TrueFlame Gas Grill User Manual
Models: TF25; TF32; TF40
TF25L; TF32L; TF40L
DANGER
Shut OFF gas supply to the appliance.
Extinguish any open flame.
Open lid.
If odor continues, keep away from the appliance
and immediately call your gas supplier or your fire
department.
WARNING
Do not store or use gasoline or other flamable liquids or
vapors in the vicinity of this or any other appliance.
An LP cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
DO NOT leave this appliance burning when unattended.
1
Advertisement
Table of Contents
Related Manuals for TrueFlame TF25L
Summary of Contents for TrueFlame TF25L
- Page 1 TrueFlame Gas Grill User Manual Models: TF25; TF32; TF40 TF25L; TF32L; TF40L ATTENTION: INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER. CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE AND BEFORE INSTALLING OR OPERATING. DANGER If you smell gas: •...
-
Page 2: Explosion Hazard
WARNINGS READ THIS MANUAL CAREFULLY AND COMPLETELY EXPLOSION HAZARD: BEFORE USING YOUR GRILL TO REDUCE THE RISK DO NOT use the grill as a storage area for flammable materials. Keep area clear and free from combustible Fire, burn hazard, personal injury or property damage, materials, gasoline, and other flammable vapors and improper installation or servicing electric shock. -
Page 3: For Your Records
THANK YOU TF25L; TF32L; TF40L Thank you for your purchase. We’d like to welcome you to the TrueFlame family of luxury outdoor kitchen (Natural Gas & Liquid Propane Gas Configurations) products, and we look forward to being a part your home for years to come. -
Page 4: Safety And Installation Warnings
WARNINGS SAFETY AND INSTALLATION WARNINGS • Please read all instructions before installation or operating your gas grill to prevent injury and appliance damage • All gas grills will get hot during use. Use extreme caution when operating the grill • Do not touch hot surfaces. -
Page 5: Before Grilling
BEFORE GRILLING UNPACKING YOUR GRILL IMPORTANT NOTES: BE MINDFUL OF WIND DIRECTION Included with your TrueFlame grill are the following loose items: Using your grill in windy conditions may disrupt the front- Burner Covers: TF25(3), TF32(4), TF40(5) to-back air flow that the grill is designed for. If you notice... -
Page 6: Installation
INSTALLATION TrueFlame Grills are a “built-in” gas grill that requires a MINIMUM GRILL CLEARANCES: non-combustible island/enclosure. Use Figure 1 and Table Minimum clearances between the grill and any side wall or 1 as a guide. rear wall must fall within one (or more) of the following:... -
Page 7: Overhead Construction And Exhaust Hood Requirements
8” clearance between the grill and protected wall.) When installing this grill in a combustible surround, an TrueFlame insulating jacket/grill liner must be used. A minimum five (5) foot clearance is required between the countertop and the overhead construction. -
Page 8: Gas Lines
GAS REQUIREMENTS NATURAL GAS REQUIREMENTS WARNING • TrueFlame recommends that only qualified profession- als perform the required plumbing on this product. GAS LINES • Check the Rating Plate to make sure the gas Never connect a gas line directly to the grill. A... - Page 9 GAS REQUIREMENTS SAFE USE AND MAINTENANCE OF PROPANE GAS CYLINDERS IMPORTANT FOR YOUR SAFETY READ AND FOLLOW ALL WARNINGS PROVIDED WITH THE PROPANE GAS CYLINDER. When operating a Propane gas cylinder, these instructions and warnings MUST be observed. FAILURE TO DO SO MAY RESULT IN A SERIOUS FIRE OR EXPLOSION COUPLER OPERATION CYLINDER/CONNECTOR REQUIREMENTS To connect the regulator/hose to the Propane gas...
- Page 10 GAS REQUIREMENTS CONNECTING TO A SIDE BURNER LIQUID PROPANE INSTALLATION You will need a ‘T’ adapter fitting (not provided) or similar LP gas grill models are designed for use with a standard 20 connection to connect a single gas line to both a side lb.
-
Page 11: Ventilation Recommendations
CUSTOM-BUILT ENCLOSURES/ ISLANDS VENTILATION RECOMMENDATIONS IMPORTANT: Ventilation is required in the enclosure on opposite sides FOR ALL ENCLOSURES to create cross-ventilation. Liquid propane is heavier than natural gas and vents should be located near the bottom of FOR ALL GAS TYPES: the enclosure. - Page 12 OPERATION & MAINTENANCE TIPS READ INSTRUCTIONS READ INSTRUCTIONS BEFORE LIGHTING BEFORE LIGHTING MANUAL (MATCH LIGHT) IGNITION SPARK IGNITION CAUTION: Keep your face and body away from CAUTION: Keep your face and body away from the grill top when lighting the grill top when lighting Open the hood before lighting;...
- Page 13 Solutions used for cleaning concrete and masonry can be very corrosive and will ‘attack’ stainless steel MAINTENANCE TIPS • Be sure your TrueFlame products are well protected Stainless steels need to be cleaned for aesthetic before using these products. considerations and to preserve corrosion resistance.
-
Page 14: Optional Accessories
IMPORTANT NOTE: FOR LOCATIONS NEAR COASTAL AREAS AND POOLS: #304 stainless steel materials used in the construction of your TrueFlame grill are highly rust resistant, however, chlorine in the air from swimming pools or the salt from sea air may cause surface rust to appear and even create some pitting if left on the product. - Page 15 GRILL ILLUSTRATIONS TF25 TOP VIEW SIDE VIEW BACK VIEW FRONT VIEW TF32 TOP VIEW SIDE VIEW BACK VIEW FRONT VIEW TF40 TOP VIEW FRONT VIEW SIDE VIEW BACK VIEW 021325...
-
Page 16: Illustrated Parts
ILLUSTRATED PARTS 40” grill shown 021325... -
Page 17: Replacement Parts
REPLACEMENT PARTS *Extra replacement parts included with grill conversion kit TF25 TF32 TF40 TF25 TF32 TF40 ITEM ITEM DESCRIPTION ITEM ITEM DESCRIPTION QTY. QTY. QTY. QTY. QTY. QTY. 11116 TF25 Lid Assembly 11155 Logo-2 11117 TF32 Lid Assembly 11156 TF25 Drip Tray 11118 TF40 Lid Assembly 11157... -
Page 18: Natural Gas : Pipe Sizing Chart
GAS PIPE SIZING CHART REFERENCE GAS PIPE SIZING NATURAL GAS : PIPE SIZING CHART Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4” • Natural Gas (NG) flow is given in 1237 2259 3640... - Page 19 VENT HOOD INFORMATION 021325...
-
Page 20: Care And Cleaning
CARE & CLEANING INITIAL CLEANING AFTER INSTALLATION RUST INFORMATION • When first installed, remove all protective plastic as Rust-like brown spots are formed when oxygen comes into soon as possible. sustained contact with iron in a process called oxidation. • Clean the exterior stainless steel with stainless steel Oxygen is delivered to the metal from water, either from liq- cleaner (Bar Keeper’s Friend, Zep, or others) right after... -
Page 21: Warranty
WARRANTY Scan this QR code to view warranty details: 021325... - Page 22 Scan this QR code to view cutout details: 021325...
- Page 23 NOTES 021325...
- Page 24 For more information call Customer Care at 800-966-8126 Hours: 7am - 5pm PST 14520 DELTA LANE SUITE 105 HUNTINGTON BEACH, CA 92647 800.966.8126 021325...
