G A L I O N
FIRECLAY FARMHOUSE SINK
FREGADERO FIRECLAY FARMHOUSE
ÉVIER STYLE FERMETTE EN ARGILE RÉFRACTAIRE
SKU: 953593-33D, 953594-33, 953593-33, 953594-33D
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing �xtures. Signature
Hardware accepts no liability for any damage to the
faucet, plumbing, sink, counter top, or for personal
injury during installation.
Observe all local plumbing and building codes.
Unpack and inspect the product for shipping damage.
If any damage is found, contact our Customer Rela...
tions team via live chat at www.signaturehardware.com
or by emailing support@siganturehardware.com.
ANTES DE COMENZAR
Le recomendamos que consulte a un profesional si no
sabe cómo instalar accesorios de plomería. Signature
Hardware no asume ninguna responsabilidad con
respecto a los daños causados al inodoro, sistema de
plomería, suelo o daños personales durante
la instalación.
Cumpla con todas las normas locales de plomería y
construcción.
Desempaque e inspeccione el producto para determinar
si tiene daños por el envío. Si tiene daños, comuníquese
con nuestro equipo de Relaciones con el Cliente por chat
en directo en www.signaturehardware.com o por correo
electrónico a support@siganturehardware.com.
AVANT DE COMMENCER
Nous vous recommandons de consulter un professionnel
si vous n'avez pas d'expérience dans l'installation
d'appareils de plomberie. Signature Hardware décline
toute responsabilité en cas de dommage au robinet, à la
plomberie, à l'évier, au comptoir ou de blessure corporelle
lors de l'installation.
Respectez tous les codes locaux de plomberie et de
construction.
Déballez et inspectez le produit pour vérifier qu'il n'a pas
été endommagé pendant le transport. Si un dommage
est constaté, communiquez avec notre équipe des
relations avec la clientèle au www.signaturehardware.com
ou par mailsupport@siganturehardware.com.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
Due to the manufacturing process, each sink will
vary slightly dimensionally. Farmhouse sinks may
require custom cabinetry. We recommend consult-
ing an experienced cabinet maker for assistance.
Providing the cabinet maker with the actual sink to
be installed will ensure a custom �t.
Please use assistance when lifting the sink in order
to avoid personal injury.
We recommend undermount sink installation.
Flush-mount and built-up installation are not
recommended.
Ensure there is adequate room for the faucet and
backsplash installations.
CÓMO COMENZAR
Asegúrese de haber reunido todos los materiales
necesarios para la instalación.
Debido al proceso de manufactura, las dimensiones
de cada fregadero varían levemente. Los fregaderos
estilo rural necesitan armarios hechos a medida. Le
recomendamos que consulte con un fabricante de
armarios con experiencia para recibir asistencia.
Indicar el tamaño real del fregadero al fabricante de
armarios garantiza un ajuste a medida.
Pida ayuda cuando levante el fregadero para evitar
lesiones personales.
Le recomendamos que el fregadero se instale
empotrado. No recomendamos las instalaciones de
montaje al ras o incorporadas.
Asegúrese de que haya suficiente espacio para instalar
el grifo y los paneles contra salpicaduras.
1
REVISED 09/24/2024
CODES: SH210000
