English Wireless Speaker
Model: YY7859E
The term "product" in this document refers to the unit or its accessories.
The nameplate and important information concerning safety are attached in the following locations:
• the inner surface of the cap on the rear side of the unit
Do not install the product in a confined space, such as a bookcase or built-in cabinet.
Do not expose the batteries (battery pack or batteries installed) to excessive heat, such as sunshine, fire
or the like, for a long time.
Do not subject the batteries to extreme low temperature conditions that may result in overheating and
thermal runaway.
Do not dismantle, open, or shred secondary batteries.
In the event of a secondary battery leaking, do not allow the liquid to come in contact with the skin
or eyes. If contact has been made, wash the affected area with copious amounts of water and seek
medical advice.
Secondary batteries need to be charged before use. Always refer to the manufacturer's instructions or
product manual for proper charging instructions.
After extended periods of storage, it may be necessary to charge and discharge the secondary batteries
several times to obtain maximum performance.
Dispose of properly.
Charging this unit
Connect the USB AC adaptor to this unit using the USB Type-C® cable, then connect the USB AC adaptor
to an AC outlet.
Do not expose the unit to naked flame sources (for example, lighted candles).
This product has magnet(s) which may interfere with pacemakers, programmable shunt valves for
hydrocephalus treatment, or other medical devices. Do not place this product close to persons who use
such medical devices. Consult your doctor before using this product if you use any such medical device.
Never insert the USB plug when the main unit or charging cable is wet. If the USB plug is inserted while
the main unit or charging cable is wet, a short circuit may occur due to liquid (tap water, seawater, soft
drink, etc.) or foreign matter on the main unit or charging cable, and cause abnormal heat generation
or malfunction.
Licenses
• This product contains software that Sony uses under a licensing agreement with the owner of
its copyright. We are obligated to announce the contents of the agreement to customers under
requirement by the owner of copyright for the software. Please access the following URL and read the
contents of the license.
https://rd1.sony.net/help/speaker/sl/25/
• This product is protected by certain intellectual property rights of Microsoft Corporation. Use or
distribution of such technology outside of this product is prohibited without a license from Microsoft
or an authorized Microsoft subsidiary.
• Services offered by third parties may be changed, suspended, or terminated without prior notice.
Sony does not bear any responsibility in these sorts of situations.
Notes on waterproof and dustproof features
(Read before using the unit)
The supplied accessories are neither waterproof nor dustproof.
On waterproof and dustproof performance of the unit
The unit, with the cap fastened securely, has a waterproof specification of IPX7 as specified in "Degree
of protection against water immersion" of the IEC60529 "Ingress Protection Rating (IP Code)", and a
dustproof specification of IP6X as specified in "Degrees of protection against solid foreign objects".
• The supplied accessories and the connectors of this unit (USB, AUDIO IN) are neither waterproof nor
dustproof. To reduce the risk of fires or electric shocks, do not expose the unit to water or droplets
while using any connectors (USB, AUDIO IN) .
Note that malfunctions as a result of water immersion or dust intrusion caused by misuse by the
customer are not covered by the warranty.
To maintain waterproof and dustproof performance
Carefully note the precautions below to ensure proper use of the unit.
• Do not pour high-temperature water or blow hot air from a hair dryer or any other appliance on the
unit directly. Also never use the unit in a place subject to high temperatures, such as in a sauna or
near a heat source.
CAUTION : Handle the cap (-) with care. The cap plays a very important role in maintenance
of the waterproof and dustproof performance. When using the unit, make sure that the cap is
closed completely. When closing the cap, be careful not to allow foreign objects inside. If the cap is not
closed completely the waterproof and dustproof performance may deteriorate and may cause a
malfunction of the unit as a result of water or dust particles entering the unit.
Precautions
On placement
• To eliminate the risk of malfunctions, avoid the following locations when placing or leaving this unit.
– A place subject to high temperatures, such as under direct sunlight or lighting equipment, near a
heat source, or in a sauna
– Inside a vehicle with the windows closed (especially in summertime)
– A place exposed to hot air, such as from a hair dryer
• Place this unit on a flat, level surface. When placed on a sloped surface, the unit may fall over or
fall off the surface due to its own vibration, resulting in injuries, malfunctions, or performance
degradation.
• This unit is not anti-magnetic. Keep objects susceptible to magnetism (recorded tapes, watches, cash
cards and credit cards with magnetic coding, etc.) away from the unit. When you carry around the
unit, keep this in mind as well.
Model, Modelo: YY7859E

How to care for the unit
Although the fabric part of the unit has water repellent treatment applied, you can use the unit more
comfortably and for a longer period of time by following the maintenance procedure below.
• If the surface of the unit gets dirty in the following cases, wash the unit with fresh water (tap water,
etc.) promptly to remove the dirt. Leaving dirt on its surface may cause the fabric part or the passive
radiator section (-) to discolor or deteriorate, or the unit to malfunction.
Ex.
– When salt, sand, etc. is stuck on the unit after using it on a beach, pool side, etc.
– When the unit is stained with sweat or foreign substances (sunscreen, suntan oil, etc.)
Note
• If the surface of the unit gets dirty, do not use detergent, thinner, benzine, alcohol, etc. to clean the
unit because it will affect the water repellent function of the fabric part of the unit.
• If sand grains, etc. enter the fabric or other part of the unit, remove them carefully. Never use a
vacuum cleaner, etc. on the unit. It may cause damage of the speaker section or other part of the unit.
On BLUETOOTH® communications
• Microwaves emitting from a BLUETOOTH device may affect the operation of electronic medical
devices. Turn off this unit and other BLUETOOTH devices in the following locations, as it may cause an
accident:
– in hospitals, near priority seating in trains, locations where inflammable gas is present, near
automatic doors, or near fire alarms.
Other notes
• When placed in an extremely hot or cold environment, the unit stops battery charging for safety
reasons. When the battery is kept charging itself for an extended period of time, the unit may stop
battery charging as well. In such a case, make sure that the ambient temperature is within the battery
charging temperature range (5 °C - 35 °C), unplug and plug the USB cable, and then charge the
battery all over again.
• Even if you do not intend to use the unit for a long time, charge the battery to its full capacity once
every 6 months to maintain its performance.
• If your skin remains in contact with the light for a long time while the light is turned on, there is a risk
of low-temperature burns. To carry the speaker using the shoulder strap, etc. while it is powered on,
turn the light (lighting function) off.
• When the unit's light seems bright or glaring, turn up the room lights or turn off the lighting function.
• If you have any questions or problems concerning this unit that are not covered in this manual, please
consult your nearest Sony dealer.
Trademarks
• Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
• The BLUETOOTH® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by Sony Group Corporation and its subsidiaries is under license.
• USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
• LDAC and LDAC logo are trademarks of Sony Group Corporation or its affiliates.
All other trademarks and registered trademarks are trademarks or registered trademarks of their
respective holders. In this manual, ™ and ® marks are not specified.
Specifications
BLUETOOTH section
Frequency band
2.4 GHz band (2.400 0 GHz - 2.483 5 GHz)
General
Inputs
AUDIO IN jack (Φ 3.5 mm)
DC OUT
USB Type-C® port (for charging the battery of a connected device) (DC 5 V/MAX. 1.5 A)
Power
DC 5 V 3.0 A or DC 9 V 3.0 A (using a commercially-available USB PD compatible AC adaptor
capable of feeding in 3.0 A) or, using built-in lithium-ion battery
Operating temperature
–5 °C - +35 °C
Battery charging temperature
5 °C - 35 °C
Dimensions (W × H × D)
Including projecting parts and controls
Approx. 320 mm × 144 mm × 125 mm
Mass (Including battery)
Approx. 3.3 kg
Included items
Wireless Speaker (1)
USB Type-C® cable (USB-C® to USB-C®)* (1)
Shoulder strap (1)
Documents (1 set)
* A charging cable exclusively designed for the unit. Do not use the cable for any other purposes.
System requirements for charging battery using USB
USB AC adaptor:
Using a commercially-available USB AC adaptor capable of delivering an output current of 1.5 A
or more.
USB AC adaptor compatible with USB PD (USB Power Delivery):
Using a commercially-available USB PD compatible AC adaptor capable of delivering DC 5 V/3.0 A
or DC 9 V/3.0 A.*
* We do not guarantee the operations with all the devices compatible with USB PD.
Design and specifications are subject to change without notice.
Español Altavoz inalámbrico
Modelo: YY7859E
El término "producto" en este documento se refiere a la unidad o sus
accesorios.
POR FAVOR LEA DETALLADAMENTE ESTE MANUAL DE INSTRUCCIONES
ANTES DE CONECTAR Y OPERAR ESTE EQUIPO.
RECUERDE QUE UN MAL USO DE SU APARATO PODRÍA ANULAR LA
GARANTÍA.
Encontrará la placa de identificación e información importante sobre
seguridad en:
• la superficie interior de la tapa de la parte trasera de la unidad
No instale el producto en un espacio reducido, como una estantería o un
armario empotrado.
No exponga las baterías (paquete de baterías o baterías instaladas) a un
calor excesivo, como la luz del sol, el fuego o similares durante un periodo
prolongado.
No someta las baterías a condiciones de temperatura extremadamente
bajas, ya que podría producirse sobrecalentamiento y fuga térmica.
No desmonte, abra ni corte las baterías secundarias.
En caso de fuga de una batería secundaria, no deje que el líquido entre en
contacto con la piel o los ojos. Si se ha producido contacto, lave la zona
afectada con abundante agua y busque asistencia médica.
Hay que cargar las baterías secundarias antes de utilizarlas. Consulte
siempre las instrucciones del fabricante o el manual del producto para
conocer las instrucciones de carga adecuadas.
Después de periodos prolongados de almacenamiento, es posible que
se deba cargar y descargar las baterías secundarias varias veces a fin de
alcanzar su rendimiento máximo.
Deséchelas correctamente.
Cargar esta unidad
Conecte el adaptador de ca USB a esta unidad mediante el cable USB Type-C®
y, a continuación, conecte el adaptador de ca USB a una toma de ca.
No exponga la unidad a fuentes de llama viva (por ejemplo, velas
encendidas).
