- Page 1 RS PRO VMX-PFE Quick Start Guide 200-480VAC 5-40 Amps DIN Rail Mounted Internally Bypassed Over-current Protected M-RS-001-V01.01 March 2025...
- Page 2 RS PRO VMX-PFE Quick Start Guide RS Components Ltd Birchington Road, Corby, NN17 9RS United Kingdom...
- Page 3 Important information Installers should read and understand the instructions in this guide prior to installing, operating and maintaining the soft- starter. The following symbols may appear in this guide or on the soft-starter to warn of potential hazards or to draw attention to certain information.
-
Page 4: Model Number Description
Model number description It is essential to check the RS PRO VMX-PFE and AC motor nameplate and ensure the soft-starter is properly sized for your AC motor. RS PRO Stock Number Frame Size kW rating @ 400VAC Main supply voltage Control supply U (Iₑ) - Page 5 Dimensions Size 1 206-080 (5A) to 206-086 (16A) Size 2 206-088 (22A) to 206-092 (41A)
- Page 6 UL Requirement: Short circuit rating 5000A, 480VAC when protected by fuses or circuit breakers, rated as indicated in table below: Model Class J or T Fuse Circuit Breaker RS PRO VMX-PFE Rated 600VAC Rated 600VAC 206-080 (5A) 206-082 (7A) 206-083 (9A)
-
Page 7: Single-Phase Connection
Single-phase connection Introduction: The RS PRO VMX-PFE soft-starter controller may be utilised to accomplish motor starting using the reduced voltage method for single-phase applications (Non UL). Soft-starter sizing is determined by the kW rating of the motor. The soft- starter controller selection process for single-phase control is identical to three-phase for standard and heavy duty applications. - Page 8 Wiring connection (continued) Conductor sizes and torques Conductor Conductor Size Torque Strip Length Terminal Models mm² Lb-in 206-080 (5A) to 206-086 (16A) 18-12 Main terminal 206-088 (22A) to 206-092 (41A) 2.5-10 12-8 Cu only Control Terminals All models 0.5-2.5 20-14 Cu only Where several conductors are to be connected, the difference between the wires/cables used must not exceed one DIN standard size level.
-
Page 9: Technical Information
Technical information Product standard IEC/EN 60947-4-2 Rated Operational Voltage (Ue) 200-480VAC (3-Phase) Rated Insulation Voltage (Ui) 500V Rated Frequency 50-60Hz ± 5Hz Over-current ≥ 3 x I for 5 seconds Index Rating (See rating table for I Form Designation Form 1, Internally Bypassed Rated Impulse Withstand Voltage 2.5kV (Uimp) - Page 10 Technical information (standards) EMC Emission and Immunity Levels ESD immunity 4kV Contact 8kV Air Discharge IEC 61000-4-2 RF immunity 140dBuv over 0.15-80MHz IEC 61000-4-6 RF immunity 10V/m over 80-1000MHz IEC 61000-4-3 Fast transient immunity 2kV/5kHz IEC 61000-4-4 Surge immunity 2kV line to ground IEC 61000-4-5 1kV line to line Conducted RF emissions...
- Page 11 Fault / operating conditions Fault / Operation LED Colour Status Not Enabled Red and Green Stable - No flash Initialising Red and Green Slow flash Running Green Ready for Operation Green Slow flash ‘’Enabled’’ Starting Green Quick flash Full Volts Green Stable Stopping...
-
Page 12: Common Applications
Common applications Conveyor Pump... -
Page 13: Operation Parameters
Operation parameters... -
Page 14: Rating Table
Rating table Type RS PRO VMX-PFE.. 230V 400V 200V 208V 220 - 240V 440 - 480V 206-080 (5A) 206-082 (7A) 206-083 (9A) 206-085 (12A) 206-086 (16A) 24VDC 206-088 (22A) 206-089 (30A) 206-091 (36A) 18.5 206-092 (41A) Notes: Rated operational powers in kW as per IEC 60072-1 (primary series) corresponding to IEC current rating. - Page 15 To assist with assessing your Environmental impact, International Recycling codes are printed/stamped on unit boxes, to cover all enclosed packing materials. RS PRO reserves the right to make changes or updates with respect to or in the content of this document or the format thereof, at any time without notice.
