- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 120715 BAR TABLE REVISION 0 : 09/04/2017 REVISION 1 : 09/06/2022 PAGE 1 OF 6 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
120715 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. -
Page 3: Hardware Identification
120715 ITEM: ASSEMBLY INSTRUCTIONS BOTTOM POST HARDWARE IDENTIFICATION LARGE ALLEN KEY (5/16" x 50mm SR) SPRING WASHER (5/16") HEXAGONAL (1/4") 2PCS (1/4") MEDIUM ALLEN BOLT 2PCS (1/4" x 63mm SR) SMALL ALLEN BOLT 3PCS (1/4" x 12mm SR) WASHER (5/16" x 57mm) - Page 4 120715 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 4 OF 6 COASTERFURNITURE.COM...
- Page 5 120715 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 COMPLETE PAGE 5 OF 6 COASTERFURNITURE.COM...
- Page 6 120715 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 597 DIA X 1117H (MM) Product Size : 23.5" DIA X 44" 23.5" 15.75" Note : Dimension tolerance ±5% PAGE 6 OF 6 COASTERFURNITURE.COM...
