Cudy AP1300 Wall Quick Installation Manual

3 Set Up
Scenario A: With Cudy Controller
LAN LAN LAN LAN WAN
Cudy Controller or Mesh Router
Switch (Optional)
AP AP AP
Clients
In this topology, the AP supports Plug-and-Play by
default. It is managed only via the Cudy Controller
or Mesh Router web page.
Note: If the AP was configured before, please reset it to the factory
defaults.Cudy Controller/Mesh Router must have network access
to the AP in order to find, adopt, and manage them.
EU Declaration of Conformity
1. English:
Cudy hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of directive 2014/53/EU, directive
2011/65/EU, directive (EU) 2015/863.
The original EU declaration of conformity can be found at http://www.cudy.com/ce.
2. Deutsch:
Cudy erklärt hiermit, dass das Gerät den grundlegenden Anforderungen und
anderen relevanten Bestimmungen der Richtlinie 2014/53/EU, der Richtlinie
2011/65/EU und der Richtlinie (EU) 2015/863 entspricht.
Die originale EU-Konformitätserklärung finden Sie unter http://www.cudy.com/ce.
3. Español:
Por la presente, Cudy declara que el dispositivo cumple los requisitos esenciales y
otras disposiciones pertinentes de la directiva 2014/53/UE, la directiva 2011/65/UE,
la directiva (UE) 2015/863.
La declaración de conformidad original de la UE se puede encontrar en
http://www.cudy.com/ce.
4. ltaliano:
Cudy dichiara che il dispositivo è conforme ai requisiti essenziali e alle altre
disposizioni pertinenti della direttiva 2014/53/UE, della direttiva 2011/65/UE e della
direttiva (UE) 2015/863.
La dichiarazione di conformità originale dell'UE è disponibile all'indirizzo
http://www.cudy.com/ce.
5. Français:
Cudy déclare par la présente que le dispositif est conforme aux exigences
essentielles et aux autres dispositions pertinentes de la directive 2014/53/UE, de la
directive 2011/65/UE, de la directive (UE) 2015/863.
La déclaration de conformité originale de l'UE peut être consultée à l'adresse
suivante http://www.cudy.com/ce.
6.Ελληνικό:
Η Cudy δηλώνει ότι η συσκευή συμμορφώνεται με τις βασικές απαιτήσεις και
άλλες σχετικές διατάξεις της οδηγίας 2014/53/ΕΕ, της οδηγίας 2011/65/ΕΕ, της
οδηγίας (ΕΕ) 2015/863.
Η αρχική δήλωση συμμόρφωσης ΕΕ βρίσκεται στη διεύθυνση
http://www.cudy.com/ce.
7. Dutch:
Cudy verklaart hierbij dat het apparaat voldoet aan de essentiële eisen en andere
relevante bepalingen van Richtlijn 2014/53/EU, Richtlijn 2011/65/EU, Richtlijn (EU)
2015/863.
De originele EU-conformiteitsverklaring is te vinden op http://www.cudy.com/ce.
Scenario B: Standalone AP
WAN
LAN
Router
AP
Clients
In this topology, the AP is configured and managed on
its own web page.
Take the steps to configure the AP:
1
Connect your device wirelessly to the AP with
the default SSID printed on the product label.
5GHz Wi-Fi：
2.4GHz Wi-Fi：
8. Português:
Cudy declara que o dispositivo está em conformidade com os requisitos essenciais e
outras disposições relevantes da Diretiva 2014/53/UE, diretiva 2011/65/UE, diretiva
(UE) 2015/863.
A declaração original de conformidade da UE pode ser encontrada em
http://www.cudy.com/ce.
9. Polski:
Cudy niniejszym oświadcza, że wyrób jest zgodny z zasadniczymi wymaganiami i
innymi odpowiednimi przepisami dyrektywy 2014/53/UE, dyrektywy 2011/65/UE,
dyrektywy (UE) 2015/863.
Oryginał deklaracji zgodności UE można znaleźć na stronie
http://www.cudy.com/ce.
10. Türkçe:
Cudy, cihazın 2014/53/EU sayılı direktif, 2011/65/EU sayılı direktif, (EU) 2015/863 sayılı
direktifin temel gerekliliklerine ve diğer ilgili hükümlerine uygun olduğunu beyan eder.
Orijinal AB uygunluk beyanı şu adreste bulunabilir: http://www.cudy.com/ce.
11. Norsk:
Cudy erklærer herved at enheten er i samsvar med de grunnleggende kravene og
andre relevante bestemmelser i direktiv 2014/53/EU, direktiv 2011/65/EU, direktiv (EU)
2015/863.
Den opprinnelige EU-samsvarserklæringen finner du på http://www.cudy.com/ce.
12. Dansk:
Cudy erklærer hermed, at udstyret er i overensstemmelse med de væsentlige krav og
andre relevante bestemmelser i direktiv 2014/53/EU, direktiv 2011/65/EU, direktiv (EU)
2015/863.
Den originale EU-overensstemmelseserklæring findes på http://www.cudy.com/ce.
13. Suomen Kieli:
Cudy vakuuttaa täten, että laite on direktiivin 2014/53/EU, direktiivin 2011/65/EU ja
direktiivin (EU) 2015/863 olennaisten vaatimusten ja muiden asiaankuuluvien
säännösten mukainen.
Alkuperäinen EU-vaatimustenmukaisuusvakuutus löytyy osoitteesta
http://www.cudy.com/ce.
14. Svenska:
Cudy förklarar härmed att enheten överensstämmer med de väsentliga kraven och
andra relevanta bestämmelser i direktiv 2014/53/EU, direktiv 2011/65/EU, direktiv (EU)
2015/863.
Den ursprungliga EU-försäkran om överensstämmelse finns på
http://www.cudy.com/ce.
15. Čeština:
Cudy tímto prohlašuje, že prostředek je v souladu se základními požadavky a dalšími
příslušnými ustanoveními směrnice 2014/53/EU, směrnice 2011/65/EU, směrnice (EU)
2015/863.
2
Launch a web browser and enter
https://cudyap.net (or 192.168.10.254) in the
address bar. Create an administrator password
to log in.
https://cudyap.net
https://cudyap.net
Edge Chrome Firefox Safari
https://cudyap.net
Create an administrator password
Create a password
Confirm
Originál EU prohlášení o shodě je k dispozici na adrese http://www.cudy.com/ce.
16. Slovenčina:
Cudy týmto vyhlasuje, že zariadenie je v súlade so základnými požiadavkami a ďalšími
príslušnými ustanoveniami smernice 2014/53/EÚ, smernice 2011/65/EÚ a smernice
(EÚ) 2015/863.
Originál EÚ vyhlásenia o zhode možno nájsť na adrese http://www.cudy.com/ce.
17. Hungarian language:
A Cudy ezúton kijelenti, hogy a készülék megfelel a 2014/53/EU irányelv, a 2011/65/EU
irányelv és az (EU) 2015/863 irányelv alapvető követelményeinek és egyéb vonatkozó
rendelkezéseinek.
Az eredeti EU-megfelelőségi nyilatkozat a következő címen érhető el
http://www.cudy.com/ce.
18. limba română:
Cudy declară prin prezenta că dispozitivul este în conformitate cu cerințele esențiale și
cu alte dispoziții relevante ale Directivei 2014/53/UE, ale Directivei 2011/65/UE, ale
Directivei (UE) 2015/863.
Declarația de conformitate originală a UE poate fi găsită la adresa
http://www.cudy.com/ce.
19. Български език:
С настоящото Cudy декларира, че устройството е в съответствие със
съществените изисквания и други съответни разпоредби на Директива
2014/53/ЕС, Директива 2011/65/ЕС, Директива (ЕС) 2015/863.
Оригиналът на ЕС декларацията за съответствие може да бъде намерен на адрес
http://www.cudy.com/ce.
20. lietuvių kalba:
"Cudy" pareiškia, kad prietaisas atitinka esminius reikalavimus ir kitas susijusias
Direktyvos 2014/53/ES, Direktyvos 2011/65/ES, Direktyvos (ES) 2015/863 nuostatas.
ES atitikties deklaracijos originalą galima rasti adresu http://www.cudy.com/ce.
21. Українська Мова:
Цим Cudy заявляє, що пристрій відповідає основним вимогам та іншим
відповідним положенням директиви 2014/53/ЄС, директиви 2011/65/ЄС,
директиви (ЄС) 2015/863.
Оригінал декларації про відповідність ЄС можна знайти за посиланням
http://www.cudy.com/ce.
22.Hrvatski:
Cudy ovime izjavljuje da je proizvod u skladu s bitnim zahtjevima i drugim relevantnim
odredbama Direktive 2014/53/EU, Direktive 2011/65/EU, Direktive (EU) 2015/863.
Izvorna izjava EU-a o sukladnosti može se naći na http://www.cudy.com/ce.
23. Slovenski jezik:
Podjetje Cudy izjavlja, da je pripomoček skladen z bistvenimi zahtevami in drugimi
ustreznimi določbami Direktive 2014/53/EU, Direktive 2011/65/EU in Direktive (EU)
2015/863.
3 Follow the step-by-step instructions to
finish Quick Setup.
Quick Setup
2
1 3
Timezone Connections Wireless Summary
2.4G SSID
Password
5G SSID
Password
Back Save & Apply
Enjoy the Internet!
GNU General Public License Notice
The software code in this product was created by third parties and is licensed
under the GNU General Public License ("GPL"). If applicable, Cudy ("Cudy" in this
context refers to the Cudy entity offering respective software for download or
being in charge of the distribution of products that contain respective code) makes
the corresponding GPL source code available upon request via the official website,
either independently or with the assistance of third parties (such as Shenzhen
Cudy Technology Co., Ltd.).
For GPL-related questions, email support@cudy.com. In addition, Cudy offers a
GPL-Code-Centre under https://www.cudy.com/gplcodecenterdownload where
users can get the GPL source codes used in Cudy products for free. Please note,
that the GPL-Code-Centre is only provided as a courtesy to Cudy's customers but
may neither offer a full set of source codes used in all products nor always provide
the latest or actual version of such source codes.
The GPL code used in this product is subject to the copyrights of one or more
authors and is supplied WITHOUT ANY WARRANTY.
Izvirna izjava EU o skladnosti je na voljo na http://www.cudy.com/ce.
24. latviešu valoda:
Ar šo Cudy paziņo, ka ierīce atbilst direktīvas 2014/53/ES, direktīvas 2011/65/ES,
direktīvas (ES) 2015/863 būtiskajām prasībām un citiem attiecīgajiem noteikumiem.
ES atbilstības deklarācijas oriģināls ir atrodams vietnē http://www.cudy.com/ce.
25. Eesti keel:
Cudy deklareerib käesolevaga, et seade vastab olulistele nõuetele ja muudele
direktiivi 2014/53/EL, direktiivi 2011/65/EL ja direktiivi (EL) 2015/863 asjakohastele
sätetele.ELi vastavusdeklaratsiooni originaal on kättesaadav aadressil
http://www.cudy.com/ce.
WEEE
According to the EU Directive on Waste Electrical and Electronic Equipment
(WEEE - 2012/19 / EU), this product must not be disposed of as normal
household waste.
Instead, they should be returned to the place of purchase or taken to a
public collection point for recyclable waste. By ensuring this product is
disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For
more information, please contact your local authority or the nearest
collection point. Improper disposal of this type of waste may result in
penalties according to national regulations.
4
