Care 700 Series
Care Support Arms with Care Seat
Installation and Maintenance Instructions
CAREARM
CAREARM-WDF
technical data
Material
Load Rating
Compatibility
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00636_18 Feb 2025
1300 369 273 | info@enware.com.au | enware.com.au
Frame: powder coated stainless steel
Maximum 60kg each support arm
CARE700 series toilet with Care seat
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Watts ENWARE Care 700 Series
Summary of Contents for Watts ENWARE Care 700 Series
- Page 1 Care 700 Series Care Support Arms with Care Seat Installation and Maintenance Instructions CAREARM CAREARM-WDF technical data Material Frame: powder coated stainless steel Load Rating Maximum 60kg each support arm Compatibility CARE700 series toilet with Care seat NOTE: Enware Australia advises: 1.
- Page 2 dimensions 45° Corner Set Up MINIMUM MINIMUM Finished Wall www.enware.com.au Page 2 © Enware Pty Ltd...
-
Page 3: Installation
installation IMPORTANT: Ensure WC pan is securely fixed to the floor with pan screws or floor mounting bracket so that the WC pan is able to withstand the extra force applied by the arm supports. Fixing pan to the floor with only silicone sealant will not be an adequate method of fixing. (See CARE700 Series toilet installation instructions for more details.) NOTE: The Support Arms cannot be installed on their own without a matching Care toilet seat hinge... - Page 4 Fit hinge fixing bolts to the seat, then fit the seat from top of pan. Fix the seat in place with washers and nuts from underneath, and tighten the nuts. (max. torque 6Nm) Max 6NM From the underside, locate the adjustment screw on base frame next to seat fixing bolt.
- Page 5 Attach support arms to base frame, then tighten the screws to secure the arms in place. max 60 kg max 60 kg www.enware.com.au Page 5 © Enware Pty Ltd...
-
Page 6: Maintenance
maintenance CLEANING • Enware Products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. • Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. • Do not use cream cleaners, as they are abrasive. •... -
Page 7: Spare Parts
spare parts DESCRIPTION PART CODE Care toilet seat double flap white CARESEAT-WDF Care support arms CAREARM Care support arms with Care toilet seat double flap white CAREARM-WDF Hinge kit for Care seat CARE-S027 Toilet roll holder for support arm CARE-TRH www.enware.com.au Page 7 ©... -
Page 8: Product Warranty Statement
- WATTS AUSTRALIA EFFECTIVE FROM 20 November 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662...
