X-ERA
Panoura
Pan-Only Installation and Assembly Quick
Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panoura X-ERA and is the answer not in the manual?

Questions and answers

Related Manuals for ImageWorks Panoura X-ERA

Summary of Contents for ImageWorks Panoura X-ERA

  • Page 1 X-ERA Panoura Pan-Only Installation and Assembly Quick Guide...
  • Page 2 These instructions serve as supplemental assembly guidance of the Panoura. They are not meant to replace the installation manual, but rather serve to complement it. If there are any questions, please do not hesitate to contact us 914-592-6100 ImageWorks Proprietary – Confidential Information...
  • Page 3 Agenda Division of Responsibility Packaging Contents Tooling Required Install Column Attaching the Main Top Section Attach Chinrest Final Leveling Critical Adjustment Install Handswitch Connecting PC Cables Install Covers ImageWorks Proprietary – Confidential Information...
  • Page 4 1. Division of Responsibility Operator Responsibilities before Installer Responsibilities ImageWorks • installer arrives Column is secured to the Responsibilities • Floor is level • floor and to the wall Alignment and • Desired location for • Column is level in both Calibration •...
  • Page 5 NOTE: These items above will be needed to fully integrate the unit and train the staff. It’s recommended to check these items BEFORE starting installation, so that if they are not done, office can work on completing this in parallel with installation. ImageWorks Proprietary – Confidential Information...

  • Page 6: Package Contents

    Basic Pan arrives in two boxes containing: Column, Components, hardcopy Install Manual. Main C-Arm Assembly, Sensor and Components The Scanner PC arrives in two boxes containing: PC with preinstalled software & USB license dongle. Monitor. ImageWorks Proprietary – Confidential Information...

  • Page 7: Required Tools

    (blade: 3.5 x 0.5 mm) Power drill (Hammer drill if installing into masonry) • Masonry drill bits (4 mm bit for pilot holes, 12.5 mm bit for • anchor bolts) Digital Volt Meter • Level and tape measure • ImageWorks Proprietary – Confidential Information...

  • Page 8: Install Column

    4. Install Column Unbox the Support Column Unit ImageWorks Proprietary – Confidential Information...
  • Page 9 * To ensure an allowance for adjustment after the angle is adjusted later, tighten the wall anchoring bracket in the middle of the connectors as shown in the following diagram. ImageWorks Proprietary – Confidential Information...
  • Page 10 * The movable support column section has been designed to be stable when the main top section is attached. When checking horizontality, push the bottom of the movable support column section against the wall to make it the same state. ImageWorks Proprietary – Confidential Information...

  • Page 11: Install Column (Initial Level Adjustment)

    Select the screws according to the condition of the wall. • 8×38 mm • 8×65 mm Tighten the screws while carefully checking that there is no deviation in the left-to- right angle. ImageWorks Proprietary – Confidential Information...
  • Page 12 Anchor the support column to the floor with 4 hexagon socket head bolts. • Non-Concrete Floor anchoring Determine the position to install the main unit, and drill pilot holes in the anchor • hole positions. Anchor the support column to the floor with 4 lag screws. • ImageWorks Proprietary – Confidential Information...

  • Page 13: Attaching The Main Top Section

    Remove main top section and the wooden frame from the cardboard box. IMPORTANT: This component is heavy and fragile. Strongly recommend 3 people, 2 to lift and hold and a third to attach bolts when mounting to column. ImageWorks Proprietary – Confidential Information...
  • Page 14 After the temporary hooks are hooked, tighten the bolts until the positioning pins (support column side) fit into the positioning holes on the top frame. * Tighten the bolts starting from the wall side. ImageWorks Proprietary – Confidential Information...
  • Page 15 5. Attaching the Main Top Section Remove the wood frame. Remove the packing bracket (indicator lights section). ImageWorks Proprietary – Confidential Information...
  • Page 16 5. Attaching the Main Top Section Unscrew the screws on the packing bracket (to prevent rotation), and rotate the arm. Remove the packing bracket (bottom of main top section). ImageWorks Proprietary – Confidential Information...
  • Page 17 5. . Attaching the Main Top Section Remove the packing bracket (top of arm section). Remove packaging on the arm section. Be sure to remove the styrofoam for cushioning during transport inserted between the sensor cover and arm section cover. ImageWorks Proprietary – Confidential Information...
  • Page 18 5. Attaching the Main Top Section Connect the support column section and main top section connectors. ImageWorks Proprietary – Confidential Information...
  • Page 19 5. Attaching the Main Top Section How to run the LAN cable (HUB1) When running the LAN cable (HUB1), use the yellow bands attached to the equipment when it is in the packaging. ImageWorks Proprietary – Confidential Information...
  • Page 20 5. Attaching the Main Top Section Loosen the fasten screws for the main control board mounting plate, and then pull it forward. Connect the connectors to the indicator lights section, and then attach it to the main unit ImageWorks Proprietary – Confidential Information...
  • Page 21 Slide the indicator lights section inside, and fasten it with screws. Close gently so that wires are not crushed and so that the indicator lights section is not slammed into the main unit damaging components. ImageWorks Proprietary – Confidential Information...

  • Page 22: Attach Chinrest

    6. Attach Chinrest Attach the chin rest section to the front of the support column section. Connect the support column section and chin rest section connectors. ImageWorks Proprietary – Confidential Information...
  • Page 23 Place the level on the base section of the arm section (refer to the following photos), and check if horizontality is within the standard value in the front-to-back and right-to-left directions. Standard value: ±0.1° ImageWorks Proprietary – Confidential Information...
  • Page 24 A: Right-to-left direction: Wall anchoring bracket (fasteners on wall side) B: Front-to-back direction: Wall anchoring bracket connectors After you have completed making the adjustments, tighten and check the fastening screws for section A, section B, and the floor anchoring section. ImageWorks Proprietary – Confidential Information...

  • Page 25: Install The Handswitch

    Attach the wall-mounting bracket to the wall so that the hole lines up the metal plate Secure the cable that runs up the wall to the wall- mounting bracket using a nylon ImageWorks Proprietary – Confidential Information...
  • Page 26 Secure the hand switch cable to the wall-mounting bracket using a nylon clip. The cable should be secured roughly 3 and 3/8 inches from the connector. ImageWorks Proprietary – Confidential Information...
  • Page 27 Attach the hand switch box cover taking care not to pinch cables by placing screw in the bottom. Secure the hand switch mounting bracket somewhere close to the hand switch box ImageWorks Proprietary – Confidential Information...

  • Page 28: Connecting Pc Cables

    X-ERA must go to PC Ethernet port “2 PAN Control” marked “3” Ethernet connection at the back of the X-ERA must go to PC Ethernet port “3 PAN Sensor” marked Connect X-ERA to the Mains AC Power. ImageWorks Proprietary – Confidential Information...

  • Page 29: Install Covers

    Attaching the bottom cover of the top (1) Attach the bottom cover for the top (rear). Use caution as the cephalometric type differs from the normal type. Attach the bottom cover for the top (middle). ImageWorks Proprietary – Confidential Information...
  • Page 30 10. Install Covers Attach the bottom cover for the top (middle). Attach the rear cover for the top. Be careful not to crush the wiring when attaching the cover. ImageWorks Proprietary – Confidential Information...
  • Page 31 10. Install Covers Attaching the top cover of the arm section Attach the cover for the arm section. Attaching the cable cover Attach the cable cover. ImageWorks Proprietary – Confidential Information...
  • Page 32 To attach the front cover (bottom) for the support column, turn ON the power supply and raise the support column. Attach 2 cover stays. Attach the front cover for the support column. ImageWorks Proprietary – Confidential Information...
  • Page 33 10. Install Covers Attach the connector caps and screw caps covers. ImageWorks Proprietary – Confidential Information...
  • Page 34 Continue with standard installation procedure from installation manual ImageWorks Proprietary – Confidential Information...
