PWC KIT - Depth Finder - GTX, RXT and Wake
PRO (2020 and up) and RXP-X (2018 and up)
Product:
Project no:
Instruction Sheet P/N: 487803570
Revision no:
Revision date:
Item covered:
The following symbols may be used in this document:
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a hazard situation which, if not avoided, could result in minor or moderate injury.
NOTICE Indicates an instruction which, if not followed, could severely damage vehicle components or
other property.
WARNING
- This kit is designed for specific applicable models only (authorized BRP dealers will confirm model(s)). It is
not recommended for units other than the one (those) for which it was sold.
- Should removal of a locking device (e.g. lock tabs, self-locking fasteners, etc.) be required when undergoing
disassembly/assembly, always replace with a new one.
- Torque wrench tightening specifications must strictly be adhered to.
WARNING
Some important safety information and/or operating instructions dedicated to the end user might be included in
this instruction sheet. Make sure to give the kit part number as well as the instruction sheet included with this kit
to the customer. Verify that the customer has access to all the information required for proper use of the
accessory.
NOTE: USE TIGHTENING TORQUES IN THE FOLLOWING TABLE IF NOT OTHERWISE SPECIFIED.
5.8
1.8 ± 0.2 N•m (16 ± 2
M4
lbf•in)
3.3 ± 0.2 N•m (29 ± 2
M5
lbf•in)
7.5 ± 1 N•m (66 ± 9
M6
lbf•in)
15.3 ± 1.7 N•m (135
M8
± 15 lbf•in)
29 ± 3 N•m (21 ± 2
M10
lbf•ft)
52 ± 6 N•m (38 ± 4
M12
lbf•ft)
