Maintenance and User Manual
Pellet Stoves
Elm 4
Elm 8
IMPORTANT!
This Appliance must be fitted by a HETAS / METAC Qualified Installer
Please keep these instructions for future reference
Our pellet stoves must be fitted with an anti-down draft cowl and a cleaning pipe on
pipework or your warranty will be null & void.
We strongly recommend a surge protector to be fitted when installing your pellet
stove, this will ensure that the igniter will not blow in the event of a power cut or
electrical surge in your power supply.
Advertisement
Table of Contents
Related Manuals for Henley Stoves Elm 4
Summary of Contents for Henley Stoves Elm 4
- Page 1 Maintenance and User Manual Pellet Stoves Elm 4 Elm 8 IMPORTANT! This Appliance must be fitted by a HETAS / METAC Qualified Installer Please keep these instructions for future reference Our pellet stoves must be fitted with an anti-down draft cowl and a cleaning pipe on pipework or your warranty will be null &...
- Page 2 Congratulations on the purchase of your new Henley Stove! With the proper care & attention your stove will give you a lifetime of heat & comfort. This manual contains instructions on how to install and maintain your Henley Stove. For both your comfort & safety please take the time to read instructions carefully.
-
Page 3: Table Of Contents
- Rope Seal Check .............. - Door Glass Cleaning ............- Anti-Fire Plate Cleaning ............ - Flue Outlet Cleaning ............- Elm 4 Maintenance ............- Elm 8 Maintenance ............General Steps & Instructions of Operation ..... - Thermostat ................ -
Page 4: Technical Information & Drawings
Door of Pellet Hopper Wi fi Kit Connection Thermostat Power Switch Flue pipe External air Elm 8 connection inlet Description Elm 4 - Z4 Elm 8 - Z8 Height 616mm 909mm Width 385mm 435mm Depth 426mm 460mm Total Weight 51kg... - Page 5 Elm 4 Elm 8...
-
Page 6: Installation Information & Examples
INSTALLATION INSTRUCTIONS & EXAMPLES Anti down-draft Anti down-draft Cowl Cowl Flexi Liner Support Wall Bracket Bend Twin Wall Flexi 80mm Straight Adapter Coupler 80mm Twin w/ cleaning door Single Wall Wall Adapter Flue Pipes External Air External Air Supply Supply T-piece with Flue Pipe Cleaning Door... -
Page 7: Power Supply
POWER SUPPLY European-style / three-hole socket/plug ; 230V /50Hz Normal power consumption : 80w Ignition stage : 340W (~ 5 minutes) NOTE : We strongly recommmend a surge protector to be fitted when installing your pellet stove, this will ensure that the igniter will not blow in the event of a power cut or electrical surge in your power supply. -
Page 8: Surrounding Safe Distance
Front : min.500mm Each side : min. 300mm 300mm 300mm Surrounding Safe Distance Elm 4 / Z4 Comer : min. 250mm Back : min. 250mm Side : min. 350mm Front : min. 1000mm Corner Installation Elm 8 / Z8 Back : min. -
Page 9: Fuel
FUEL Wood pellets are the only combustible material you can use. You can find different kind of pellets with different characteristics and quality on sale. We recommend to use pellets of good quality as this has a great influence on the heating capacity and on the residuals of ash. Pellets characteristics are: diameter of 6mm , length <25mm, they must be well pressed and little friable, without any residuals of glue, resin or additive. -
Page 10: General Cleaning & Maintenance
GENERAL CLEANING AND MAINTENANCE Before doing any maintenance work, it is necessary to turn off the stove and wait until it’s cooled down to room temperature, then pull the plug. The cleaning interval depends on pellet quality and average heating power. Moist or high-ash & sawdust pellets may disrupt normal cleaning interval. -
Page 11: Flue Outlet Cleaning
FLUE OUTLET CLEANING Every week please open the cleaning door on the T-piece or straight pipe and clean out any soot. Below are 2 examples of where you may find cleaning doors or T-pieces in your installation T-PIECE CLEANING Remove T-piece cover on the bottom of the pipe, vacuum inside the T-piece pipe and cover. IMPORTANT - Make sure when clean the T-piece cover is correctly fitted back and a firmly sealed. -
Page 12: Elm 4 Maintenance
ELM 4 DAILY MAINTENANCE The burning pot must be cleaned out after every use. If you don’t clean out the pot after each use: - When you go to re-light the pellet stove it may fail to light - Many pellets will gather in the brazier pot - If it does light with these extra pellets there will be a puff of smoke coming out of the stove into the room. -
Page 13: Monthly Maintenance
ELM 4 - WEEKLY MAINTENANCE There is an ash reservoir at the front of the Elm 4 inside the door, to access loosen the two wing nuts of the door and lift the metal cover up and off the screws. This ash reservoir should... -
Page 14: Elm 8 Maintenance
ELM 8 DAILY MAINTENANCE The burning pot must be cleaned out after every use. If you don’t clean out the pot after each use: - When you go to re-light the pellet stove it may fail to light - Many pellets will gather in the pot - if it does light with these extra pellets it can cause a puff of smoke from the stove into the room. -
Page 15: General Steps & Instructions Of Operation
THERMOSTAT The temperature you read on the display (which is the reference for all the temperature functions of the pellet stove), is sensed by the thermostat which is placed in the back of the stove, just above the power switch. The thermostat is very sensitive to the temperature. -
Page 16: Display Screen
Heat Output DISPLAY SCREEN Time & Power Setting Current Room Timer Temperature + Temperature Mode On/Off Red = Off Green = On Heat Output Temperature Fan Power Power Setting Motor Speed Setting Temperature - Setting Symbol Symbol BUTTON CONTROLS On/Off Button - Press for 3 seconds to start or to stop the stove. -
Page 17: Funtions & Operation Procedures
FUNCTIONS & OPERATION PRECEDURES START - TURNING ON Note: Burning pot must be checked, remove all ash before starting Plug in power supply & switch on power switch on the back of the stove so it lights up. Press for 3 seconds > a green light will appear on the display screen. On/Off Note: Pellets will start to fall into the pot, It will take 3 to 4 minutes before you will have ignition. -
Page 18: Settings Menu
SET UP ( TIME , TIMER & MODE ) Press Button to enter the menu, the setup screen will show as below , Scroll through each mode in the menu that appears by pressing and press Set Button again to enter the mode you want to control. Below is a list of the different modes that are displayed in the menu. -
Page 19: Stove Mode
ON OUR YOUTUBE CHANNEL NAMED - 2. Setting modes on the Elm Pellet stove The Elm 4 at its lowest setting will give out 2.4kW of heat ouput. The smallest size room we would recommend fitting this stove in would be 12ftx12ft with a standard 8ft tall ceiling. -
Page 20: Temperature Settings
ROOM TEMPERATURE SETTINGS Heat output power settings and Fan motor speed settings range from 1 - 5 . These settings greatly affect the ouput temperature of your pellet stove as well as the consumption of pellets and electricity. On daily consumption we would recommend using the heat output and fan motor speed settings on 1 or 2 with temperatures set varying from 18°C to a maximum of 28°C based on your preference. -
Page 21: Remote Control
SETTING THE ROOM TEMPERATURE (RT SET = Room Tempearture) After Power on, press and set the temperature you want using Once the temperature is at the level wanted press to exit A STEP BY STEP VIDEO TUTORIAL FOR SETTING THESE ON YOUR STOVE IS ON OUR YOUTUBE CHANNEL NAMED - 4. -
Page 22: Setting Up A Wifi Kit
WIFI CONNECTION Method 1: Vin WIFI 1：Download TUYA app and register. 2：Insert the acceptor on back of stoves USB connection. 3：press “3” key into Gen parameter, search for “WIFI CONNECTION” as below: Press”3” key again, choose “Vin WIFI” as below: Press “4”... - Page 23 A STEP BY STEP VIDEO TUTORIAL FOR SETTING THESE UP IS ALSO ON OUR YOUTUBE CHANNEL NAMED - Connecting Wifi on Elm Pellet stove Choose the 1 with Wifi mark Open the app Add device First, reboot the device Enter your home Wi-fi Connecting Passowrd Keep the router, mobile and...
- Page 24 WIFI CONNECTION Method 2: App WIFI 1：Download TUYA app and register. 2：Insert the acceptor on back of stoves USB connection. 3：press “3” key into Gen parameter, search for “WIFI CONNECTION” as below: Press again “3” key, choose “Vin WIFI” as below: Press “4”...
- Page 25 First, reboot the device Choose Other Modes Choose the 1 with Wifi mark Open the app Add device confirmation light on flash Firs, reboot the device Connect to the network using an Choose SmartLife access point To connect confirm confirmation... blinks slowly Connecting Connecting Choose SmartLife Option...
-
Page 26: Troubleshooting & Alarms
8 Faults - Causes – Solution TROUBLESHOOTING & ALARMS 8.1 errors and solutions ALARM 1 - MAINT Cause : This is a service alarm to let you know Maintenance time is due after 1200 working hours of use, The stove will not ALARM 6: light again until the maintenance clock is reset Cause: Thermocouple problem, wrong match with or poor contacting with anode... - Page 27 ALARM 5 - PELLET LACK ALM Cause : The hopper where pellets are stored is either empty or too low to feed the auger. Solution : Fill the hopper and restart the stove. ALARM 5: ALARM 2: Cause: Hopper is empty. Cause: Ignition failure Solution: Fill the hopper and re-start the stove.
- Page 28 Information for Low Negative Pressure Solutions - LOW NP - Low Negative Pressure Anti down-draft If the stove is installed for over 3-6 months. Cowl Cause: Pipe is blocked with soot due to not having an 80 mm straight pipe with a cleaning door or a T-Piece installed. Support Wall Solution: Bracket...
-
Page 29: Replacing The Igniter
REPLACING THE IGNITER Inforamtion for Replacing the Ingitor The Igniter location is in the middle of the stove, inside a small black metal pipe (as shown by the white arrow below). 5mm Allen Key 1. To access the ignitor, unscrew the auger motor in front of it with a 5mm Allen key (yellow), make sure you are holding the motor, so it doesn’t fall and carefully move to the side / replace. -
Page 30: Warranty & Commission List
(all sections must be completed in full to uphold warran Flue gas sensor check: Flue tem Yes Customer Name: Henley Stoves does not accept warranty submissions through post INSTALLATION & COMMISSIONING CERTIFICATE INSTALLATION DETAILS COMMISSIONING DETAIL INSTALLATION DETAILS (all sections must be completed in full to uphold warran... -
Page 31: Technical Service - Spare Parts
All spare parts can be purchased throught www.henleystoves.com Elm 4 Cleaning Access Door Smoke Motor... - Page 32 Henley Stoves Elm 4 / z4 Henley Stoves Elm 8 / z8 ENERGIA · · ΕΝΕΡΓΕΙΑ · ENERGIJA · ENERGY · ENERGIE ENERGIA · · ΕΝΕΡΓΕΙΑ · ENERGIJA · ENERGY · ENERGIE 2015/1186 2015/1186...
