KMC Controls rc allen RCA22 Series Installation & Operation Manual page 5

Ø 3.125
0
2
3.38
1 0
( TYP )
10 10
20 20
INSTALL LAMP TRAY
AS SHOWN, WIRES
EXIT THIS END
2 0
3.38
1 0
( TYP )
10 10
20 20
6-32 UNC 2B
(4 PL)
Rev B
RCA22 Series Installation/Operation Guide
6-32 UNC 2B
(4 PL)
0.12
1.0
RCA22-7 SHOWN
UNLIGHTED (TYPICAL)
0.375
1.00
RCA22-11 SHOWN
LIGHTED (TYPICAL)
Figure 1.1, General Dimensions (Typical)
KMC Publication No. 1405
VACUUM
PORT
4.70
6.25 MAX
4.95
6.50 MAX
NOTE:
• All dimensions are in inches.
• Screw length: 0.38 plus bezel & panel thickness.
• Light wiring: White - power, Black - Ground.
KMC
KELLY MANUFACTURING COMPANY
1/4-18 NPTF
NYLON FITTING
AIR
VACUUM GAGE
1/8-27 NPTF
NYLON FITTING
REAR VIEW
(TYPICAL)
Ø 0.170
Ø 3.17
(4 PL)
1.237
2.474
PANEL CUTOUT
REAR MOUNTING
(TYPICAL)
Page 3 of 9
