ImageWorks Panoura 18S Installation & Assembly

Pan-only
Hide thumbs

Advertisement

Table of Contents

18
Panoura
S
Pan-Only Installation and Assembly Quick Guide
12/22/23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panoura 18S and is the answer not in the manual?

Questions and answers

Related Manuals for ImageWorks Panoura 18S

Summary of Contents for ImageWorks Panoura 18S

  • Page 1 Panoura Pan-Only Installation and Assembly Quick Guide 12/22/23...
  • Page 2 The full installation manual can typically be found on the desktop of the acquisition PC or on the imageworkscorporation.com website If there are any questions, please do not hesitate to contact us 914-592-6100 ImageWorks Proprietary – Confidential Information...
  • Page 3 Agenda Division of Responsibility Packaging Contents Tooling Required Install Handswitch Install Column Hang C-Arm Attach Chinrest Insert Side Covers Insert Center Panel and Mirrors Final Leveling Check Connecting PC and Handswitch Attach Head Support ImageWorks Proprietary – Confidential Information...
  • Page 4 1. Division of Responsibility Operator Responsibilities before Installer Responsibilities ImageWorks • Column is secured to the installer arrives Responsibilities • Floor is level floor and to the wall • Alignment and • Desired location for equipment • Column is straight up and...
  • Page 5 NOTE: These items above will be needed to fully integrate the unit and train the staff. It’s recommended to check these items BEFORE starting installation, so that if they are not done, office can work on completing this in parallel with installation. ImageWorks Proprietary – Confidential Information...

  • Page 6: Package Contents

    2. Package Contents Basic Pan arrives in three boxes containing: Column C-Arm Assembly, Sensor and Components Accessories (including covers and cables) ImageWorks Proprietary – Confidential Information...

  • Page 7: Tooling Required

    Tool for working with electrical terminals (precision screwdriver, • etc.) (flat blade: 3.5 x 0.5 mm) Power drill • Masonry drill bits (4 mm bit for pilot holes, 12.5 mm bit for anchor • bolts) All hardware is metric ImageWorks Proprietary – Confidential Information...

  • Page 8: Install The Handswitch

    Attach the wall-mounting bracket to the wall so that the hole lines up the metal plate Secure the cable that runs up the wall to the wall- mounting bracket using a nylon ImageWorks Proprietary – Confidential Information...
  • Page 9 The distance from the nylon clip to the connector is roughly 85 mm. Secure the hand switch cable to the wall-mounting bracket using a nylon clip. The cable should be secured roughly 150 mm from the connector. ImageWorks Proprietary – Confidential Information...
  • Page 10 Attach the hand switch box cover taking care not to pinch cables by placing screw in the bottom. Secure the hand switch mounting bracket somewhere close to the hand switch box ImageWorks Proprietary – Confidential Information...

  • Page 11: Install Column

    5. Install Column Unbox the post Assemble the wall-mounting bracket and secure it temporarily using two Allen bolts Secure the wall-mounting bracket to the column with two Allen bolts ImageWorks Proprietary – Confidential Information...
  • Page 12 Fix the column to the floor using four Allen bolts Note: Tapcon Concrete Anchors (3/8" x 3") avail at hardware stores can be used as alternate to supplied floor anchors ImageWorks Proprietary – Confidential Information...
  • Page 13 Don’t tighten until leveling has been checked. * The following coach screws are supplied within the box. Choose the right screws according to the condition of the wall. - 8 x 38 mm - 8 x 65 mm ImageWorks Proprietary – Confidential Information...
  • Page 14 Then adjust the level by slipping the adjustment shims supplied under the column and retightening the bolts. After confirming that the equipment is level, tighten the fixing bolts in the wall-mounting bracket. ImageWorks Proprietary – Confidential Information...
  • Page 15 6. Hang C-Arm Remove box from C-Arm package by removing 4 screws attaching box to skid ImageWorks Proprietary – Confidential Information...
  • Page 16 6. Hang C-Arm Remove sensor package and place in a safe location Remove top cover from c-arm by removing 4 phillips screws. ImageWorks Proprietary – Confidential Information...
  • Page 17 6. Hang C-Arm Move C-Arm assembly into position in front of post Remove bolts from c- arm chassis bracket ImageWorks Proprietary – Confidential Information...
  • Page 18 6. Hang C-Arm Remove bolts that fix C-Arm assembly to wooden frame WARNING: Bolts must be fully removed from chassis to prevent damage upon installation ImageWorks Proprietary – Confidential Information...
  • Page 19 Lift up C-arm assembly and place large hook over mating bracket. Two pins and two tabs fit through mating holes (see next slide) WARNING: Make sure no cables get caught between post bracket and C-arm assembly ImageWorks Proprietary – Confidential Information...
  • Page 20 6. Hang C-Arm There are two alignment pins and two tabs on the bracket that fit through mating holes in the C-arm assembly. Pin into slot (x2) Tab into slot (x2) ImageWorks Proprietary – Confidential Information...
  • Page 21 6. Hang C-Arm • Place and tighten four bolts to fasten C-Arm to Post • Pull cable assembly up through hole in C-Arm Chassis, and make 7 wiring connections (for Pan Unit without ceph) ImageWorks Proprietary – Confidential Information...
  • Page 22 Run Ethernet cable down through same hole. Make sure cable is above the support tray (otherwise front panel will not fit). Remove panel box on rear of unit and connect Ethernet to port in box. Reattach panel box. ImageWorks Proprietary – Confidential Information...
  • Page 23 Check leveling of the unit following 2.2.4 Leveling in the Installation Manual Note: In the case of Ceph unit, check the level after installation of the unit as following “2.9 Cephalometric Unit Mounting” in the Installation Manual ImageWorks Proprietary – Confidential Information...

  • Page 24: Attach Chinrest

    7. Attach Chinrest To attach chinrest assembly, remove 4 bolts from chinrest bracket. Attach chinrest assembly over 2 pins and screw to chinrest bracket on post (4 screws). ImageWorks Proprietary – Confidential Information...
  • Page 25 Fasten the under panel of the chinrest with the four screws. Run cables over the chinrest assembly as shown and make connection of cable on the right side. Fix wiring using banding connectors on chinrest assembly. ImageWorks Proprietary – Confidential Information...
  • Page 26 7. Attach Chinrest Remove screws on rear left and right of chinrest assembly cover. Place cover and insert screws. Snap on the white screw covers. ImageWorks Proprietary – Confidential Information...
  • Page 27 8. Insert Side Covers Remove left side cover from packaging Make cabling connection to inside of keypad (K1, K3-K7, K2 for Ceph unit) ImageWorks Proprietary – Confidential Information...
  • Page 28 8. Insert Side Covers Fasten left side and right side panels ImageWorks Proprietary – Confidential Information...
  • Page 29 9. Insert Center Panel and Mirror Insert center panel and mirror mirror swings toward operator Mount eye-ear beam lever ImageWorks Proprietary – Confidential Information...
  • Page 30 If the unit is slanted by more than ± 0.1 degree (i.e. bubble level is not near center), refer to manual to make adjustments ImageWorks Proprietary – Confidential Information...
  • Page 31 X-ray room out into the room housing the computer. Plug the data and PC connection cables into their respective connectors on the back of the Panoura 18S. PC typically will also connect to office network (not shown) ImageWorks Proprietary – Confidential Information...
  • Page 32 11. Connecting the PC and Handswitch Confirm all connections on the rear of the Panoura 18S Bundle the power, data, PC connection and hand switch box cables together with a provided cable tie as shown in the figure and secure it with the clamp 1.
  • Page 33 Turn on unit and press "Reset" on the operator panel (unit should rotate) Raise unit so underside is accessible. Then turn unit off Insert and attach underside cover with 5 screws and connect connector Remove cap4 screws on the head support fastening bracket ImageWorks Proprietary – Confidential Information...
  • Page 34 12. Attach Head Support Connect the connector on the head support unit to the connector on the driving part ImageWorks Proprietary – Confidential Information...
  • Page 35 NOTE: When mounting the head support unit, make sure that the connector is placed in the connector holder on the head support disc. Beware that the harness is not caught between when the screws are fastened ImageWorks Proprietary – Confidential Information...
  • Page 36 Work with Office to Assure PC is ready for alignment and integration: • Install imaging software that office will plan to use (e.g. Dexis, Eaglesoft, Apteryx, Evasoft, etc) • PC is connected to network and has internet access Continue with standard installation procedure from installation manual ImageWorks Proprietary – Confidential Information...
