  • Page 1 Quick Start Guide Model 1220 System Manual Thunder Scientific Corporation...
  • Page 2 Model 1220 Humidity Generation System Document #SG1220 - Edition 2.4 Quick Start Guide...

  • Page 3: Important Notice

    FREE. https://www.thunderscientific.com/product_registration Once you have registered your Model 1220 Humidity Generator, click the link on the same page, labeled Click here if you need to download your FREE software. Click here if you need to download your FREE software.
  • Page 4 Thunder Scientific ® Corporation 1220 Item Check List 1. Certificate of Calibration with Data Traceable to (SI) 2. Quick Start Guide 3. HumiCalc® Humidity with Uncertainty (Download) 4. Chamber Port Plug 5. Keyboard 6. Power Cable 7. T10 Torx Driver 8.
  • Page 5 Suomi English Tämä tuote noudattaa WEEE-direktiivin (2002/96/EY) This product complies with the WEEE Directive (2002/96/EC) marking merkintävaatimuksia. Kiinnitetty etiketti osoittaa, että tätä requirements. The affixed label indicates that you must not discard sähkö-/elektroniikkalaitetta ei saa hävittää kotitalousjätteissä. this electrical/electronic product in domestic household waste. Tuoteluokka: Viitaten WEEE-direktiivin liitteessä...
  • Page 6 Deutsch Nederlands Dieses Produkt stimmt mit den Kennzeichnungsanforderungen Dit product voldoet aan de merktekenvereisten van de AEEA- der WEEE-Richtlinie (2002/96/EC) überein. Das angebrachte richtlijn (2002/96/EG). Het aangebrachte merkteken duidt erop dat Etikett weist darauf hin, dass dieses elektrische/elektronische dit elektrische/elektronische product niet met het huishoudelijk Produkt nicht in Hausmüll entsorgt werden darf.

  • Page 7: Table Of Contents

    2.13.8 Date and Time or Point Time ................... 22 2.13.9 Set Date and Time ......................22 2.13.10 Help ..........................23 Reference Drawings 1220D901-2,3 &4 + 1220D905-1 & 2 Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 8: Getting Started

    ETTING TARTED This section will provide the user with information about the Model 1220 humidity generator, where to obtain technical support, software license agreement, specifications, uncertainty, facility requirements and installation. The following sections will provide further details on how to use and operate the Model 1220 generator using the ControLog software.

  • Page 9: Notice

    "as is" basis and the entire risk as to their quality and performance rests with the user. Thunder Scientific Corporation shall not be liable for any incidental or consequential damages in connection with or arising out of the furnishing, use, or performance of the examples, procedures or program.

  • Page 10: Safety Symbols

    Table 1-1 2.4 T ECHNICAL UPPORT If the user requires assistance with any aspect of the 1220 Humidity Generating System or the ControLog application, technical support can be obtained by contacting Thunder Scientific Corporation by any of the following means: Web: www.ThunderScientific.com...
  • Page 11 Should you have any questions concerning this Agreement, or if you desire to contact TSC for any reason, please write: Thunder Scientific Corporation, 623 Wyoming NE, Albuquerque, NM 87123 Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 12: Warranty

    2.6 W ARRANTY Thunder Scientific Corporation (TSC) warrants, to the Buyer, the Product manufactured by TSC to be free of defects in material and workmanship under normal use and service and to be free from inadequate mechanical design when operated within the specified design limitations for a period of one year from date of acceptance.

  • Page 13: Specifications

    Regulated supply pressure lower than the recommended 150 psiG is acceptable but may limit the lowest humidity obtainable from the generator and will require an internal pressure regulator (REG) adjustment. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 14: Uncertainty

    95%. Uncertainty is not specified at flow rates below 10 L/min. Uncertainty is based on the worst-case value from the 1220 uncertainty analysis. Model 1220 System Manual – Document #SG1220 - Edition 2.4...

  • Page 15: Facility Requirements

    500 hours of use depending upon the temperature and humidity at which the generator is operated (reference section 13.3.4). During operations near ambient temperature and 50% RH, one liter should last for approximately 200 hours. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 16: Installation

    2.12.3 Chamber Fluid The Model 1220 test chamber utilizes distilled water as a heat transfer fluid. The distilled water is circulated by a magnetically coupled centrifugal pump through the thermoelectric module, saturator assembly and the test chamber shell for temperature conditioning of the generator.

  • Page 17: Reservoir Initial Filling Procedure

    The supply pressure must be regulated to ensure proper control and operation. It is recommended to double regulate the air supply; once at the supply and again at 1220. The goal of double regulation is to minimize air supply oscillations.

  • Page 18: Quick Start

    When the Remote/Manual switch is in the Remote position the ACS1220 compressor will – not run when first switched to ON. The air compressor system is remotely controlled by the 1220 and will not start until the user requests an operation that requires supply pressure.

  • Page 19: Loading Screen

    As the system boots, the generator will show a loading screen which will indicate the status of the loading process and will also show the software version of the generator. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 20: Controlog Screen

    Upon completion of the loading process the generator will show the main ControLog page and a dialog showing the status of establishing communication with the generator. Once communication with the generator is established the generator’s parameter and data tabs will be displayed. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 21: Control Parameters

    The Parameter Tab Group is located on the left side of the application and contains a parameter tab for each connected device. The 1220 Parameters contain all the control and measurement parameters critical to the operation of the humidity generator.
  • Page 22 Scrolling through parameter items Each Parameter Tab can be scrolled up and down to show additional parameter items. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...
  • Page 23 If multiple parameter tabs are open the user can access other tabs using the scroll bar at the bottom of the group. Taping in the area to the right or left of the scroll indicator will also scroll (toggle) between parameter groups. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...
  • Page 24 Enter the new value into the Setpoint Entry box and select Ok. Notice that the Percent Relative Humidity setpoint value updates to the new value and the actual values begin moving toward the new setpoint. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 25: Control Modes

    Parameter Name, the Actual Value and the Unit the value is displayed in. 2.13.5 Control Modes The user can change the operating mode of the 1220 by selecting from the drop-down menu within the Mode group on the Generator’s Operation menu tab.

  • Page 26: Generating And Shutting Down

    Selecting Shutdown from the run menu commands the 1220 to shut down. The 1220 may be shutdown whenever it is generating. When stopped, all system functions shut down, pressure is vented, and the idle Control/Display screen is shown. During this idle time, when the 1220 is stopped, air is not flowing through the generator.

  • Page 27: Power-Off

    The user is safe to switch the power switch to OFF once the PC has shut down completely (display goes blank). CAUTION! TURNING OFF MAIN POWER WITHOUT SHUTTING DOWN THE SYSTEM FIRST CAN CORRUPT THE EMBEDDED SYSTEM IMAGE. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 28: Date And Time Or Point Time

    Start by long pressing or right clicking anywhere within the status bar. A long press is when you touch and hold the screen. Long enough for a square selection box to appear. Releasing will open the status bar context menu. Model 1220 System Manual – Document #SG1220 - Edition 2.4 March 2025...

  • Page 29: Help

    Select “Set Date and Time” from the context menu to open the system Date and Time dialog. 2.13.10 Help The Help Menu located on the upper right side of the screen allows the user to open the 1220 System Manual.
  • Page 30 DO NOT SCALE PROPRIETARY NOTICE THIRD ANGLE PROJECTION FROM DRAWING THIS DRAWING AND INFORMATION CONTAINED 623 Wyoming S.E. Albuquerque, NM 87123 WITHIN IS PROPRIETARY TO THUNDER SCIENTIFIC AND CANNOT BE COPIED OR REPRODUCED WITHOUT SPECIFIC WRITTEN PERMISSION 1220 Components TOLERANCES 02/04/2025 DRAWN SIZE DWG.
  • Page 31 DO NOT SCALE PROPRIETARY NOTICE THIRD ANGLE PROJECTION FROM DRAWING THIS DRAWING AND INFORMATION CONTAINED 623 Wyoming S.E. Albuquerque, NM 87123 WITHIN IS PROPRIETARY TO THUNDER SCIENTIFIC AND CANNOT BE COPIED OR REPRODUCED WITHOUT SPECIFIC WRITTEN PERMISSION 1220 Components TOLERANCES 02/04/2025 DRAWN SIZE DWG.
  • Page 32 DO NOT SCALE PROPRIETARY NOTICE THIRD ANGLE PROJECTION FROM DRAWING THIS DRAWING AND INFORMATION CONTAINED 623 Wyoming S.E. Albuquerque, NM 87123 WITHIN IS PROPRIETARY TO THUNDER SCIENTIFIC AND CANNOT BE COPIED OR REPRODUCED WITHOUT SPECIFIC WRITTEN PERMISSION 1220 Components TOLERANCES 02/04/2025 DRAWN SIZE DWG.
  • Page 33 DO NOT SCALE PROPRIETARY NOTICE THIRD ANGLE PROJECTION FROM DRAWING THIS DRAWING AND INFORMATION CONTAINED 623 Wyoming S.E. Albuquerque, NM 87123 WITHIN IS PROPRIETARY TO THUNDER SCIENTIFIC AND CANNOT BE COPIED OR REPRODUCED WITHOUT SPECIFIC WRITTEN PERMISSION 1220 Components TOLERANCES 02/04/2025 DRAWN SIZE DWG.
  • Page 34 (~30.5 mm) THIS DRAWING AND INFORMATION CONTAINED 623 Wyoming S.E. Albuquerque, NM 87123 WITHIN IS PROPRIETARY TO THUNDER SCIENTIFIC AND CANNOT BE COPIED OR REPRODUCED WITHOUT SPECIFIC WRITTEN PERMISSION 1220 Fluid Fill / Drain Instruction DETAIL "A" TOLERANCES 02/17/2025 DRAWN SIZE DWG.
  • Page 35 FROM DRAWING THIS DRAWING AND INFORMATION CONTAINED 623 Wyoming S.E. Albuquerque, NM 87123 WITHIN IS PROPRIETARY TO THUNDER SCIENTIFIC AND CANNOT BE COPIED OR REPRODUCED WITHOUT SPECIFIC WRITTEN PERMISSION 1220 Fluid Fill / Drain Instruction TOLERANCES 02/17/2025 DRAWN SIZE DWG. NO.
