LSD300W-ST
Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.
Model No.: VS20579
Model Name: LSD300W-ST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSD300W-ST and is the answer not in the manual?

Questions and answers

Related Manuals for ViewSonic LSD300W-ST

Summary of Contents for ViewSonic LSD300W-ST

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.
  • Page 2 At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.

  • Page 3: Safety Precautions

    Safety Precautions Please read the following Safety Precautions before you start using the projector. • Keep this user guide in a safe place for later reference. • Read all warnings and follow all instructions. • Allow at least 20“ (50 cm) clearance around the projector to ensure proper ventilation.
  • Page 4 (UPS). • If smoke, an abnormal noise, or a strange odor is present, immediately switch the projector off and call your dealer or ViewSonic®. It is dangerous to continue using the projector. • Use only attachments/accessories specified by the manufacturer.
  • Page 5 Safety Precautions - Ceiling Mounting Please read the following Safety Precautions before you start using the projector. If you intend to mount the projector on the ceiling, it is strongly recommended that you use a proper fitting projector ceiling mount kit and that you ensure it is securely and safely installed.

  • Page 6: Table Of Contents

    Contents Safety Precautions ............3 Introduction ..............8 Package Contents ....................8 Product Overview ....................9 Projector ........................9 Controls and Functions ................... 9 Connection Ports ....................10 Remote Control ..................... 11 Initial Setup ............... 14 Choosing a Location ....................14 Projection Dimensions ..................15 Mounting the Projector ..................17 Preventing Unauthorized Use................18 Using the Security Slot ..................
  • Page 7 Operation ..............26 Turning the Projector On/Off ................26 Starting Up the Projector ..................26 First Time Activation ..................... 26 Shutting Down the Projector ................. 27 Selecting an Input Source ..................28 Adjusting the Projected Image ................29 Auto-Adjusting the Image ..................29 Fine-Tuning the Image Size and Clarity ..............
  • Page 8 Regulatory and Service Information ......70 Compliance Information ..................70 FCC Compliance Statement ................... 70 Industry Canada Statement ................... 70 Declaration of RoHS2 Compliance................. 72 Indian Restriction of Hazardous Substances ............73 Product Disposal at End of Product Life ..............73 Copyright Information ..................74 Customer Service ....................

  • Page 9: Introduction

    Introduction Package Contents NOTE: The power cord and video cables included in your package may vary depending on your country. Please contact your local reseller for more information.

  • Page 10: Product Overview

    Product Overview Projector Power Indicator Light Temperature Indicator Light ENTER Light Source Indicator Light Focus Ring Vent (heated air exhaust) Projection Lens Remote IR sensor Controls and Functions Description Toggles the projector between standby mode and Power On. Power Manually corrects distorted images resulting from an angled projection.

  • Page 11: Connection Ports

    Connection Ports AC Power Cord Inlet Security Bar Ceiling Mount Holes Adjuster Foot Interactive module mounting Port Description [1] AUDIO IN Audio signal input socket. [2] AUDIO OUT Audio signal output socket. [3] HDMI HDMI port. [4] USB 5V/2A (SERVICE) USB Type A port for power supply.

  • Page 12: Remote Control

    Remote Control Button Description SOURCE • Displays the source selection bar. Controls and Functions • Displays the HELP menu by a long press for 3 seconds. Manually corrects distorted images resulting Keystone Keys from an angled projection. ENTER Enacts the selected OSD Menu item.
  • Page 13 Button Description Increases the volume level. (Volume Decreases the volume (Volume level. Down) Toggles audio between on (Mute) and off. Magnifies the projected picture size. Reduces the projected picture size. COLOR MODE Displays the color mode selection bar. Remote Control Effective Range To ensure proper function of the remote control follow the steps below: 1.
  • Page 14 Replacing the Remote Control Batteries 1. Remove the battery cover from the rear of the remote control by pressing the finger grip and sliding it in the direction of the arrow as illustrated. Remove any existing batteries (if necessary) and install two AAA batteries. NOTE: Observe the battery’s polarities as indicated.

  • Page 15: Initial Setup

    Initial Setup This section provides detailed instructions for setting up your projector. Choosing a Location Personal preference and room layout will decide the installation location. Consider the following: • Size and Position of your screen. • Location of a suitable power outlet. •...

  • Page 16: Projection Dimensions

    Projection Dimensions NOTE: See “Specifications” on page 63 for the native display resolution of this projector • 16:10 Image on a 16:10 Screen • 16:10 Image on a 4:3 Screen NOTE: (e) = Screen (f) = Center of Lens 16:10 Image on a 16:10 Screen (a) Screen (b) Projection Distance (c) Image...
  • Page 17 16:10 Image on a 4:3 Screen (a) Screen (b) Projection Distance (c) Image (d) Vertical Offset Size minimum maximum Height minimum maximum inch mm inch inch inch inch inch 60 1524 23.44 595 23.44 595 30.00 3.00 3.00 70 1778 27.34 695 27.34 695 35.00 3.50 3.50...

  • Page 18: Mounting The Projector

    If you buy a third-party mount, please use the correct screw size. Screw size can vary depending on the thickness of the mounting plate. 1. To ensure the most secure installation, please use a ViewSonic® wall or ceiling mount. 2. Ensure the screws used to attach a mount to the projector meet the following specifications: •...

  • Page 19: Preventing Unauthorized Use

    Preventing Unauthorized Use The projector has several built-in security features to prevent theft, access, or accidental setting changes. Using the Security Slot To help prevent the projector from being stolen, use a security slot locking device to secure the projector to a fixed object. Below is an example of setting up a security slot locking device: NOTE: The security slot can also be used as a safety anchor if the projector is...

  • Page 20: Using The Password Function

    Using the Password Function To help prevent unauthorized access or use, the projector offers a password security option. The password can be set through the On-Screen Display (OSD) Menu. NOTE: Make note of your password, and keep it in a safe place. Setting a Password Press MENU to open the OSD Menu and go to: SYSTEM...
  • Page 21 Changing the Password 1. Press MENU to open the OSD Menu and go to: SYSTEM > Security Settings > Change Password. 2. Press Enter, the message, ‘INPUT CURRENT PASSWORD’ will appear. 3. Enter the old password. ͫ If the password is correct, the message, ‘INPUT NEW PASSWORD’ will appear.
  • Page 22 Forgetting the Password If the password function is activated, you will be asked to enter the six-digit password every time you turn on the projector. If you enter the wrong password, the password error message, as pictured to the right, will appear for 5 seconds, and the message ‘INPUT PASSWORD’...

  • Page 23: Locking The Control Keys

    Locking the Control Keys With the control keys on the projector locked, you can prevent your settings from being changed accidentally (by children, for example). NOTE: When the Panel Key Lock is On, no control keys on the projector will operate except Power.

  • Page 24: Making Connections

    Making Connections This section guides you on how to connect the projector with other equipment. Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the projector. 2. Plug the power cord into a power outlet. NOTE: When installing the projector, incorporate a readily accessible disconnect device in the fixed wiring, or connect the power plug to an easily accessible...

  • Page 25: Connecting To Computer Sources

    Connecting to Computer Sources VGA Connection Connect one end of a VGA cable to the VGA port of your computer. Then connect the other end of the cable to the COMPUTER IN port of your projector. NOTE: Some notebooks do not turn on their external displays automatically when connected to a projector.
  • Page 26 The connection illustrations below are for reference only. The connecting jacks available on the projector vary with each projector model. Some cables may not be included with the projector. They are commercially available from electronics stores.

  • Page 27: Operation

    Operation Turning the Projector On/Off Starting Up the Projector 1. Press the Power button to turn on the projector. 2. The light source will light up, and a “Power On/Off Ring Tone” will play. 3. The Power Indicator Light stays green when the projector is On.

  • Page 28: Shutting Down The Projector

    Shutting Down the Projector 1. Press the Power or Off button and a confirmation message will appear to prompt you to press the Power or Off button a second time. Additionally you can press any other button to cancel. NOTE: If you do not respond in a few seconds after the first press, the message will disappear.

  • Page 29: Selecting An Input Source

    Selecting an Input Source The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. If you want the projector to automatically search for the input source, ensure the Quick Auto Search function in the SYSTEM menu is On.

  • Page 30: Adjusting The Projected Image

    Adjusting the Projected Image Adjusting the Projector's Height and Projection Angle The projector is equipped with one (1) adjuster foot. Adjusting the foot will change the projector’s height and the vertical projection angle. Carefully adjust the feet to fine tune the projected image’s position. Auto-Adjusting the Image Sometimes, you may need to improve the picture quality.

  • Page 31: Correcting Keystone

    Correcting Keystone Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection. To correct this, besides adjusting the height of the projector, you may also: Perform automatic keystone correction by enabling the Auto V Keystone function. Or manually correct keystone following the below steps: 1.

  • Page 32: Adjusting 4 Corners

    Adjusting 4 corners You can manually adjusts the shape and size of an image that is unevenly rectangular on all sides. 1. To display the Corner Adj. page, you can do one of the followings: • Press • Open the OSD menu and go to the DISPLAY >...

  • Page 33: Controlling The Projector Through A Lan Environment

    Controlling the Projector through a LAN Environment The projector supports Crestron® software. With correct settings for the LAN Control Settings menu, you can manage the projector from a computer using a web browser when the computer and the projector are properly connected to the same local area network.
  • Page 34 • If you are in a non-DHCP environment: 1. Repeat steps 1-2 above. 2. Highlight LAN Settings and press to select Static 3. Contact your ITS administrator for information on the Projector IP Address, Subnet Mask, Default Gateway, DNS Server settings.

  • Page 35: Menu Functions

    Menu Functions This section will introduce the On-Screen Display (OSD) Menu and its options. General On-Screen Display (OSD) Menu Operation NOTE: The OSD screenshots in this manual are for reference only and may differ from the actual design. Some of the following OSD settings may not be available. Please refer to the actual OSD of your projector.

  • Page 36: On-Screen Display (Osd) Menu Tree

    On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Option DISPLAY Aspect Ratio Auto 16:9 16:10 Native Keystone Auto V Keystone Off/On Vertical +40~-40 Horizontal +40~-40 Corner Adj. Top-Right Top-Left Bottom-Right Bottom-Left Position X: -5 ~ 5, Y: - 5 ~ 5 Phase 0~31 H.
  • Page 37 Main Menu Sub-menu Menu Option IMAGE Color Mode Brightest Presentation Standard Photo Movie Golf User 1 User 2 Brightness 0~100 Contrast -50~50 Color Temp. 9300K/7500K/6500K Red Gain 0~100 Green Gain 0~100 Blue Gain 0~100 Red Offset -50~+50 Green Offset -50~+50 Blue Offset -50~+50 Advanced...
  • Page 38 Main Menu Sub-menu Menu Option Auto Power On Signal Disable/VGA/HDMI /All Disable/Enable Direct Power On Disable/Enable Smart Energy Auto Power Off Disable/10 min/20 min/30 min Sleep Timer Disable/30 min/1 hr/2hr/3 hr/4 hr/ 8 hr/12 hr Power Saving Disable/Enable Standby Settings VGA Loop Through Off/On Audio Pass Through...
  • Page 39 1~240 m Timer Display Always/1 min/2 min/3 min/Never Timer Position Top-Left/Bottom-Left/ Top-Right/Bottom-Right Timer Counting Direction Count Down/Count Up Sound Reminder Off/On Start Counting/Off Pattern Test Card Blank Timer Disable/5 min/10 min/15 min/20 min/25 min/30 min Message Splash Screen Black Blue ViewSonic...
  • Page 40 Main Menu Sub-menu Menu Option ADVANCED 3D Settings 3D Format Auto Frame Sequential Frame Packing Top-Bottom Side-by-Side 3D Sync Invert Disable/Invert Save 3D Settings Yes/No HDMI Settings HDMI Format Auto/RGB/YUV HDMI Range Auto/Enhanced/ Normal LAN Control Settings LAN Settings DHCP ON/Static IP Projector IP Address Subnet Mask Default Gateway...
  • Page 41 Main Menu Sub-menu Menu Option SYSTEM Language Multi-Language OSD Selection Projector Position Front Table Rear Table Rear Ceiling Front Ceiling Menu Settings Menu Display Time 5 sec/10 sec/15 sec/20 sec/25 sec/30 sec Menu Position Center/Top-Left/ Top-Right/ Bottom-Left/ Bottom-Right High Altitude Mode Quick Auto Search Security Settings Change Password...
  • Page 42 Main Menu Sub-menu Menu Option INFORMATION Source Color Mode Resolution Color System IP address MAC address Firmware Version 3X Fast Input...

  • Page 43: Display Menu

    DISPLAY Menu 1. Press the MENU button to display the On-Screen Display (OSD) Menu. 2. Press to select the DISPLAY menu. Then press Enter or use to access the DISPLAY menu. 3. Press to select the menu option. Then press Enter to display its sub-menu, or press...
  • Page 44 Menu Option Description Aspect Ratio Auto Scales an image proportionally to fit the projector’s native resolution in its horizontal width. This is suitable for the incoming image which is neither in 4:3 nor 16:9 and you want to make most use of the screen without altering the image’s aspect ratio.
  • Page 45 Menu Option Description H. Size Adjusts the horizontal width of the image. NOTE: This function is only available when a PC input signal is selected. Zoom Magnifies the projected image and allows you to navigate the image. OverScan Adjusts the overscan rate from 0 to 5. NOTE: This function is only available when a Composite Video or HDMI input signal is selected.

  • Page 46: Image Menu

    IMAGE Menu 1. Press the MENU button to display the On-Screen Display (OSD) Menu. 2. Press to select the IMAGE menu. Then press Enter or use to access the IMAGE menu. 3. Press to select the menu option. Then press to display its sub-menu, Enter or press...
  • Page 47 Menu Option Description Color Mode Brightest Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms. Presentation Designed for presentations under daylight environment to match PC and notebook coloring.
  • Page 48 Menu Option Description Color Temp. There are several preset color temperature settings (9300K, 7500K, 6500K) available. The available settings may vary according to the personal preferences. To set a custom color temperature, you can further adjust the following items: Red Gain/Green Gain/Blue Gain Adjusts the Contrast levels of Red, Green, and Blue.

  • Page 49: Power Management Menu

    POWER MANAGEMENT Menu 1. Press the MENU button to display the On-Screen Display (OSD) Menu. 2. Press to select the POWER MANAGEMENT menu. Then press Enter or use to access the POWER MANAGEMENT menu. 3. Press to select the menu option. Then press Enter to display its sub-menu, or press...
  • Page 50 Menu Option Description Auto Power On Signal Selecting VGA/HDMI allows the projector to turn on automatically once the VGA/HDMI signal is fed through the VGA/HDMI cable. You can also select All and the projector will turn on automatically upon receiving either a VGA or HDMI signal.
  • Page 51 Menu Option Description Standby Settings The functions below are available in standby mode (plugged in, but not turned on). VGA Loop Through When selecting On, the projector outputs the signal received only from COMPUTER IN. Audio Pass Through When selecting On, the projector outputs an audio signal when the Audio In and Audio Out sockets are correctly connected to a proper device.

  • Page 52: Basic Menu

    BASIC Menu 1. Press the MENU button to display the On-Screen Display (OSD) Menu. 2. Press to select the BASIC menu. Then press Enter or use to access the BASIC menu. 3. Press to select the menu option. Then press Enter to display its sub-menu, or press...
  • Page 53 Menu Option Description Audio Settings Mute Select to temporarily turn off the projector’s internal speaker or the volume being output from the audio output jack. Audio Volume Adjusts the volume level of the projector’s internal speaker or the volume being output from the audio output jack. Power On/Off Ring Tone Turns on/off the ring tone during the starting up and shutting down process.
  • Page 54 Menu Option Description Blank Timer Allows the projector to return the image automatically after a period of time when there is no action taken on the blank screen. To display the blank screen, press Blank on the projector or remote control. NOTE: Do not block the projection lens as this could cause the blocking object to become heated and deformed or even...

  • Page 55: Advanced Menu

    ADVANCED Menu 1. Press the MENU button to display the On-Screen Display (OSD) Menu. 2. Press to select the ADVANCED menu. Then press Enter or use access the ADVANCED menu. 3. Press to select the menu option. Then press to display its sub-menu, Enter or press to adjust/select the setting.
  • Page 56 Menu Option Description 3D Settings This projector features a 3D function which enables you to enjoy 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view 3D images. 3D Format The default setting is Auto and the projector automatically chooses an appropriate 3D format when detecting 3D...
  • Page 57 Menu Option Description LAN Control Settings LAN Settings ͫ DHCP ON: Select this if you are in a DHCP environment and Projector IP Address, Subnet Mask, Default Gateway, DNS Server settings will be automatically retrieved. ͫ Static IP: Select this if you are in a non-DHCP environment and make adjustments to below settings.
  • Page 58 Menu Option Description Reset Settings Returns all settings to the factory preset values. When using Reset Settings, the following settings will still remain: Zoom, Keystone, Language, Projector Position, USB A Power, High Altitude Mode, Security Settings, Remote Control Code, Control Method, Baud Rate, Corner Adj., LAN Control Settings, Light Source Hours Information.

  • Page 59: System Menu

    SYSTEM Menu 1. Press the MENU button to display the On-Screen Display (OSD) Menu. 2. Press to select the SYSTEM menu. Then press Enter or use to access the SYSTEM menu. 3. Press to select the menu option. Then press to display its sub-menu, Enter or press...
  • Page 60 Menu Option Description Language Sets the language for the On-Screen Display (OSD) Menu. Projector Position Selects a proper position for the projector. Menu Settings Menu Display Time Sets the length of time the OSD Menu will remain active after your last interaction. Menu Position Sets the OSD Menu’s position.
  • Page 61 Menu Option Description Baud Rate Selects a baud rate that is identical with your computer’s so that you can connect the projector using a suitable RS-232 cable and control the projector with RS-232 commands...

  • Page 62: Information Menu

    INFORMATION Menu 1. Press the MENU button to display the On-Screen Display (OSD) Menu. 2. Press to select the INFORMATION menu and display its contents. Menu Option Description Source Shows the current input source. Color Mode Shows the selected mode in the IMAGE menu. Resolution Shows the native resolution of the input source.

  • Page 63: Appendix

    Physical (W x H x D) 293 x 115 x 237 mm (11.5” x 4.5” x 9.3”) Weight Physical 2.85 kg (6.28 lb) Power 255 W (Typical) consumption < 0.5W (Standby) Please use the power adapter from ViewSonic® or an authorized source only. The test condition follows EEI standards.

  • Page 64: Projector Dimensions

    Projector Dimensions 293 mm 115 mm...

  • Page 65: Timing Chart

    Timing Chart HDMI (PC)/Analog RGB Signal Resolution (dots) Aspect ratio Refresh rate (Hz) 640 x 480 60/72/75/85/120 720 x 400 SVGA 800 x 600 56/60/72/75/85/120 1024 x 768 60/70/75/85/120 1152 x 864 WXGA 1280 x 768 15:9 1280 x 800 16:10 60/75/85 SXGA...
  • Page 66 HDMI (Video) Signal Resolution (dots) Aspect ratio Refresh rate (Hz) SDTV (480i) 720 (1440) x 480 4:3/16:9 SDTV (480p) 720 x 480 4:3/16:9 SDTV (576i) 720 (1440) x 576 4:3/16:9 SDTV (576p) 720 x 576 4:3/16:9 HDTV (720p) 1280 x 720 16:9 50/60 HDTV (1080p)
  • Page 67 HDMI 3D Signal Resolution (dots) Aspect ratio Refresh rate (Hz) In Frame Packing format 1080p 1920 x 1080 16:9 23.98/24 720p 1280 x 720 16:9 50/59.94/60 In Side-by-Side format 1080p 1920 x 1080 16:9 50/60 1080i 1920 x 1080 16:9 50/60 720P 1280 x 720...

  • Page 68: Troubleshooting

    Troubleshooting This section describes some common problems that you may experience when using the projector. Problem Possible Solutions The projector does not turn on • Ensure the power cord is properly attached to the projector and to the power outlet. •...

  • Page 69: Led Indicator

    LED Indicator Light Status and Description Power Green Stand-by mode Flashing Green Powering up Green Normal operation Green Normal power-down cooling Flashing Downloading Green Green Green Burn in off Light source Green First light source-lit error cooling Flashing Light source error in normal operation Green Color wheel start has failed Heating/Cooling...

  • Page 70: Maintenance

    • ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the lens or case. Some chemical cleaners have been reported to damage the lens and/or case of the projector. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.

  • Page 71: Regulatory And Service Information

    Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 72 CE Conformity for European Countries The device complies with the EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU. Ecodesign Directive 2009/125/EC. The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE).

  • Page 73: Declaration Of Rohs2 Compliance

    Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Substance...

  • Page 74: Indian Restriction Of Hazardous Substances

    Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...

  • Page 75: Copyright Information

    Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic® and the three birds logo are registered trademarks of ViewSonic® Corporation. VESA is a registered trademark of the Video Electronics Standards Association.

  • Page 76: Customer Service

    For technical support or product service, see the table below or contact your reseller. NOTE:  You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn www.viewsonic.com/hk/ 香港 (繁體中文) Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/...

  • Page 77: Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
  • Page 78 (e) the serial number of the product. 3. Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. 4. For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
  • Page 79 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.

  • Page 80: Mexico Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 81 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based...
  • Page 82 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
