- Page 1 BRC-R Mounting- und operating manual WN 058931 45532/13847 – 2019-09...
-
Page 2: Table Of Contents
Content General Safety Product description Connecting Switching on the operating voltage Teaching the receiver Carrying out a factory reset LED display Recycling and disposal 10. EC Declaration of conformity... -
Page 3: General
General Please retain the documents and forward them to the new owner in case the system is passed on. Symbols used in this manual NOTE A note points to important information that will facilitate your work. REMARK A remark warns you about possible damage to the device and explains how it can be prevented. -
Page 4: Safety
Safety This documentation contains important instructions for the installation and safe operation. Read these instructions before you begin with the installation. In order to ensure your safety please follow all the enclosed instructions. An incorrect installation can lead to serious injuries. - Page 5 2.3 Safety instructions Work on electrical equipment must be performed only by properly qualified specialists. The receiver is part of a building installation. When planning and installing electrical systems, you need to comply with the relevant standards and guidelines of the country in which the system is installed.
-
Page 6: Product Description
Product description 3.1 Radio operation The device works with a bi-directional radio protocol. All devices will be delivered with a standard configuration. These frequencies are also used by other devices; interferences therefore cannot be ruled out. Interferences can also be caused by switching operations, electric motors or defective electrical devices. - Page 7 3.3 Technical data Radio frequency: 868.3 MHz Typ. free-field range: 100 m Voltage supply: 24 V DC +/- 10 % Current consumption: 23 mA Standby consumption: approx. 0.5 W Protection category: Protection class: Dimensions: 13.2 x 70.0 x 24.0 mm (H x W x D) Transistor switch: for microcontroller...
-
Page 8: Connecting
Follow the instructions in the installation manual for the respective drive unit. 4.1 Connecting the receiver For the connection, use the enclosed, 4-wire ribbon cable assembled on one side. Receiver BRC-R Blue Violet VCC + 24 VDC Grey White White Transistor switch for... -
Page 9: Switching On The Operating Voltage
Switching on the operating voltage Once the operating voltage is switched on, the receiver will check its components. The receiver will then send a radiogram with its status information to the drive unit. The LED will then flash as in the teach-in mode. Teaching the receiver 6.1 Opening pulse Follow the instructions enclosed with the... -
Page 10: Carrying Out A Factory Reset
Carrying out a factory reset Press the teach-in button for more than 4 seconds. Press the teach-in button again for more than 4 seconds. ► A fast flashing of the device LED indicates that the factory reset has been successful. LED display The LED indicates the different states of the receiver. -
Page 11: Recycling And Disposal
10. EC Declaration of conformity DORMA Deutschland GmbH DORMA Platz 1 58256 Ennepetal hereby declares that the product BRC-R complies with the provisions of the named EC Directive(s) and that the standards and/or technical specifications referred to in the following have been applied. - Page 12 Deutschland GmbH DORMA Platz 1 58256 Ennepetal Deutschland T: +49 2333 793-0 www.dormakaba.com F: +49 2333 793-4950...
