SAWFLY GENERAL DESCRIPTION
The Sawfly Military Eyewear System consists of interchangeable protective lenses
that lock into an ultra comfortable, slim-line frame with adjustable arms and head
strap. The Sawfly Spectacle is available in three sizes: the small size fits up to a
6-7/8 hat size, the regular size fits 6-3/4 to 7-1/2 hat sizes and the large size fits
7-1/2 or larger hat sizes. If in doubt, try each size to confirm optimal fit.
OPTIONAL PRESCRIPTION (Rx) CARRIER
Your prescription lenses can be filled and inserted by your on-base Optometrist.
The Rx Carrier must be fitted with high-impact polycarbonate lenses. The Rx Carrier
clips securely to the nosepiece on the inside the Sawfly Eyewear System.
INSTRUCTIONS
ADJUSTMENTS
The arms on your Sawfly System
can be extended to fit comfortably
behind your ears.
To attach the head strap to the
frame, snap the plastic ends from
the strap into the holes at the end
of the arms.
CARE, CLEANING & MAINTENANCE:
clean and store your eyewear when not in use. The lenses should be cleaned with water or eyewear cleaning spray and dried with the microfiber cleaning pouch.
Anti-Fog (AF) Cloth: The AF cloth should be used to prevent fogging of lenses and Rx.
CAUTION:
To use: Prior to application of the anti-fog cloth, all loose sand and dirt should be cleaned by rinsing with water to avoid scratching of
Avoid cleaner
the lenses. Gently wipe AF cloth over clean, dry interior surface ensuring good even coating. Store the AF cloth in the resealable polybag to
spray contact
extend the life of the cloth's AF performance. The cloth is reusable for over 25 applications if stored properly in its package. Replace the
with eyes
cloth as needed.
SAWFLY MILITARY EYEWEAR SYSTEM
Small Size Kit: Model # 4-0076-9825
Regular Size Kit: Model # 4-0076-9800
Large Size Kit: Model # 4-0076-9700
Small Clear Lens: Model # 4-0137-9001
Regular Clear Lens: Model # 4-0130-9100
Large Clear Lens:
Model # 4-0131-9100
Small Smoke Lens: Model # 4-0137-9002
