TrueFlame TFE25-NG User Manual

Hide thumbs

page of 20

/ 20
Bookmarks

Quick Links

Download this manual

ATTENTION:

INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER.

CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE

REFERENCE AND BEFORE INSTALLING OR OPERATING.

If you smell gas:

•

This appliance is designed as an "ATTENDED APPLIANCE".

072024

TrueFlame Gas Grill User Manual

Models: TFE25-NG; TFE32-NG

TFE25-LP; TFE32-LP

DANGER

Shut OFF gas supply to the appliance.

Extinguish any open flame.

Open lid.

If odor continues, keep away from the appliance

and immediately call your gas supplier or your fire

department.

WARNING

Do not store or use gasoline or other flamable liquids or

vapors in the vicinity of this or any other appliance.

An LP cylinder not connected for use shall not be stored

in the vicinity of this or any other appliance.

DO NOT leave this appliance burning when unattended.

Need help?

Do you have a question about the TFE25-NG and is the answer not in the manual?

Questions and answers

Summary of Contents for TrueFlame TFE25-NG

Page 1 TrueFlame Gas Grill User Manual Models: TFE25-NG; TFE32-NG TFE25-LP; TFE32-LP ATTENTION: INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER. CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE AND BEFORE INSTALLING OR OPERATING. DANGER If you smell gas: •...
Page 2 WARNINGS READ THIS MANUAL CAREFULLY AND COMPLETELY EXPLOSION HAZARD: BEFORE USING YOUR GRILL TO REDUCE THE RISK DO NOT use the grill as a storage area for flammable materials. Keep area clear and free from combustible Fire, burn hazard, personal injury or property damage, materials, gasoline, and other flammable vapors and improper installation or servicing electric shock.
Page 3 THANK YOU TFE25-LP; TFE32-LP Thank you for your purchase. We’d like to welcome you to the TrueFlame family of luxury outdoor kitchen (Natural Gas & Liquid Propane Gas Configurations) products, and we look forward to being a part your home for years to come. As a family business with...
Page 4 WARNINGS SAFETY AND INSTALLATION WARNINGS • Please read all instructions before installation or operating your gas grill to prevent injury and appliance damage • All gas grills will get hot during use. Use extreme caution when operating the grill • Do not touch hot surfaces.
Page 5 BEFORE GRILLING UNPACKING YOUR GRILL IMPORTANT NOTES: BE MINDFUL OF WIND DIRECTION Included with your TrueFlame grill are the following loose items: Using your grill in windy conditions may disrupt the front- Burner Covers: TFE25(3), TFE32(4) to-back air flow that the grill is designed for. If you notice...
Page 6 INSTALLATION TrueFlame Grills are a “built-in” gas grill that requires a MINIMUM GRILL CLEARANCES: non-combustible island/enclosure. Use Figure 1 and Table Minimum clearances between the grill and any side wall or 1 as a guide. rear wall must fall within one (or more) of the following:...
Page 7 ( 4” non-combustible material clearance, plus an additional boat. 10” clearance between the grill and protected wall.) When installing this grill in a combustible surround, an TrueFlame insulating jacket/grill liner must be used. Min. 14” Non-Combustible A minimum five (5) foot clearance is required between the Substrate countertop and the overhead construction.
Page 8 GAS REQUIREMENTS NATURAL GAS REQUIREMENTS WARNING • TrueFlame recommends that only qualified profession- als perform the required plumbing on this product. GAS LINES • Check the Rating Plate to make sure the gas Never connect a gas line directly to the grill. A...
Page 9 GAS REQUIREMENTS SAFE USE AND MAINTENANCE OF PROPANE GAS CYLINDERS IMPORTANT FOR YOUR SAFETY READ AND FOLLOW ALL WARNINGS PROVIDED WITH THE PROPANE GAS CYLINDER. When operating a Propane gas cylinder, these instructions and warnings MUST be observed. FAILURE TO DO SO MAY RESULT IN A SERIOUS FIRE OR EXPLOSION COUPLER OPERATION CYLINDER/CONNECTOR REQUIREMENTS To connect the regulator/hose to the Propane gas...
Page 10 GAS REQUIREMENTS CONNECTING TO A SIDE BURNER LIQUID PROPANE INSTALLATION You will need a ‘T’ adapter fitting (not provided) or similar LP gas grill models are designed for use with a standard 20 connection to connect a single gas line to both a side lb.
Page 11 CUSTOM-BUILT ENCLOSURES/ ISLANDS VENTILATION REQUIREMENTS IMPORTANT: Ventilation is require in the enclosure on opposite sides FOR ALL ENCLOSURES to create cross-ventilation. Liquid propane is heavier than natural gas and vents should be located near the bottom of FOR ALL GAS TYPES: the enclosure.
Page 12 OPERATION & MAINTENANCE TIPS READ INSTRUCTIONS READ INSTRUCTIONS BEFORE LIGHTING BEFORE LIGHTING MANUAL (MATCH LIGHT) IGNITION SPARK IGNITION CAUTION: Keep your face and body away from CAUTION: Keep your face and body away from the grill top when lighting the grill top when lighting Open the hood before lighting;...
Page 13 ‘attack’ stainless steel • Be sure your TrueFlame products are well protected GRILL EXTERIOR before using these products. Routinely wipe down your grill exterior with warm water and finish by applying stainless steel polish.
Page 14 IMPORTANT NOTE: FOR LOCATIONS NEAR COASTAL AREAS AND POOLS: #304 stainless steel materials used in the construction of your TrueFlame grill are highly rust resistant, however, chlorine in the air from swimming pools or the salt from sea air may cause surface rust to appear and even create some pitting if left on the product.
Page 15 GRILL ILLUSTRATIONS TFE25 21.654 22.197 23.094 24.984 TOP VIEW FRONT VIEW SIDE VIEW BACK VIEW TFE32 30.409 32.441 TOP VIEW FRONT VIEW SIDE VIEW BACK VIEW 072024...
Page 16 ILLUSTRATED PARTS 32” grill shown 072024...
Page 17 PARTS LIST TFE25 TFE32 TFE25 TFE32 ITEM ITEM DESCRIPTION ITEM ITEM DESCRIPTION QTY. QTY. QTY. QTY. 11058 - TFE25 Hood 11154 - Logo-1 11059 - TFE32 Hood 11155 - Logo-2 11053 - TFE Hood Pivot Hard- 11156 - 25” Grill Drip Tray ware 11157 - 32”...
Page 18 WARRANTY Scan this QR code to view warranty details: 072024...
Page 19 Scan this QR code to view cutout details: 072024...
Page 20 For more information call Customer Care at 800-966-8126 Hours: 7am - 5pm PST 14520 DELTA LANE SUITE 105 HUNTINGTON BEACH, CA 92647 800.966.8126 072024...
