- Page 1 Owner's Manual LED Monitor* * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 24GS65F 27GS65F www.lg.com Copyright © 2024 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE ........3 USING THE MONITOR ....15 TROUBLESHOOTING ....30 - Connecting to a PC...........15 ASSEMBLING AND PREPARING 4 PRODUCT SPECIFICATION ..33 HDMI Connection - Supported Drivers and Software ......4 - Factory Support Mode..........37 DisplayPort Connection - Product and Button Description......5 - HDMI Timing (Video) ..........39 - Connecting AV Devices ...........16... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 4: Assembling And Preparing
The power cord provided may differ depending upon the region. • It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Supported Drivers and Software •... -
Page 5: Product And Button Description
Product and Button Description How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. Basic Functions Press the joystick button once with Power on your finger to turn on the monitor. -
Page 6: Moving And Lifting The Monitor
Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. - Page 7 Installing on a Table • If you use the monitor panel without the stand base, its joystick button may cause the monitor to become unstable and fall, resulting in damage to the monitor or • Lift the monitor and place it on the table in an upright position. Place the monitor human injury.
-
Page 8: Adjusting The Stand Height
Adjusting the Stand Height CAUTION Place the monitor mounted on the stand base in an upright position. • Unplug the power cord before moving or installing the monitor. There is risk of Handle the monitor with both hands for safety. electric shock. -
Page 9: Adjusting The Angle
Adjusting the Angle WARNING Place the monitor mounted on the stand base in an upright position. • To avoid injury to the fingers when adjusting the screen, do not hold the lower part Adjust the angle of the screen. of the monitor’s frame as illustrated below. The angle of the screen can be adjusted forward or backward from -5°... -
Page 10: Pivot Feature
Pivot Feature Adjust the angle of the monitor in the direction of the arrow as shown in the figure. The pivot feature allows the monitor to rotate 90° clockwise. Head Rotate the monitor clockwise as shown in the figure. Stand WARNING •... -
Page 11: Tidying Up Cables
Tidying up Cables Complete the installation by rotating the monitor 90° as shown below. Arrange the cables using the cable holder as shown in the illustration. (27GS65F) NOTE • Auto Pivot feature of the display is not supported. • The screen can be rotated easily using the screen pivot shortcut key provided with your Windows operating system. -
Page 12: Using The Kensington Lock
Installing the Wall Mount Plate Using the Kensington Lock This monitor meets the specifications for the wall mount plate or other compatible The connector for the Kensington security system is located at the bottom of the devices. monitor. For more information on installation and usage, refer to the Kensington lock owner’s Place the screen face down. -
Page 13: Installing On The Wall
If you use screws longer than the standard length, it may damage the inside of bracket. the product. A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non- standard screws. 100 mm Wall Mount (mm) - Page 14 Installing the monitor on the ceiling or on a slanted wall may result in the monitor Back of the falling off, which could lead to injury. Use an authorized LG wall mount and contact Monitor the local dealer or qualified personnel.
-
Page 15: Using The Monitor
USING THE MONITOR Connecting to a PC • This monitor supports the *Plug and Play feature. • Illustrations in this manual may differ from the actual product. * Plug and Play: A feature that allows you to add a device to your computer without Press the joystick button, go to Menu →... -
Page 16: Displayport Connection
Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection NOTE HDMI transmits digital video and audio signals from your AV device to the monitor. • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. -
Page 17: Connecting Peripherals
Connecting Peripherals Connecting Headphones Connect peripherals to the monitor via the headphones port. NOTE • Peripheral devices are sold separately. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor. Therefore, it is recommended to use straight earphones. Angled Straight (Recommend) -
Page 18: User Settings
USER SETTINGS Button Menu Status Description Main menu disabled Enables the main menu. Enters the Menu feature. Activating the Main Menu (Holding down the button to turn off the monitor. You can Main menu enabled turn off the monitor this way at any time, including when the Press the joystick button on the bottom of the OSD is on.) monitor. -
Page 19: Main Menu Features
Main Menu Features Main Menu Description : Power Off Turns off the monitor. : Input Sets input mode. : Game Mode Sets the game mode for gaming. : Menu Configures the screen settings. Exits the main menu. : Exit... -
Page 20: User Settings
User Settings Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. Move the joystick up/down and left/right to set the options. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it. - Page 21 Game Mode on SDR(Non-HDR)signal. Menu > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 22 Game Mode on HDR signal. Menu > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 23 Menu > Game Adjust Description Provides seamless and natural images by synchronizing the vertical frequency of the input signal with that of the output signal. CAUTION • Supported Interface: DisplayPort (Adaptive-Sync), HDMI (FreeSync) • Supported Graphic Card : A graphic card that supports AMD’s FreeSync is necessary. FreeSync / Adaptive- Sync •...
- Page 24 Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Once Faster Mode is selected, Motion Blur may occur depending on the content. Response Time Faster Sets the response time to faster.
- Page 25 Menu > Picture Adjust Description Adjusts the brightness of the screen. Brightness Adjusts the contrast of the screen. Contrast Sharpness Adjusts the sharpness of the screen. Mode 1, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter Mode 2, the image becomes.
- Page 26 Adjusts the brightness automatically according to the screen. Disables the DFC feature. Do you want to reset your picture settings? Picture Adjust Picture Reset Cancel the select. Returns to the default settings.
- Page 27 Menu > Input Description Input List Selects the input mode. Adjusts the aspect ratio of the screen. Full Wide Displays the video in widescreen, regardless of the video signal input. Original Displays video according to the aspect ratio of the video signal input. Aspect Ratio Input NOTE...
- Page 28 Menu > General Description Language Sets the menu screen to the desired language. User-defined Key 1 You can customise the main menu to access your preferred menu easily. User-definded Key 1 and User-definded Key 2 appear at the left/right of the main menu. User-defined Key 2 High Saves energy using the high-efficiency SMART ENERGY SAVING feature.
- Page 29 Please set the Input Compatibility Version to match the version of the connected external device. 2.0/1.4 Input Compatibility HDMI If you want to use the HDR, select the Input Compatibility Version to 2.0. Version 1.4/1.2/1.1 DisplayPort If you want to use the HDR, select the Input Compatibility Version to 1.4. This feature lets you set the sound generated from Buzzer when your monitor powers on.
-
Page 30: Troubleshooting
Have you installed the display driver? • Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function. Some features are disabled. - Page 31 The screen retains an image. Does image sticking occur even when the • Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. monitor is turned off? • To extend the lifetime of the monitor, use a screensaver. Screen display is unstable and shaky.
- Page 32 The display color is abnormal. Does the display appear discolored • Set the color to 24 bit (true color) or higher. In Windows, go to Control Panel > Display > Menu > Color Quality. (The settings (16 colors)? may differ depending on the operating system (OS) you use.) Does the display color appear unstable or •...
-
Page 33: Product Specification
PRODUCT SPECIFICATION 24GS65F LCD Screen Color Depth 8-bit color is supported. Resolution Max Resolution 1920 x 1080 @ 180 Hz Recommended Resolution 1920 x 1080 @ 180 Hz Power Sources Power Rating 19 V 1.6 A AC/DC Adapter ADS-45SQ-19-3 19032E type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45FSQ-19 19032EPG-1 type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45FSQ-19 19032EPK-1 type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45FSQ-19 19032EPCU-1 type, manufactured by SHENZHEN HONOR ELECTRONIC... - Page 34 Dimensions Monitor Size (Width x Height x Depth) With Stand 540.8 x 551.1 x 291.2 (mm) Without Stand 540.8 x 323.8 x 42.8 (mm) Weight (Without Packaging) With Stand 5.6 kg Without Stand 3.4 kg Specifications are subject to change without notice. The symbol means alternating current, and the symbol means direct current.
- Page 35 PRODUCT SPECIFICATION 27GS65F LCD Screen Color Depth 8-bit color is supported. Resolution Max Resolution 1920 x 1080 @ 180 Hz Recommended Resolution 1920 x 1080 @ 180 Hz Power Sources Power Rating 19 V 2.0 A AC/DC Adapter ADS-45SN-19-3 19040G type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45SQ-19-3 19040E type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45FSQ-19 19040EPG-1 type, manufactured by SHENZHEN HONOR ELECTRONIC Or ADS-45FSQ-19 19040EPK-1 type, manufactured by SHENZHEN HONOR ELECTRONIC...
- Page 36 Dimensions Monitor Size (Width x Height x Depth) With Stand 614.2 x 575.9 x 291.2 (mm) Without Stand 614.2 x 364.8 x 51.7 (mm) Weight (Without Packaging) With Stand 7.2 kg Without Stand 5.1 kg Specifications are subject to change without notice. The symbol means alternating current, and the symbol means direct current.
-
Page 37: Factory Support Mode
Factory Support Mode HDMI Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 1024 79.976 75.025 1920 x 1080 67.500 60.000 Recommended Timing 1920 x 1080 67.500 60.000... - Page 38 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 1024 79.976 75.025 1920 x 1080 67.500 60.000 1920 x 1080 67.500 60.000 1920 x 1080 84.364 74.990...
-
Page 39: Hdmi Timing (Video)
HDMI Timing (Video) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Remarks 480P 31.5 720P 1080P 67.5 1080P Only HDMI 2.0 and HDMI Freesync Power LED Mode LED Color On Mode Red (For a few seconds) Sleep Mode (Standby Mode) Off Mode... - Page 40 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
