights And Dimensions
Weights and dimensions 206-123 (17A) to 206-134 (100A) (Frame Size 1) Weight = 4.2Kg (9.26lbs) 206-136 (132A) to 206-139 (195A) (Frame Size 2) Weight = 7Kg (15.44lbs) - Page 8 Weights and Dimensions 206-140 (242A) to 206-143 (361A) (Frame Size 3A) Weight = 17Kg (37.5lbs) 206-145 (430A) to 206-149 (500A) (Frame Size 3B) Weight = 22Kg (48.5lbs)
- Page 9 Weights and Dimensions 206-151 (625A) to 206-158 (850A) (Frame Size 4) Weight = 54Kg (119lbs)
-
Page 10: Enclosure Ventilation
Enclosure Ventilation When installing an RS PRO VMX-Synergy Plus into an enclosure, ventilation must be provided if the heat output of the unit is greater than the cabinet will dissipate. Use the following formula to determine the fan requirement. An allowance has been incorporated into the formula so that the figure for Q is the air delivery in the fan supplier’s data. - Page 11 Table 2 Temperature and altitude 206-123 (17A) to 206-149 (500A) -20°C (-4°F) to 50°C (122°F). Above 50°C (122°F) de-rate linearly by 4% of RS PRO VMX-Synergy Plus I per °C to a maximum of 60°C (140°F). 206-151 (625A) to 206-158 (850A) -20°C (-4°F) to 40°C (122°F).
- Page 12 Conductor sizes and torques Models Conductor Size Torque Terminal RS PRO VMX-Synergy Plus … Metric Imperial Ib-in Main Terminals Terminal 206-123 (17A) 206-134 (100A) 2.5 - 70mm 12- 2/0AWG Cu STR 75 C only 206-136 (132A) 206-139 (195A) 4 - 185mm 12 –...
-
Page 13: Terminal Designations
Terminal designations on 206-123 (17A) to 206-143 (361A) models only 0VDC, 24VDC input terminals... -
Page 14: Terminal Descriptions
être appliquée qu’à une entrée d’alimentation. Refer to RS PRO VMX-Synergy Plus User Manual for factory default settings. Référer au la Manuel de Programmation pour des paramètres par défaut d’usine... - Page 15 Control supply and control circuit (Us and Uc) Power Model No (s) (+10% -15%) (+10% -15%) Notes consumption 110-230VAC 206-123 (17A) to 60VA The system can have 206-143 (361A) either a 110/230VAC 24VDC (#1) mains or 24VDC input 110VAC or 230VAC or NOT both.
-
Page 16: Wiring Connection
Information/standards or there is a risk of section of this guide. damaging thyristors due to current peaks. RS PRO VMX-Synergy RS PRO VMX-Synergy Pour les dimensions de Plus Iₑ = Iₑ (moteur)/ √3 Plus Iₑ = Iₑ (motor) / √3 Condensateurs de câble et les besoins en... - Page 17 Wiring connection 3 Wire Control Diagram 3 Wire Control Diagram 110/230VAC control supply (U ) and digital input (U ) programming 24VDC control supply (U ) and digital input (U ) programming (only applicable to 206-123 (17A) to 203-143 (361A)) CAUTION Refer to TABLE 5 page 13 for input control voltages.
- Page 18 Programming...
-
Page 19: Rating Table
Rating table ¹ Type RS PRO VMX-Synergy 230V 400V 500V 200V 208V 220-240V 440-480V 550-600V Plus.. ( 206-123 (17A) 206-124 (22A) 206-125 (29A) 206-127 (35A) 18.5 206-128 (41A) 206-130 (55A) 24VDC, 206-131 (66A) 18.5 110VAC 206-133 (80A) 206-134 (100A) 230VAC... -
Page 20: Sizing Guide
Sizing guide In-Line Connection Use tables to determine the size of the RS PRO VMX-Synergy Plus required for the motor selected. Trip Class 10 Trip Class 20 Trip Class 30 : AC-53a: : AC-53a: : AC-53a: 3.5-17: 90-S 4-19: 90-S... - Page 21 Maximum motor line current indicated. For In-Delta connections, all six motor wires must be available for connection, and it is critical to exactly follow the In-Delta wiring diagram in the RS PRO VMX-Synergy Plus Quick Start Guide. The soft-starter will only sense the Phase Current, which is about 57.7% of the motor line current.
-
Page 22: Overload Trip Curves
Overload trip curves Note - When the overload has tripped, there is an enforced cooling time to allow the overload to recover before the next start. The ‘warm’ trip times are 50% of the ‘cold’ trip time. -
Page 23: Technical Information And Standards
Technical information and standards Product standard EN 60947-4-2:2012 Rated operational voltages 200VAC to 600VAC Rated operational currents See Rating Table Rating index See Sizing Guide Rated frequency/frequencies 50 - 60Hz ± 5Hz Rated duty Uninterrupted Form designation Form 1, Internally Bypassed Rated insulation voltage 600V Rated impulse withstand voltage... -
Page 24: Short Circuit Protection
1000 1200 rating Z fuse . Correctly selected semiconductor fuses provide additional protection against damage to the UL Listed inverse- RS PRO VMX-Synergy Plus unit. These Maximum time delay circuit 1000 1200 1200 semiconductor fuses are recommended to provide rating Z breaker this increased protection. - Page 25 RS PRO aim to ensure that any battery used within their products is readily removable and replaceable by the end user. Instructions are available on the RS PRO website. RS PRO reserves the right to make changes or updates with respect to or in the content of this document or the format thereof, at any time without notice.
- Page 26 Notes...
- Page 27 Notes...
- Page 28 RS PRO VMX-Synergy Plus Quick Start Guide www.RS-online.com M-RS-025-V01.01...
