Summary of Contents for OHIOSTEEL 7PPS80
- Page 1 SCAN HERE MORE PRODUCT INFO 7PPS80 FERTILIZER AND SALT SPREADER READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 6005889 - REV A - 03/23...
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this product. -
Page 3: Warranty
Product degradation or failure due to corrosion or its effects. • To arrange for product repair visit ohiosteel.com/customer-support and fill out the warranty repair form. You can also call 1-800-652-2321, ext. 212 to speak to our Customer Service Team. This warranty gives you specific legal rights, and you may also have other rights which may vary... -
Page 4: Carton Contents
Carton Contents Summer Material Plate Winter Material Plate PARTS LIST: Pneumatic Wheel (X2) Summer Material Plate M6x60 Bolts (X4) Handle Bar M6 lock nuts (X4) Adjuster Stand M6 X35 Bolts (X2) Pivot Bracket Gear Box and Impeller M6 Wing Nut (X2) Pivot Rod Axle Bearing (X2) Winter Material Plate... - Page 5 Assembly Instructions Before you start, decide what you would like to use your spreader for. If you are spreading salt, use the material plate shown on the left. If you are applying fertilizer, use the material plate shown on the right. You can change the material plate later using the, 'Changing Your Material Plate' section of this manual.
- Page 6 Assembly Instructions Protruding from the back of the hopper body (17) is a V-shaped metal pivot bracket (21). Assemble the bent end of the control rod (16) into the short leg of the hole pivot bracket, as shown below. Feed the other end of the control rod (16) through the hole at the back of the control lever (18).
- Page 7 Operating Instructions Walking Patterns for the optimum application (For Fertilizer Only) There are two methods of effective spreading, longitudinal fertilizer spreading and cross sectional fertilizer spreading. Single Pass Fertilizer Spreading Use ½ the application rate suggested on the back of your fertilizer bag. Cover the area as shown by passing over it in an up and down track as shown, taking into account the spread width of the material being...
- Page 8 Changing The Material Plate Use these instructions only if you are replacing the material plate on the finished unit. Place the finished unit onto a table so that the back of the spreader is easily accessible. Shown below. Locate cotter pin (24) near the assembled material plate (20/23) below the hoper body (17) and remove it.
- Page 9 Changing The Material Plate Remove the pivot rod end (16) by pushing the tip through the hole at the top of the material plate (20/23). Then, remove the material plate and store it for next use. After removing the old material plate, locate the new material plate and reinstall it into the grooves on the bottom of the hopper body (17).
-
Page 10: Replacement Parts
Replacement Parts DESCRIPTION HANDLE, FORMED, 7PPS80 BUSHING, AXLE, SPREADER ASSEMBLY, CONTROL, 7 GAL AXLE, TUBE, 7PPS80 ROD, UPPER, 7 GAL LEG, FRAME, SPREADER FRAME, BACK, 7PPS80 PLATE, MATERIAL, WINTER ROD, LOWER, 7PPS80 HOPPER, OHIO STEEL, 7 GAL 5943 PIN, AGITATOR, 7PPS80... - Page 11 Notes...
- Page 12 PRODUCT MADE IN INDIA MODEL #7PPS80...
