E L M D A L E
DOUBLE BOWL UNDERMOUNT SINK VANITY
SKU: 951635, 951640, 951645, 951650, 951655
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing bathroom �xtures and
plumbing. Signature Hardware accepts no liability for any
damage to the �oor, walls, plumbing, vanity cabinet, sink,
counter top, or personal injury during installation.
Observe all local plumbing and building codes.
Unpack and inspect the vanity for damage. If any
damage is found, contact our Customer Relations team
at 1-866-855-2284.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
Ensure that your bathroom �oor is adequately
supported, and the �nished �oor is level.
Ensure that there is adequate support behind the
bathroom wall before installation.
NEVER LIFT THE VANITY TOP FLAT
For Warranty information, please visit: signaturehardware.com/services/warranty
NEVER CARRY THE VANITY TOP FLAT
1
PLANNING
Use the vanity's PDF speci�cation sheet as a reference
when planning your layout. The speci�cation sheet can
be found and downloaded from the product page on
our website.
Because the vanity speci�cation measurements are
approximate and slight variations may occur, we highly
recommend performing any rough-in procedures with
the vanity on site.
TOOLS AND MATERIALS:
Marker*
Tape Measure*
Neutral Cure
Stud Finder
Level
Silicone Sealant
Wood Shims
Drill*
Screwdriver*
Damp Cloth
*not included
REVISED 01/21/2021
CODES: 532229, 532230
532251, 532253, 532254

Advertisement

loading
Need help?

Need help?

Do you have a question about the ELMDALE 951635 and is the answer not in the manual?

Questions and answers

Summary of Contents for Signature Hardware ELMDALE 951635

  • Page 1 �xtures and when planning your layout. The speci�cation sheet can plumbing. Signature Hardware accepts no liability for any be found and downloaded from the product page on damage to the �oor, walls, plumbing, vanity cabinet, sink, our website.
  • Page 2: Cabinet Installation

    E L M D A L E DOUBLE BOWL UNDERMOUNT SINK VANITY SKU: 951635, 951640, 951645, 951650, 951655 CABINET INSTALLATION 1. Determine the location where you would like to install 3. Place the vanity in the installation location. Verify that your vanity.
  • Page 3 E L M D A L E DOUBLE BOWL UNDERMOUNT SINK VANITY SKU: 951635, 951640, 951645, 951650, 951655 SINK INSTALLATION 1. Carefully turn the counter top over, resting it on a 3. Use a pencil or marker to draw an outline around the soft, stable surface to prevent damage.
  • Page 4 E L M D A L E DOUBLE BOWL UNDERMOUNT SINK VANITY SKU: 951635, 951640, 951645, 951650, 951655 5. Carefully place the sink upside down on the counter 7. Repeat steps 1-6 to attach the second sink to your top, positioning it within your marked outline. Once top.
  • Page 5: Countertop Installation

    E L M D A L E DOUBLE BOWL UNDERMOUNT SINK VANITY SKU: 951635, 951640, 951645, 951650, 951655 COUNTER TOP INSTALLATION 1. Apply a bead of silicone sealant around the top edge 9. Wipe away any excess sealant with a damp cloth, and of the vanity cabinet.
  • Page 6 E L M D A L E DOUBLE BOWL UNDERMOUNT SINK VANITY SKU: 951635, 951640, 951645, 951650, 951655 5. For stone tops, such as marble and granite, it is 3. If you are installing a side-splash and/or back-splash, recommended that you apply a high-quality sealer to place a generous amount of silicone sealant on the back of it and press it into place against your bathroom protect from staining and discoloration.
  • Page 7 E L M D A L E DOUBLE BOWL UNDERMOUNT SINK VANITY SKU: 951635, 951640, 951645, 951650, 951655 INSTALLING SHELF 2. For added stability the shelf can be attached to the (If shelf is already installed move to next section) shelf supports using the provided screws.
  • Page 8 E L M D A L E DOUBLE BOWL UNDERMOUNT SINK VANITY SKU: 951635, 951640, 951645, 951650, 951655 ADJUSTING SHELF HEIGHT 2. Remove the screw from the shelve supports if needed. Lift up the shelve and reposition the shelf 1. Remove drawer by pulling out fully then press the supports to the desired height.
  • Page 9 E L M D A L E DOUBLE BOWL UNDERMOUNT SINK VANITY SKU: 951635, 951640, 951645, 951650, 951655 3. Re-install the drawers by pulling the inner slides fully to the front. Sit the drawer on top of the inner slides while inserting the hooks at the back of drawer.
