- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 120630 DINING TABLE REVISION 0 : 09/01/2023 PAGE 1 OF 6 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
120630 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1. -
Page 3: Hardware Identification
120630 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION SMALL LEG FRAME WITH METAL HARDWARE IDENTIFICATION SHORT BOLT 2PCS 4PCS SUCTION CUP (1/4" x 12mm BLK) LONG BOLT ALLEN WRENCH 6PCS (1/4" x 28mm BLK) (4mm) 4PCS (20 x 40mm BLK) PAGE 3 OF 6 PAGE 3 OF 6 COASTERFURNITURE.COM... - Page 4 120630 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 4 OF 6 COASTERFURNITURE.COM...
- Page 5 120630 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 COMPLETE PAGE 5 OF 6 COASTERFURNITURE.COM...
- Page 6 120630 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 1137 DIA X 775 H (MM) Product Size : 44.75" DIA X 30.5" 44.75" Note : Dimension tolerance ±5% PAGE 6 OF 6 COASTERFURNITURE.COM...
