Summary of Contents for Totem Compass

  • Page 1 The Friend-Finding Compass USER MANUAL...
  • Page 2 Totem is dedicated to making live events safer, more immersive, and more beautiful. Please read this manual before using your Totem Compass, and keep it for future reference. Scan the QR code on the back of your Totem Compass to register your device and update your software.
  • Page 3: This Package Contains

    This Package Contains: One (1) Totem Compass Two (2) elastic Lanyards One (1) USB-C Cable...
  • Page 4: Table Of Contents

    Your Totem Compass Touch Crystal & Halo Buttons & Ports Vibe Mode Compass Mode Get Started 10-19 Power On & Off 10-11 Your Totem on Power Up 12-13 Establish Satellite Connection 14-15 Bond your Totems 16-17 Navigate 18-19 Additional Features...
  • Page 5 Content Table of Additional Features (cont.) 20-31 Brightness Settings 26-27 Touch Crystal Colors 28-29 Software Updates Support & Troubleshooting Care & Maintenance 32-33 Conditions for Use Battery Life & Range Performance Variables 36-37 Technical Specifications 38-39 Warranty Information Return Policy...
  • Page 6: Your Totem Compass

    Totem Compass Touch Crystal & Halo Touch Crystal Functions: • Add Bonds (press + hold) • Remove Bonds (triple-tap) • Change Colors (single-tap) Halo Displays: • Vibe Mode (vertical orientation) • Bond Lights (horizontal orientation) • Searching for Satellite...
  • Page 7: Buttons & Ports

    Totem Compass Buttons & Ports Power Button Functions: SOS Button • Power On Functions: (single-click) • SOS Alerts • Power Off (press + hold) (press + hold) • Software • Adjust Updates Brightness (triple-click) (single-click) USB-C Port Functions: • Charging...
  • Page 8: Vibe Mode

    Totem Compass Vibe Mode (vertical orientation) Available Features: • Vibe • Send SOS Alerts • Receive SOS Alerts • Adjust Brightness...
  • Page 9: Compass Mode

    Totem Compass Compass Mode (horizontal orientation) Available Features: • Bonding • Navigation • Send SOS Alerts • Receive SOS Alerts • Bond Removal • Adjust Brightness • Change Crystal Color...
  • Page 10: Get Started

    get started 1) Power On & Off To Power On: Click Power Button once To Power Off: Press and hold Power Button while device is powered on...
  • Page 11 get started Power On Power Off...
  • Page 12: Your Totem On Power Up

    2) Your Totem on Power Up When your Totem powers on, the Halo displays a Battery Level Indicator: • Full Green Halo = 100% • Yellow Half-Filled Halo = 50% • Yellow Quarter-Filled Halo = 25% • Red, Flashing Touch Crystal = Low Battery...
  • Page 13 get started 100% Charged 50% Charged 25% Charged Low Battery...
  • Page 14: Establish Satellite Connection

    2. Step away from roofs, walls, and other large structures 3. Wait 10-15 minutes for your Totem to establish Satellite Connection* *Enable Eco Mode to speed up satellite connection process...
  • Page 15 get started searching for satellite connection satellite connection nearby satellite connection successful satellite connection successful with Bond established...
  • Page 16: Bond Your Totems

    When Bonding is successful: The blue light on your Totem’s Halo will change to the color of your new Bond. The Halo will collapse into a single LED Note: Your Totem Compass will always remember Bonds unless you remove them...
  • Page 17 get started How to Bond Bonding Success Already Bonded Max. Bonds Reached...
  • Page 18: Navigate

    5) Navigate Establish Satellite Connection (see page X) Move 20 meters away from Bonded peer Hold Totem in Compass Mode and spin in a circle once to calibrate Follow the direction of Bond Light on Halo As you move toward Bonded peer, Bond...
  • Page 19 get started Bonded peer is >100 meters away Bonded peer is 50-20 meters away Bonded peer is <10 meters away Note: If you or a Bonded peer are out of peer-to-peer range, your Bond Light will begin to “breathe”, indicating stale location data...
  • Page 20: Additional Features

    When Bonded peer receives SOS Alert: Their Touch Crystal will blink “SOS” in morse code; Bond Light will blink rapidly when Totem is in Compass Mode To disable SOS Alert: Press and hold SOS Button until red light stops blinking...
  • Page 21 additional features Send SOS Disable SOS Receive SOS...
  • Page 22: Bond Lights & Colors

    additional features Bond Lights & Colors Bond Light colors are automatically assigned to peers based on Bonding order: • First Bond = pink • Second Bond: green • Third Bond = blue • Fourth Bond = yellow To check colors of Bonded peers: Move Totems together Touch Crystal will display color of Bonded peer...
  • Page 23 additional features second Bond third Bond first Bond fourth Bond Bonded Peer Check...
  • Page 24: Remove Bonds

    Remove Bonds Triple-tap Touch Crystal while Totem is in Compass Mode 2. Single-tap Touch Crystal to cycle between Bonded peers 3. Press and hold Touch Crystal to remove selected Bond Note: Bonded peers that you remove will no longer be able...
  • Page 25 additional features...
  • Page 26: Brightness Settings

    Brightness Settings Your Totem has 3 brightness settings that impact battery life: Day Vibe (10+ hours) Night Vibe (14+ hours) Eco Mode (24+ hours) To toggle between brightness settings, click the Power Button once while your Totem is powered on.
  • Page 27 additional features Eco Mode Day Vibe Night Vibe 24+ hours 10+ hours 14+ hours...
  • Page 28: Touch Crystal Colors

    Touch Crystal colors are for aesthetic purposes only and do not correlate to Bond Light colors. To change your Touch Crystal color: Enter Compass Mode Single-tap Touch Crystal to change color Continue tapping Touch Crystal to cycle through twelve different colors...
  • Page 29 additional features Available Crystal Colors Blue Indigo Magenta Hot Pink Orange Yellow Yellow-Green Green Blue-Green Teal White Aqua...
  • Page 30: Software Updates

    Software Updates Totem releases periodic, free Software Updates downloadable straight to your device. Remember to update your Totem Compass before you leave for any outdoor event. scan to download software update...
  • Page 31: Support & Troubleshooting

    Support & Troubleshooting If you encounter an issue with your Totem Compass, ensure you have updated your device to the latest software version. For all Totem Compass Resources & Support, scan the QR code below: scan for resources...
  • Page 32: Care & Maintenance

    • Avoid placing the device in pockets or bags with sharp objects. Water Resistance • The Totem Compass can withstand light rain and splashes but should not be submerged in water. • Dry immediately if exposed to moisture. Charging •...
  • Page 33 Cleaning • Fingerprints and smudges may appear on the surface. Use a soft, dry microfiber cloth to gently wipe the device. • For deeper cleaning, use a slightly damp cloth with water or mild soap. Avoid harsh chemicals or abrasive materials. Environmental Care •...
  • Page 34: Conditions For Use

    Conditions for Use • Use the device outdoors in open areas with a clear view of the horizon to maintain a reliable Satellite Connection. • Keep the device at least one foot away from smart phones, iron-based objects or heavy metal structures, as these can interfere with accuracy and satellite connection.
  • Page 35: Battery Life & Range

    Battery Life & Range Maximum Battery Playtime*: • Day Vibe: ~10 hours • Night Vibe: ~14 hours • Eco Mode: 24+ hours Charging Time: • Charges in ~45 minutes via standard USB-C • Charging Light turns green on full charge Range: Peer-to-peer range is ~1 kilometer, but Unity Mesh Network™ extends that range for all Totems in the...
  • Page 36: Performance Variables

    Performance Variables The Totem Compass leverages Global Navigation Satellite Systems (GNSS) to provide accurate positioning and navigation. However, several factors can influence its performance: Environmental Obstructions: Physical obstructions such as dense foliage, tall buildings, or mountainous terrain can cause signal reflection or blockage, leading to multipath errors and decreased positional accuracy.
  • Page 37 Solar Activity: Elevated solar activity can induce scintillation events in the ionosphere, degrading the quality of satellite signals. In standard GNSS receivers, mild scintillation can reduce position accuracy by several meters, while severe scintillation can cause signal loss. Weather Conditions: Adverse weather can have minor effects on the strength and quality of GNSS signals, potentially impacting the device’s performance.
  • Page 38: Technical Specifications

    Technical Specifications Model: Totem Compass Gen 1 Power Adapter Charging Voltage: 5V Max Charging Current: 1A Battery Type: LiPo ion Battery Capacity: 1000 mAh Wireless Frequency/Protocol: 2.4GHz Charging Port: USB type C Operating Temperature: -10°-60°C / 14°-140°F Housing Material: MABS Size: 58x58x24 mm/ 2.28x2.28x0.95 in...
  • Page 39 Safety Features: Over-voltage and under-voltage protection to ensure safe operation within the specified voltage range. • Thermal shutdown prevents the device from overheating during high-stress conditions • Designed with safeguards to prevent damage from short circuits Lanyard Material: 100% polyester braided around a core of 10 natural latex threads Lanyard Relaxed Size: 360 x 2.5 mm Lanyard Stretched Size: 620 x 2.5 mm...
  • Page 40: Warranty Information

    Warranty Information Your limited warranty starts on the date of your purchase and lasts for ninety (90) days. The Warranty Period is not extended if we repair or replace a warranted product. We may change the availability of this limited warranty at our discretion, but any changes will not be retroactive.
  • Page 41: Return Policy

    Return Policy Except for any products designated on the Website as non-returnable, we will accept a return of undamaged products for a refund of your purchase price, less the original shipping and handling costs, provided such return is made within fourteen (14) days of delivery and provided such products are returned in their original condition and packaging.
  • Page 42 This package contains recyclable materials. Please dispose of it responsibly by recycling where facilities exist.
  • Page 43 ©Totem, Inc. All Rights Reserved. Designed in Tennessee Made in China...
  • Page 44 FCC ID: 2BMQS-ESP32WROOM32E...
