TrailFX WXVS95B Assembly, Installation, Operation And Maintenance Instructions

APPLICATION: UNIVERSAL FOR TRUCK OR SUV ( DESIGNED FOR BUMPERS AND MOUNTING PLATES WITH 10" x 4.5" PATTERN )
DEALER / INSTALLER
END USER
WARNING
WARNING
PARTS LIST
DESCRIPTION
XV95 RECOVERY WINCH
SYNTHETIC ROPE, 94' X 8.3mm (PRE-SPOOLED)
HAWSE FAIRLEAD
BLACK CLEVIS HOOK
BLACK BATTERY CABLE LEAD (5' 3/4")
MOUNTING HARDWARE PACK
FAIRLEAD HARDWARE PACK
USER GUIDE
TORQUE SPECS
TORQUE
42.75 FT-LBS.
65.25 FT-LBS.
Visit www.trailfx.com or 1 (866) 638-4870 for Warranty Information / Tech Support / Product Updates.
XV95 RECOVERY WINCH
®
Assembly, Installation, Operation,
and Maintenance Instructions
Provide a copy of these instructions to the end user of this product. These instructions provide
important operating and safety information for proper usage of this product. Demonstrate the
proper use of the product with the end user. Have the end user demonstrate that they understand
the proper use of the product.
Read and follow all instructions included in this manual. Ask your Dealer/Installer for assistance if
you do not understand the proper use of the product. Never remove any decals from the product.
Failure to follow these instructions can result in injury or death.
Observe safety precautions for personal safety and the safety of others. Improper equipment
operation may cause personal injury and equipment damage. Never operate this winch if
you are under 16 years of age.
TOOLS REQUIRED
SOCKET WRENCH
SOCKETS - 19mm, 5/8
ADJUSTABLE WRENCH / 3/4" 19mm WRENCH
LARGE FLATHEAD SCREWDRIVER
SIZE
©2024 Keystone Automotive Operations Inc. All Rights Reserved. 2024. REV1
ZIP TIES
MOUNTING HARDWARE PACK
QTY
1
1
1
1 HEXAGON SOCKET HEAD CAP SCREW M10X30
1
FAIRLEAD HARDWARE PACK
1
1
1
M10
M12
PART
NUMBER
INSTALL
TIME
DESCRIPTION
NUT M10
WASHER
SPRING WASHER
DESCRIPTION
NUT M12
SPRING WASHER
SCREW M12
WXVS95B
120 MINUTES
QTY
4
4
4
4
QTY
2
2
2
Page 1
