- Page 1 USER MANUAL Water Flow Meter Model No. HCS008FRF Welcome to the RAINPOINT family! Please read the manual before using to learn about the features and functions.
-
Page 2: Table Of Contents
Contents Contents in the box Introduction 2.1 Product Overview 2.2 Specification 2.3 Product Features Connection and Installation 3.1 Flow Meter Connection 3.2 Flow Meter Installation App Features and Functions 4.1 Device Home Page 4.2 Basic Setting 4.3 Special Features 4.4 Charts Troubleshooting Precautions Warranty Policy... -
Page 3: Contents In The Box
1. Contents in the box 1 X HCS008FRF Water Flow Meter 1 X 3/4" Faucet End Connector (NH Thread/ USA-type or BSP thread/ EU-type) 1 X 3/4" Faucet Adapter (NH Thread/ USA-type or BSP thread/ EU-type) 1 X User Manual... -
Page 4: Introduction
2. Introduction 2.1 Product Overview Operation Button Battery Cover 2.2 Specification 3/4" Inlet and Outlet thread. Water rate: 20 L/H to 2400 L/H Working water pressure: 0.5 bar to 8 bar (7-116 psi) Accuracy: ±5% Communication distance with hub about 60m. Powered by 3*AAA alkaline batteries. -
Page 5: Product Features
2.3 Product Features Current water flow rate and consumption checking on both LCD and APP. Hourly, daily and monthly water consumption checking via APP. Split type design. Liter and Gallon switchable. Sleep mode for saving power. Low power alert notification. Water usage warning and correction on APP. -
Page 6: Flow Meter Connection
3.1 Flow Meter Connection This device is a sub-device, please connect the hub of Rainpoint Smart+ series before connecting this device. After the hub is successfully connected. Select the button on the top right corner of the APP home page to add device, or you can go to the hub's home page and use "Sub-devices"... - Page 7 Enter the "Add Device" page, click on , or click on in the upper right corner, scan the QR code in bottom of the manual or on the device to connect to network. Scan to connect 0230008300 -05-...
- Page 8 Insert the batteries, and then the indicator will quickly blink in red. Tips: Pull out the detector and use the tool to unscrew the four screws of the back cover. At the same time, select＂NEXT＂on the APP and start searching devices. Keep the sensor and the hub close to each other to connect automatically.
-
Page 9: Flow Meter Installation
3.2 Flow Meter Installation Option 1: Install the flow meter on the faucet and tighten it hard. 3/4" Faucet End Connector (NH Thread/ USA-type) 3/4" Faucet Adapter BSP Thread/ EU-type (Gray screw thread)(BSP Thread/ EU-type) 3/4" Faucet End Connector 3/4" Faucet Adapter NH Thread/ USA-type (Black screw thread) -07-... - Page 10 Option 2: Connect the flow meter with tubes or hose nozzle. Note: 1 and 5 are available in different type and will be differentiated by region. Please do not remove the connectors while using. The fitting 2 3 4 are indivisible parts. Do not split them. The fitting 1and 4, 2 and 5 are different in the type of thread.
-
Page 11: App Features And Functions
4. APP Features And Functions 4.1 Device Home Page Setting: Basic settings for the sensor. Real-time flow rate Data display: Current water usage, Last water usage, Current time, Last time, Total cumulative, and Total cumulative. Charts: Check the water flow in 24 hours, 30 days, and 12 months. -09-... -
Page 12: Basic Setting
4.2 Basic Setting Find the icon on the top right corner of the APP home page to "Settings" page. In the basic settings, you can check and manage the device information, such as name and interface. -10-... -
Page 13: Special Features
4.3 Special Features Water Usage Warning: Detect the water usage in hours and send a warning notification if the water usage exceeds the standard. -11-... - Page 14 Water Usage Correction: Correct the water usage value in percentage if needed. Data Reset: Clear the water usage record in this device. -12-...
-
Page 15: Charts
4.4 Charts Select Charts to review your water consumption hourly, daily and monthly in a bar graph. -13-... -
Page 16: Troubleshooting
5. Troubleshooting Problem Possible Factors Solution may help Fail to connect Wi-Fi signal unstable. Wait a little bit and try to with the hub Distance between sensor connect one more time by and hub is too far. reinsert the batteries. WiFi is not 2.4GHz. -
Page 17: Precautions
Under freezing temperatures, please keep the sensor away from snow to avoid potential freezing damage. Try to use it following the water flow direction. 7. Warranty Policy RainPoint provides a 1-year limited warranty on this product against manufacturing defects in materials and workmanship. -15-... -
Page 18: Fcc Statement
8. FCC Statement (FCC ID: 2AWDBHCS008FRF) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. FCC Warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. -
Page 19: Customer Support
If you find it difficult to set up and want to watch the setting tutorial video, please subscribe to our channel RainPoint on YouTube. Or scan the QR code to visit the RainPoint channel on YouTube quickly. If the app and the user manual don’t have what you’re looking for, and need some help about Rainpoint, please contact us by LOT NO.: XXXXXX (on the back of the device) -
Page 20: Need Help
Need Help ? Scan the QR code for more help. or Email： support@rainpointonline.com...
