DP VIDEO DZP905 User Manual

Touch screen 7 tft lcd usb/sd dvd player in-dash mobile video system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
7 Fully Motorized Wide Touch screen DVD Receiver
DP Video
DP Video
SRC
IR
PWR
TOUCH SCREEN
7 TFT LCD
In-Dash Mobile Video System
User Manual
DZP905
DZP905
DZP905
CLOCK
STOP
SRC
RESET
EJECT
AUX IN
PWR
BAND
DVD
MUTE
USB/SD
DVD PLAYER
ST
ADJ
RPT
Adjust angle
EJECT
AUX IN
IR
MUTE
BAND
DVD
MADE IN CHINA
Designed in the USA
DP Video
DP Video
RESET

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DZP905 and is the answer not in the manual?

Questions and answers

Related Manuals for DP VIDEO DZP905

Summary of Contents for DP VIDEO DZP905

  • Page 1 All manuals and user guides at all-guides.com User Manual DZP905 DZP905 7 Fully Motorized Wide Touch screen DVD Receiver DZP905 DP Video DP Video CLOCK DP Video DP Video STOP Adjust angle RESET RESET EJECT AUX IN EJECT AUX IN...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com Contents Warning and Precautions.........2 Radio Operation...........12 Band Electric Connection..........4 Band tuner Receiption collection AS/PS Speaker collection Sound Operation..........14 Installation..............5 Install the unit SD/USB...............15 Remove the unit Operation ............16 General Features.............6 Remote Control............7 Accessories............17 Loading and Replacing the battery Basic operation Troubleshooting...........18...

  • Page 3: Warning And Precautions

    All manuals and user guides at all-guides.com Warnings and Precautions Warnings 1 Only connect the unit to a 12V power supply with negative grounding. Never install the unit where the operation for safety driving is restrained. Never use the video display function in the front when driving to prevent the violation of laws regulations and also to reduce the risk of traffic accident except using for rear view video camera.
  • Page 4 All manuals and user guides at all-guides.com Warnings and Precautions Precautions Never disassemble or adjust the unit without any professional guide. For details, please consult any professional car shop/ dealer for inquiry. If the front panel or the TFT monitor is squalid, please use a clean silicone cloth and neutral detergent to wipe off the spot. Using a rough cloth and non-neutral detergent such as alcohol for cleaning may result in scratching or decoloration to the applicant.

  • Page 5: Electric Connection

    All manuals and user guides at all-guides.com Electric Connection TV ANTENNAPLUG (Without TV tuner, without this wire.) SUBWOOFER BROWN FRONT RIGHT RCA OUT WHITE FRONT LEFT RCA OUT BLUE REAR RIGHT RCA OUT CAR ANTENNA PURPLE REAR LEFT RCA OUT YELLOW VIDEO OUT BACK CAR VIDEO IN...

  • Page 6: Installation

    All manuals and user guides at all-guides.com Installation Before installing the receiver permanently, fit it in the approximate place in your car ,and connect the equipment according to the speakers and electrical connections. When your system is operated properly,(preferably with the car engine running), follow the instructions for permanent installation of your system.

  • Page 7: General Features

    All manuals and user guides at all-guides.com General Features Stop/Clock RPT/ST Adjust angle AVH-7073 Adjust angle CLOCK STOP RESET EJECT AUX IN MUTE BAND...

  • Page 8: Remote Control

    All manuals and user guides at all-guides.com General Features Remote Control Loading and replacing the battery Stop/Clock RPT/ST Adjust angle AVH-7073 Adjust angle CLOCK STOP RESET EJECT AUX IN Pull out MUTE BAND VOL/SRC/PWR Button: Rotate the VOL button to adjust the Notes of remote control using: volume;...
  • Page 9 All manuals and user guides at all-guides.com Remote Control Button and Function [BAND/RDM] Button: Band switch/Play randomly [APS/PRG] Button: Scan/Program [ST/RPT] Button: Stereo switch/Repeat Mute Sub-T [ ]Button: Play/Pause Band [ ]Button: Stop Language Angle [Setup] Button: Menu setting [Title] Button: Title Menu [ENTER] Button: Play/Confirm S T S T [ ][ ][ ][ ]Button: Up/down/left/right button...

  • Page 10: Play Operation

    All manuals and user guides at all-guides.com Play operation Flex screen( Stop/Clock RPT/ST Adjust angle Open screen: Press [ ] to open. Close screen: Press [ ] to close. Note: If the screen stop when out press[ ] to hide the screen, then press [ ] again the screen will out.

  • Page 11: Mute

    All manuals and user guides at all-guides.com Play operation Display position Adjustment MUTE MUTE: Short press this button to mute the sound, short press For smooth adjustment, make sure that you return the lateral MUTE button again or press any other button to resume angle to the neutral position and then adjust the tilt angle.

  • Page 12: Setup Operation

    All manuals and user guides at all-guides.com Setup Operation MENU V d o setup ENTER MENU: Press [MENU] button, then touch setting button, it Bright Color Contrast Tint will show in screen follows: Vmode Video mode: STAD USER VIDEO Menu operation BRIG SOFT BRIGHT...

  • Page 13: Radio Operation

    All manuals and user guides at all-guides.com Radio Operation Select station Stop/Clock RPT/ST Adjust angle Press [AS/PS] button Seek Tune: In radio playing mode, holding down the [AS/PS] icon will seek and store strong frequency stations automatically. Note: FM band can store 18 stations; AM band can store 12 stations. Browse station Press [SCAN] button Press [SCAN] button to scan the existing station.
  • Page 14 All manuals and user guides at all-guides.com Radio Operation AF(Alternative Frequency) Press AF and then press[ ],the machine will scan signal get the best frequency of the local radio station. If meet a stronger signal of the same program. letter TP will appear on LCD, and unit will automatically choose the stronger signal sought.

  • Page 15: Sound Operation

    All manuals and user guides at all-guides.com Sound Operation Title: In play mode, press [TIT] on the screen or remote control to back to the title menu, and re-select the items needed. Play/pause In play mode, press [ ] button to switch to play or pause mode.

  • Page 16: Sd/Usb

    All manuals and user guides at all-guides.com SD/USB Operation USB/SD play operation AVH-7073 Adjust angle PLAY/PAUSE: CLOCK STOP Press [ ] button to play or pause. RESET EJECT AUX IN Select: MUTE BAND Under USB or SD play, press[ ]can select tracks. REPEAT: Press [ST/RPT] button first to repeat the playing track RPT OFF...

  • Page 17: Tv Operation

    All manuals and user guides at all-guides.com TV Operation Without touch function, without these icons. AVH-7073 Adjust angle CLOCK STOP RESET EJECT AUX IN MUTE BAND TV operation You need install TV antenna, when receive program. TV mode: Press [SRC] to enter main menu, then press TV icon on TFT screen to enter.

  • Page 18: Accessories

    All manuals and user guides at all-guides.com Accessories The included attachments of the unit are as below sheet: Keys ...........one pair Mantle ..........one piece Frame..........one piece The use of any accessories except of those provided might result in damage to the unit .Make sure only to use the accessories shipped with the unit ,as shown above.

  • Page 19: Troubleshooting

    All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Please check the following points before calling a service center. Familiar characters and their meanings Causes Characters Remedies Clean the disc or change the disc. Disc is too dirty.

  • Page 20: General Problems

    All manuals and user guides at all-guides.com Troubleshooting General problems Symptoms Causes Remedies The fuse of the unit has been broken. Install a new fuse with correct rating. The unit cannot be Install a new fuse with correct rating. The fuse of car battery has been broken. powered on.

  • Page 21: Tft Monitor

    All manuals and user guides at all-guides.com Troubleshooting TFT Monitor Symptoms Causes Remedies No image appears on the Correct the connection according to monitor and warning Incorrect connection of Breaking wire. (Electrical Connections Overall Diagram). information is shown at all times. The color system of DVD disc is not Adjust the color system of the DVD disc suited with the monitor.

  • Page 22: Radio Tuner

    All manuals and user guides at all-guides.com Troubleshooting Radio Tuner Symptoms Causes Remedies Correct the connection according to Auto antenna is not extended completely. (Electrical Connections Overall Diagram). It's hard to receive Correct the connection according to stations. Auto antenna is not connected with the unit firmly. (Electrical Connections Overall Diagram).

  • Page 23: Dvd Player

    All manuals and user guides at all-guides.com Troubleshooting DVD player Symptoms Causes Remedies Disc cannot be inserted. There is a disc in the unit already. Eject the disc then insert another one. Change the disc. Disc is scratched. Disc is too dirty or wet. Clean the disc.

  • Page 24: Specifications

    All manuals and user guides at all-guides.com Specifications Specifications subject to change without notice. DISPLAY UNIT RECEVING FREQUENCY FIGURE Liquid crystal panel.........7 inches wide Auto Tiny FREQUENCY AREA BAND Stepping Stepping Display weight ............1.7kg RANGE HZ Number of pixels..........33,6960 pixels 87.5-108.0M EUROPE Display method......Transparent color filter format...
  • Page 25 All manuals and user guides at all-guides.com If you have any questions about this unit or technical problems, please contact: TechnicalSupport@DPAudioVideo.com WNER'S MANUAL Before installation and operating the unit please read this manual thoroughly and retain it for future reference...
