SPLIT-SYSTEM HEAT PUMP
Technical & Service Manual
Indoor unit
[Model Name]
[Service Ref.]
PKA-AK24NL-U1
PKA-AK24NL
PKA-AK30NL-U1
PKA-AK30NL
PKA-AK36NL-U1
PKA-AK36NL
Contents
Service manual
1. REFERENCE MANUAL ................................... 2
2. SAFETY PRECAUTION ................................... 3
3. PARTS NAMES AND FUNCTIONS ................. 8
4. SPECIFICATIONS ............................................ 9
5. NOISE CRITERION CURVES ......................... 10
6. OUTLINES AND DIMENSIONS ...................... 11
7. WIRING DIAGRAM ......................................... 12
9. TROUBLESHOOTING .................................... 14
10. FUNCTION SETTING ..................................... 28
11. SPECIAL FUNCTION ..................................... 29
12. DISASSEMBLY PROCEDURE ....................... 32
13. REMOTE CONTROLLER ............................... 36
R454B
INDOOR UNIT
WIRELESS REMOTE
CONTROLLER
(Option)
Technical data
T1. SPECIFICATION CONNECTED TO
OUTDOOR UNITS ···························· 56
T2. POSITION OF THE CENTER OF
GRAVITY ········································ 59
T3. PERFORMANCE CHART ·················· 60
T4. AIRFLOW DATA ······························ 64
September 2024
No. OCD859
ON
RETURN SELECT
MENU
HOLD
OFF
WIRED REMOTE
CONTROLLER
(Option)
