DGLP60 WLC
Hands-Free Proximity Card Reader - Wiegand
Lecteur Proximité Main Libre - Wiegand
Range: Online Access Control /
Group Products
FR
EN
INSTALLATION MANUAL
MANUEL D'INSTALLATION
FRANCAIS
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGLP60 WLC and is the answer not in the manual?

Questions and answers

Summary of Contents for CDVI DGLP60 WLC

  • Page 1 FRANCAIS ENGLISH DGLP60 WLC Hands-Free Proximity Card Reader - Wiegand Lecteur Proximité Main Libre - Wiegand Range: Online Access Control / INSTALLATION MANUAL MANUEL D’INSTALLATION Group Products...
  • Page 2 MANUEL D’INSTALLATION DGLP60 WLC Lecteur Proximité Main Libre - Wiegand Merci pour l’achat de ce produit et pour la confi ance que vous accordez à notre entreprise. 1] PRESENTATION DES PRODUITS Wiegand 26, 30 ou 44 bits. Connexion à la centrale via l’interface Bus Wiegand (INTBUSW).
  • Page 3 MANUEL D’INSTALLATION DGLP60 WLC Lecteur Proximité Main Libre - Wiegand - Variateurs. Si le lecteur fonctionne mieux - Ondulateurs. dans une confi guration ou un emplacement - Ecrans informatiques. différent, cela signifi e que l’environnement - Boucle de détection de présence de véhicules.
  • Page 4: Montage

    (Perçeuse, tournevis, mètre,...) et suivez les recommandations de montage qui correspondent au lecteur que vous allez installer. Ref : DGLP60 WLC* A l’aide du lecteur, prenez les marques pour fi xer le produit. Percez 4 pts de fi xation pour vis DIAX M5 sur le support ®...
  • Page 5 Data 1 possède un système de proximité (avec une antenne), la distance Buzzer entre l’antenne DGLP60 WLC et la centrale doit être supérieure à 5 m]. La centrale et l’antenne doivent être alimentées séparément. Voyant vert Il est imperatif d’alimenter la centrale avant l’antenne.
  • Page 6 MANUEL D’INSTALLATION DGLP60 WLC Lecteur Proximité Main Libre - Wiegand 6] FORMAT DE SORTIE WIEGAND 26, 30 ET 44 BIT Chronogrammes 0 logique 1 logique \DATA1 \CLOCK \DATA0 50 μs 50 μs Format Wiegand 26 bit Format 26 bit hexadécimal. La communication s’effectue par une liaison de type Wiegand 26 bit (Signaux : DATA1, DATA0 et CLOCK).
  • Page 7 Lecteur Proximité Main Libre - Wiegand Format Wiegand 30 bit - DGLP60 WLC Format 30 bit hexadécimal. La communication s’effectue par une liaison de type Wiegand 30 bit (Signaux : DATA1, DATA0 et CLOCK). La trame est constituée d’une totalité de 30 bit et se décompose comme suit : 1 - 1ère parité...
  • Page 8 Le préjudice imputable à CDVI ne saurait en aucun cas dépasser la valeur du produit. La responsabilité de CDVI ne peut être engagée auprès de l’acheteur, installateur, client fi nal ou qui que ce soit, lors de dommages consécutifs à des imperfections ou mauvais fonctionnement du produit. Cette garantie prend effet à...
  • Page 9: Product Presentation

    INSTALLATION MANUAL DGLP60 WLC Hands-Free Proximity Card Reader - Wiegand Thank you for buying our products and for the confi dence you placed in our company. 1] PRODUCT PRESENTATION 26, 30 or 44 bits Wiegand outputs. Connection to the controller via the Wiegand bus interface (INTBUSW).
  • Page 10: Mounting Kit

    INSTALLATION MANUAL DGLP60 WLC Hands-Free Proximity Card Reader - Wiegand - Reinforced concrete walls. If the reader works better in a different - Any equipment not in conformity confi guration or position, it means with the EMC directive. that the initial position is not optimal...
  • Page 11: Mounting Instructions

    After checking that the mounting kit is complete, you can proceed with the fi nal installation of your reader. Prepare the appropriate tools (Drill, screwdriver, measuring tape, etc) and follow the mounting instructions Ref : DGLP60 WLC* Measure and mark the center lines to determine the reader position. Drill the mounting screw holes (Diametre: 4MM for the mounting plate and 6MM for the reader).
  • Page 12 Data 1 Buzzer Green light Red light The hands free reader should not be installed on a metal surface. Use a separate power supply for the DGLP60 WLC. Power the hands free reader before powering the controller. cdvi.com cdvigroup.com...
  • Page 13 Open collector output with internal pulls up 1K at +5V or +12V according the ST4 position. 26-bit Wiegand Output - DGLP60 WLC Format 26-bit hexadecimal. The output format is 26-bit Wiegand (Signals: DATA1, DATA0 and CLOCK) The frame is made of 26-bit and built as follow: 1 - First parity: 1-bit –...
  • Page 14 Hands-Free Proximity Card Reader - Wiegand 30-bit Wiegand Output - DGLP60 WLC Signals output in open collectors with pull up in 30-bit hexadecimal format. The output format from the proximity reader is 30-bit wiegand (Signal: DATA1, DATA0 and CLOCK) and is structured as follow: 1 - First parity : 1 bit –...
  • Page 15 “Limited Lifetime Warranty”, complete the enclosed registration card and return it, either by e-mail or post, to the relevant CDVI address or completion of the on line registration at www.cdvigroup.com. Repair or replacement of the defective product is the exclusive remedy.
  • Page 16 Reference : G0301FR0321V02 Extranet : EXE-CDVI_IM DGLP60 WLC CMYK A5 EN-FR 02 Manufacturing Access Control since 1985 CDVI Group FRANCE (Headquarter/Siège social) Phone: +33 (0)1 48 91 01 02 Fax: +33 (0)1 48 91 21 21 CDVI CDVI CDVI DIGIT...
