Solight WO68-W Manual

EN WO68-W, WO68-B
LED rechargeable lamp 3in1
Thank you for purchasing our equipment. Please read this manual carefully and heed the safety warnings and
instructions before installing, using or repairing the equipment. This will ensure not only the protection of persons,
but also the long life of the equipment. USB-C charging cable included. The device can be placed on a table stand,
clip or wall bracket (all included). The device can be carried and powered by the built-in battery or used plugged in
using the USB cable.
T EC H N IC A L P A R A M ET E R S
Power input
Luminous flux
Chromaticity
Batteries
Battery endurance
Battery power supply time
Power supply
Max. dimension
C O N T R O L
Fully charge the device before use.
To switch On, press the touch button on the lamp head.
Short press: On/Off, change chromaticity.
-
Long press: Adjust the intensity of the light.
-
W A R N IN G
Before use, check that the power cord is not damaged. If damaged, replace it with a cable of the same type.
-
The device contains lithium-ion batteries, so avoid contact with fire, water and strong vibrations. Avoid contact with
-
hot surfaces and avoid prolonged exposure to sunlight.
Leave the power cord disconnected when not in use.
-
Do not use the device if any of its parts are damaged!
-
Do not repair the equipment. Repairs must only be carried out by the manufacturer's service centre.
-
When lighting and charging at the same time, the battery heats up and reduces its lifetime. For maximum
-
battery life, charge the light first and then use.
D ESC R IP T IO N O F E Q U IP M EN T
Magnetic swivel joint
Touch button
Charging LED indicator
Red - charging, Green - fully charged fully
USB-C charging
input
4W
max. 280lm
3000K, 4000K, 6500K
Li-Ion 18650, 3.7V 2000mAh
approx. 3,5h at 100% power
about 3 hours
DC 5V; 1A (cable included, adapter not included)
approx. 320 x 120 x 140mm
