CDVI BIOSYS 1 Programming

BIOSYS 1
PROGRAMMING

SETTING THE MASTER CARD

1
Reader is connected to
the remote controller
Orange LEDs
flashing

TO DELETE MASTER CARD

In the remote electronics, put Dipswich 1 to ON for 1 sec., then OFF.
The template/users remain programmed.

ADD USER

1
Swipe the master card
One audible
beep is emitted
and the green
LED flashes
slowly
!
The master card is not
programmed if the red LED
activates for 1 second. Refer
to «Setting the master card»
section.

BIOSYS 1 LED Status Indicators

Blue : Standby mode.
Red : Access denied or invalid programming
Green : Access Granted or acknowledgement
Orange : Programming mode.
2
Swipe the master card
Orange LEDs
flashing and
three audible
beep are emitted
2
Swipe the user card
One audible beep
is emitted and the
green LED flashes
faster
!
The user card is already
programmed in the reader if the
red LED activates for 1 second.
Try another user card.
3
LEDs turn to solid
green (master
card approved)
then turn to blue
(Standby mode)
Place and remove
3
your finger on the
sensor five time
Place your finger
on the sensor. One
beep is emitted and
the LED turn to solid
green for a second.
Remove your finger.
The green LED starts
to flash rapidly again.
Repeat the operation
four more times.
!
The fingerprint has not been
enrolled if no audible feedback is
emitted. Repeat steps 1, 2 and 3.
