CERTIFIED PRODUCT
USER INSTRUCTION MANUAL
EN 360:2002,
MICRON BLOCK
VG11 RFU # 11.060
THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODEL:
AFS550002, AFS55002D, AFS550102, AFS550102D, AFS550028,
Certified to AS/NZS 1891.3:2020
AFS550028D and AFC602100, AFC609101, AFC609102 (MICRON
Issued by BSI
Vide Lic. No.: BMP 777809
CONNECTOR)

Advertisement

loading
Need help?

Need help?

Do you have a question about the MICRON BLOCK AFS550102D and is the answer not in the manual?

Questions and answers

Related Manuals for KStrong MICRON BLOCK AFS550102D

Summary of Contents for KStrong MICRON BLOCK AFS550102D

  • Page 1 CERTIFIED PRODUCT USER INSTRUCTION MANUAL EN 360:2002, MICRON BLOCK VG11 RFU # 11.060 THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODEL: AFS550002, AFS55002D, AFS550102, AFS550102D, AFS550028, Certified to AS/NZS 1891.3:2020 AFS550028D and AFC602100, AFC609101, AFC609102 (MICRON Issued by BSI Vide Lic. No.: BMP 777809 CONNECTOR)

  • Page 2: Performance And Limitations Of Use

    In a Fall Factor 2 condition, the user anchors the lanyard below his foot level. The impact on the user is highest in this situation. KStrong Micron has been designed to significantly reduce the impact forces applied to user whilst decreasing the risk of serious injuries when used a foot level.
  • Page 3 Fall Clearance Table : Deployed length of Arrest KStrong Code Arrest Force (kN) Test Energy Absorber (cm) Distance (m) Leading edge test 5.00 1.50 AFS550002 Vertical Testing 5.00 1.50 5.00 1.50 Leading edge test AFS550102 5.00 1.50 Vertical Testing Leading edge test 5.00...
  • Page 4 HOW TO USE MICRON AS A SINGLE OR TWIN LANYARD WITH MICRON CONNECTOR (AFC609100) Insert one Micron Block in Insert the separator in the Now insert the second Move the karabiner to be the karabiner and insert the karabiner. Micron Block. placed in the centre.
  • Page 5 The pre-use check shall involve checking of any wear or abrasion on webbing and sign of corrosion, if any on metal parts or any breakage of Ÿ the plastic casing made of glass reinforced polyamide material. Withdraw from use immediately if there is any doubt about its safe condition or if it has already arrested a fall, the equipment shall not be Ÿ...
  • Page 6 INSTRUCTION FOR MAINTENANCE : Follow the maintenance instructions procedure strictly. Ÿ In case of minor soiling, wipe the equipment with cotton cloth or soft brush. Do not use any abrasive material. For intensive cleaning wash in Ÿ water at a temperature between 25 C to 50 C using a neutral detergent. It should be allowed to dry by Itself and be kept away from open or any other source of heat.

  • Page 7: Icon Explanation

    ICON EXPLANATION Keep away from sunlight or heavy rains. Ensure that the anchorage point has strength of min 12kN (EN) and Min 15kN.(AS/NZS 1891.3). 40 max Ensure that the max angle between the vertical & the lanyard is 40°. Fall Factor Micron Block can be used where the Anchorage point at foot level.
  • Page 8 SATRA Technology Europe Ltd, Bracetown Business Park, Clonee, Dublin D15 YN2P Ireland (Notified Body 2777) Ongoing Assessment Body: SGS Fimko Oy, Takomotie 8, FI-00380 Helsinki, Finland (Notified Body 0598) For EU Declaration, please visit https://kstrong.com/asia/eu-declaration-form/ KStrong Asia Pte Ltd 33A Chander Road, Singapore 219539 Contact Email: customercare@kstrong.com...
