Reference Manual
12G-SDI Analog Audio
Embedder / De-Embedder
This Manual Supports Device Revisions:
PDM 5380 Firmware Revision
LynxCentraal
APPolo Server Release
Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form
or by any means, electronic or mechanical for any purpose, without express written permission of LYNX Technik AG.
LYNX Technik AG may have patents, patent applications, trademarks, copyrights or other intellectual property rights covering the subject
matter in this document. Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to
patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.
PDM 5348 O
Revision 1.1 – May 2025
© 2025 LYNX Technik AG all rights reserved
1249
1.8.0
8.22.0
Advertisement
Table of Contents
Related Manuals for LYNXTechnik 5000 Series
Summary of Contents for LYNXTechnik 5000 Series
- Page 1 Reference Manual PDM 5348 O 12G-SDI Analog Audio Embedder / De-Embedder Revision 1.1 – May 2025 This Manual Supports Device Revisions: PDM 5380 Firmware Revision 1249 LynxCentraal 1.8.0 APPolo Server Release 8.22.0 Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical for any purpose, without express written permission of LYNX Technik AG.
-
Page 2: Table Of Contents
Module Layout .................... 10 Connections ................. 11 Video ......................11 Audio ......................11 Optional Fiber ..................... 12 Installation ................... 12 Settings and Control ..............13 Auto Store ....................13 Reset Button ....................13 © 2025 LYNXTechnik ® Page 2 of 21... - Page 3 New Control Window ..................19 Rename ....................... 20 Save Settings Now ..................... 20 Lock ........................20 Reset Factory Defaults ..................20 Service ..................21 Parts List ....................21 Technical Support ..................21 Contact Information ..............21 © 2025 LYNXTechnik ® Page 3 of 21...
-
Page 4: Warranty
TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. LYNX TECHNIK AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER LYNX TECHNIK OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES. © 2025 LYNXTechnik ® Page 4 of 21... -
Page 5: Regulatory Information
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. © 2025 LYNXTechnik ® Page 5 of 21... -
Page 6: Getting Started
Connect the strap to any solid grounding source such as any exposed metal on the rack chassis or any other unpainted metal surface. Caution Periodically check the resistance value of the antistatic strap. The measurement should be between 1 and 10 Megohms. © 2025 LYNXTechnik ® Page 6 of 21... -
Page 7: Product Description
Embedded audio group selection • Embedding into test pattern output video frame with no SDI input signal • 2x 12G-SDI outputs • Selectable Horizontal and Vertical Video Blanking • Optional optical interface (RX and/or TX) © 2025 LYNXTechnik ® Page 7 of 21... -
Page 8: Functional Diagram
59.94 (1.5G-SDI) 1080p 29.97 SMPTE 424M 1080p 59.94 (3G-SDI) SMPTE 2081 2160p 29.97 (6G-SDI) SMPTE 2082 2160p 47.95 59.94 (12G-SDI) Output Video Formats Output Video formats are identical to Input Video Formats. © 2025 LYNXTechnik ® Page 8 of 21... -
Page 9: Video And Audio Delay
/ swapped before embedding. Note: The mono-switching function is only accessible using the Module GUI via the control system. The local menu system and display only allow for switching of stereo pairs © 2025 LYNXTechnik ® Page 9 of 21... -
Page 10: Audio Group Deletion
The PDM 5380 will detect any audio groups present in the SDI stream, and each group can be selected individually. The user has the choice of passing any existing embedded audio group(s) intact, replacing the audio group(s) or deleting the audio group(s). Module Layout © 2025 LYNXTechnik ® Page 10 of 21... -
Page 11: Connections
XLR connectors. Model number RAC M 25-8 or RAC F 25-8 Figure 1:SubD25 Audio connector (looking into connector from back of module) © 2025 LYNXTechnik ® Page 11 of 21... -
Page 12: Optional Fiber
Remove the rear connection panel and check alignment with the CardModule. 5. Insert and remove the CardModule a few times to ensure correct alignment and then tighten the two screws to secure the rear connection plate. © 2025 LYNXTechnik ® Page 12 of 21... -
Page 13: Settings And Control
This LED indicates the status of the SDI input signal LED Color Indication LED Col Green SDI present and ok Yellow SDI ok, but unsupported standard, no embedding takes place No valid SDI standard © 2025 LYNXTechnik ® Page 13 of 21... -
Page 14: Alarm Indicator
(main power supply and redundant power supply). LED 1 Indication Green Power from Main PSU ok No power from Main Power Supply LED 2 Indication Green Power from Redundant PSU ok No power from Redundant PSU © 2025 LYNXTechnik ® Page 14 of 21... -
Page 15: Control System Gui
GUI screens with controls for these specific functions. There are several Tabs associated with each Module which split up the module’s settings into several separate screens. The primary GUI screens and functions are described below. © 2025 LYNXTechnik ® Page 15 of 21... -
Page 16: Main Tab
Audio ports that are configured as outputs are greyed out in the input section. Note: Input and output signals can be renamed by the user. Simply right- click on the signal name and specify a user-defined signal name © 2025 LYNXTechnik ® Page 16 of 21... -
Page 17: Audio Crossbars
The required audio full-scale levels can be adjusted for the input A/D conversion and the output D/A conversion. To avoid level changes through conversion, the full-scale level of the input and output conversion should be set to the same level. © 2025 LYNXTechnik ® Page 17 of 21... -
Page 18: Aes Processing Tab
Please check connected peripheral equipment before using the PDM 5348 O to make sure the audio ports are configured correctly, e.g. an output is not connected to an output of another device, this might damage the equipment. © 2025 LYNXTechnik ® Page 18 of 21... -
Page 19: Common Gui Controls
“locate “button on the top right-hand side of the screen. New Control Window Opens a new control window for the selected module. This window can be minimized to the taskbar for faster access. © 2025 LYNXTechnik ® Page 19 of 21... -
Page 20: Rename
You will be asked to confirm this operation with the dialog below © 2025 LYNXTechnik ® Page 20 of 21... -
Page 21: Service
E-Mail info@lynx-technik.com LYNX Technik manufactures a complete range of high-quality modular products for broadcast and Professional markets. Please contact your local representative or visit our web site for more product information. © 2025 LYNXTechnik ® Page 21 of 21...
